10GBASE-CX4 Study Group

This study group, led by Chris Di Minico at CDT Corporation, focuses on establishing transmission characteristics for 10GBASE-CX4 cable assemblies, specifically designed for InfiniBand applications. Key specifications include analyzing parameters such as impedance, insertion loss, pair-to-pair skew, and jitter across a 10-15 meter range using 24 AWG cabling. The objective is to ensure compliance with 10GBASE-CX4 and InfiniBand electrical requirements while providing worst-case HSPICE models for rigorous testing. The insertion loss must be less than TBD dB from TBD MHz to TBD GHz.

july
Télécharger la présentation

10GBASE-CX4 Study Group

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 10GBASE-CX4 Study Group Chris Di MinicoCDT Corporation cd@mohawk-cdt.com

  2. Channel Specification Development • PAR Objective • 10-15 meter (24 AWG) - InfiniBand Cable Assembly • EstablishTransmission Characteristics (worst case) • Impedance • Impedance Deviation • Insertion Loss • Pair-to-Pair Skew • Jitter • Return Loss • MDNEXT • other • HSPICE(?) Models for worst case

  3. 10GBASE-CX4 Cable Assembly Characteristics 4X InfiniBand Cable Assembly InfiniBand 4X Electrical Requirements (1.25 GHz) 10GBASE-T Additional Electrical Requirements (1.56 GHz)

  4. 10GBASE-CX4 Compliance Channel 10GBASE-CX4- Compliance Channel Insertion loss: The insertion loss of each pair of the CX4 cable assembly shall be less than: Insertion_Loss(f) < TBD (dB) at all frequencies from TBD MHz to TBD GHz. This includes the attenuation of the differential cabling pairs, and the connector (i.e., the assembly).
