  1. Gravity in Motion Section 6-1 Pages 150 - 156

  2. In the beginning…. • According to the Greek philosopher Aristotle, an object’s mass affects how fast it will fall • He said that objects with larger masses will fall faster • Aristotle never actually tested his theory • Italian scientist Galileo argued that the mass of an object des not affect the time it takes to fall to the ground • He proved this by dropping two different massed canon balls from the Leaning Tower of Pisa and they landed at the same time

  3. Gravity and Acceleration • The reason the two cannon balls hit the ground at the same time is because acceleration due to gravity is the same for all objects • As we’ve talked about before, acceleration depends on mass and force • A heavier object experiences greater gravitational force but is harder to accelerate due to its increased mass • The extra mass of the heavier object balances the additional gravitational force

  4. Acceleration due to gravity • Remember that acceleration is the rate at which velocity changes over time • All objects accelerate toward Earth at a rate of 9.8 m/s2 • This means that for every second an object falls toward the Earth, its velocity increases by 9.8 m/s

  5. Calculating change in velocity • Δv = g x t • Δ (delta) stands for change in • Δv = change in velocity • g = acceleration due to Gravity (always 9.8 m/s2) • t = time the object takes to fall (in seconds) • Do Math focus on page 151 as a class

  6. Air resistance • Two pieces of paper, one flat and one crumpled • They will not fall at the same rate • This is because of air resistance • The force that opposes motion of objects in the air • Its pushes up against the object, going against the force of gravity • The amount of air resistance depends on the size, shape and speed of the object • The more surface area, the more air resistance • The more mass, the less air resistance • The faster the object moves, the more air resistance

  7. We have reached Terminal Velocity • Objects do not continue to accelerate (increase their velocity) forever until they hit the ground • This is because air resistance continues to increase as speed increases • Air resistance increases until it is equal to the force of gravity • Results in a net force of 0N • Is there any further change in motion (increase in speed) if net force is 0N? • NO!!

  8. When net force is 0N, the object falls at a constant velocity which is called its terminal velocity • Terminal means at the end • Terminal velocity is a good thing • Think about hail storms • If large chunks of hail did not reach a terminal velocity (usually between 5 and 40 m/s), they could reach velocities of up to 350 m/s! • Terminal velocity is reached at a faster pace when using a parachute – allows sky divers and airmen to reach the ground at a safer speed

  9. Free Falling • When you ride the Free Fall at Six Flags, you are not really in free fall • Free Fall occurs when gravity is the only force acting on an object • Therefore, the only place you can experience free fall is in space where there is no air • Why? • If there is air, there is air resistance, which is a force

  10. Weightless or not? • Astronauts are said to be weightless when they are in space and that is why they float, but… • You can never truly be weightless • Why not? • Everything creates a gravitational force so there will always be something around you that causes you to have weight • So why do astronauts float? • They are in free fall as they orbit the Earth

  11. Orbits – not the gum • An object is orbiting when it is traveling around another object in space • It is caused when an object is moving forward, but it is also in free fall (being pulled towards the Earth or another object due to gravity) • The two forces combine to create a circular path of motion • Remember that any object traveling in a circular path is constantly changing direction • A force that causes circular motion is called a centripetal force

  12. Aim High • Projectile motion is the curved path an object takes when it is thrown near the Earth’s surface • Two parts to projectile motion • Horizontal motion • Ie: Caused by the force of your hand throwing the ball • Vertical motion • Caused by gravity • When these two parts combine, they cause a curved path of motion
