  1. Versaprop Increased Value Increased Strength Increased Profitability

  2. Versaprop • Higher Conductivity per $ • 25% to 37% more conductivity • Greater Strength • Only 1.4% Crush at 7,500 psi • Increased Productivity • More conductivity means increased effective fracture half-lengths

  3. Conductivity Comparison 10000 20/40 Econoprop 20/40 Valuprop Conductivity, md-ft Economic Light-weight ceramic proppants provide good conductivity per dollar of cost 2 250 deg F, 2 lbs/ft Ohio Sandstone 1000 0 2000 4000 6000 8000 10000 12000 Closure Stress, psi

  4. Conductivity Comparison 10000 20/40 Econoprop Versaprop 20/40 Valuprop Conductivity, md-ft Versaprop provides 25% to 37% more conductivity at light-weight ceramic costs 2 250 deg F, 2 lbs/ft Ohio Sandstone 1000 0 2000 4000 6000 8000 10000 12000 Closure Stress, psi

  5. Versaprop provides conductivity within 10% of premium light-weight ceramics at lower costs

  6. Versaprop provides conductivity above that of intermediate ceramics as lower costs

  7. 30/50 API ceramic proppants range in MPD from 0.43 mm to 0.512 mm

  8. 20/40 API ceramic proppants range in MPD from 0.635 mm to 0.723 mm

  9. 16/30 API ceramic proppants range in MPD from 0.928 mm to 0.974 mm

  10. While Versaprop is not a 20/40 API proppant, It’s MPD is very similar to one

  11. Typical

  12. Typical

  13. Typical

  14. Versaprop A medium density (3.2 g/cc) ceramic proppant which through grain size and strength provides increased conductivity (25% - 37%) at competitive prices to light-weight economic ceramic proppants.

  15. Versaprop • A proppant for the widest range of application • High conductivity at low stresses • High conductivity and strength at high stresses
