  1. Perfect for Special Applications

  2. Out Buildings Garages and Studios Small Business One or Two Camera Installs Moveable To Various Rooms for Various Reasons Distant Locations Boat Docks, Work Areas, Gardens Eliminates Damaging Walls Ornate Internal Stone Walls in Churches

  3. Camera And Transmitter Installation

  4. Receiver and Monitor Installation

  5. Turn on Monitor • Make the Appropriate Settings

  6. Perfect DI (VGA+) Resolution PLUG, PLAY and WALK AWAY!

  7. Additional Application Notes

  8. Units work up to 1000 ft LINE OF SITE 300 ft through MODEST OBSTRUCTIONS

  9. Signal will not pass through… Multiple Elevator Shafts Large Bodies of Water

  10. Up to 4 Transmitters 4 Receivers Per Install

  11. Place TRANSMITTERS More than 10 Feet Apart

  12. Units are not WATERPROOF BUT Can be placed in an “Ernie” Box As a Waterproofing Solution.

  13. If necessary extend the antenna with a JUMPER The JUMPERS should be the same length at both the TRANSMITTER AND RECEIVER And should not exceed 9 Ft in JUMPER length

  14. Kit Cost IS LESS THAN $300

  15. Successful Installation Environments

  16. 60 FEET through CONCRETE ROOM and CLOSED METAL DOOR

  17. 160 FEET through SHOWROOM AND WAREHOUSE, MILD ELECTRONICS, INTERNAL WALLS and METAL RACKS

  18. 260 FEET across a PARKING LOT, GRASS MEDIAN and a 2 LANE HIGHWAY to a DISTANT BUILDING CONFERENCE ROOM

  19. 200 FEET down 4 STORE FRONTS through 3 WALLS and a DRY CLEANER STORE

  20. ALL WORKED PERFECTLY!
