  1. Peer-to-Peer Systems Chapter 25

  2. What is Peer-to-Peer (P2P)? • Napster? • Gnutella? • Most people think of P2P as music sharing

  3. What is a peer? • Contrasted with Client-Server model • Servers are centrally maintained and administered • Client has fewer resources than a server

  4. What is a peer? • A peer’s resources are similar to the resources of the other participants • P2P – peers communicating directly with other peers and sharing resources

  5. P2P Concepts Client-client as opposed to client-server File sharing: I get a copy from someone, and now make it available for others to download---copies are/workload is spread out Advantages: Scalable, stable, self-repairing Process: A peer joins the system when a user starts the application, contributes some resources while making use of the resources provided by others, and leaves the system when the user exits the application. Session: One such join-participate-leave cycle Churn: The independent arrival and departure by thousands—or millions— of peers creates the collective effect we call churn. The user-driven dynamics of peer participation must be taken into account in both the design and evaluation of any P2P application. For example, the distribution of session length can affect the overlay structure, the resiliency of the overlay, and the selection of key design parameters.

  6. Types of clients • Based on the client behavior, there are three types of clients: • True clients (not active participants; take but don’t give; short duration of stay) • Peers: Clients that stay long enough and well-connected enough to participate actively (Take and give) • Servers (Give, but don’t take) • Safe vs. probabilistic protocols • Mostly logarithmic order of performance/cost

  7. Levels of P2P-ness • P2P as a mindset • Slashdot • P2P as a model • Gnutella • P2P as an implementation choice • Application-layer multicast • P2P as an inherent property • Ad-hoc networks

  8. P2P Goals/Benefits • Cost sharing • Resource aggregation • Improved scalability/reliability • Increased autonomy • Anonymity/privacy • Dynamism • Ad-hoc communication

  9. P2P File Sharing • Content exchange • Gnutella • File systems • Oceanstore • Filtering/mining • Opencola

  10. P2P File Sharing Benefits • Cost sharing • Resource aggregation • Improved scalability/reliability • Anonymity/privacy • Dynamism

  11. P2P Application Taxonomy P2P Systems Distributed Computing SETI@home File Sharing Gnutella Collaboration Jabber Platforms JXTA

  12. Management/Placement Challenges • Per-node state • Bandwidth usage • Search time • Fault tolerance/resiliency

  13. Approaches • Centralized • Flooding • Document Routing

  14. Centralized • Napster model • Benefits: • Efficient search • Limited bandwidth usage • No per-node state • Drawbacks: • Central point of failure • Limited scale Bob Alice Judy Jane

  15. Flooding • Gnutella model • Benefits: • No central point of failure • Limited per-node state • Drawbacks: • Slow searches • Bandwidth intensive Carl Jane Bob Alice Judy

  16. Connectivity

  17. Napster • Uses a centralized directory mechanism • To control the selection of peers • To generate other revenue-generating activities • In addition is has several regional servers • Users first connect to the Napster’s centralized server to one of the regional servers • Basically, each client system has a Napster proxy that keeps track of the local shared files and informs the regional server • Napster uses some heuristic evaluation mechanisms about the reliability of a client before it starts using it as a shared workspace

  18. Gnutella and Kazaa • Unlike Napster, it is a pure P2P with no centralized component---all peers are completely equal • Protocol: • Ensures that each user system is concerned with a few Gnutella nodes • Search for files: if the distance specified is 4, then all machines within 4 hops of the client will be probed (1st all M/C within 1 hop; then 2 hops; and so on) • The anycast mechanism becomes extremely costly as system scales up. • Kaaza also does not have a centralized control (as Gnutella); it uses Plaxton trees.

  19. CAN • Content Addressable Network • Each object is expected to have a unique system wide name or identifier • The name is hashed into a d-tuple--- identifier is converted into a random-looking number using some cryptographic hash function • In a 2-dimensional CAN the id is hashed to a 2-dimensional tuple: (x,y) • Same scheme is used to convert machine IDs • Recursively subdivide the space of possible d-dimensional identifiers, storing each object at the node owning the part of the space (zone) that object’s ID falls in. • When a new node is added, it shares its space with the new node; similarly when a node leaves, its space is owned by a nearby node • Once a user provides the search key, it is converted to (x,y); the receiving CAN node finds a path from itslef to the node having (x,y) space. If d is the dimensions, and N is the #of nodes, then the number of hops is (d/4)*N1/d • TO take care of node failures, there will be backups. • Cost is high when there are frequent joins/leaves

  20. Document Routing 001 012 • FreeNet, Chord, CAN, Tapestry, Pastry model • Benefits: • More efficient searching • Limited per-node state • Drawbacks: • Limited fault-tolerance vs redundancy 212 ? 212 ? 332 212 305

  21. Document Routing – CAN • Associate to each node and item a unique id in an d-dimensional space • Goals • Scales to hundreds of thousands of nodes • Handles rapid arrival and failure of nodes • Properties • Routing table size O(d) • Guarantees that a file is found in at most d*n1/d steps, where n is the total number of nodes Slide modified from another presentation

  22. CAN Example: Two Dimensional Space • Space divided between nodes • All nodes cover the entire space • Each node covers either a square or a rectangular area of ratios 1:2 or 2:1 • Example: • Node n1:(1, 2) first node that joins  cover the entire space 7 6 5 4 3 n1 2 1 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  23. CAN Example: Two Dimensional Space • Node n2:(4, 2) joins  space is divided between n1 and n2 7 6 5 4 3 n2 n1 2 1 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  24. CAN Example: Two Dimensional Space • Node n2:(4, 2) joins  space is divided between n1 and n2 7 6 n3 5 4 3 n2 n1 2 1 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  25. CAN Example: Two Dimensional Space • Nodes n4:(5, 5) and n5:(6,6) join 7 6 n5 n4 n3 5 4 3 n2 n1 2 1 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  26. CAN Example: Two Dimensional Space • Nodes: n1:(1, 2); n2:(4,2); n3:(3, 5); n4:(5,5);n5:(6,6) • Items: f1:(2,3); f2:(5,1); f3:(2,1); f4:(7,5); 7 6 n5 n4 n3 f4 5 4 f1 3 n2 n1 2 f3 1 f2 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  27. CAN Example: Two Dimensional Space • Each item is stored by the node who owns its mapping in the space 7 6 n5 n4 n3 f4 5 4 f1 3 n2 n1 2 f3 1 f2 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  28. CAN: Query Example • Each node knows its neighbors in the d-space • Forward query to the neighbor that is closest to the query id • Example: assume n1 queries f4 • Can route around some failures • some failures require local flooding 7 6 n5 n4 n3 f4 5 4 f1 3 n2 n1 2 f3 1 f2 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  29. CAN: Query Example • Each node knows its neighbors in the d-space • Forward query to the neighbor that is closest to the query id • Example: assume n1 queries f4 • Can route around some failures • some failures require local flooding 7 6 n5 n4 n3 f4 5 4 f1 3 n2 n1 2 f3 1 f2 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  30. CAN: Query Example • Each node knows its neighbors in the d-space • Forward query to the neighbor that is closest to the query id • Example: assume n1 queries f4 • Can route around some failures • some failures require local flooding 7 6 n5 n4 n3 f4 5 4 f1 3 n2 n1 2 f3 1 f2 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  31. CAN: Query Example • Each node knows its neighbors in the d-space • Forward query to the neighbor that is closest to the query id • Example: assume n1 queries f4 • Can route around some failures • some failures require local flooding 7 6 n5 n4 n3 f4 5 4 f1 3 n2 n1 2 f3 1 f2 0 0 2 3 4 6 7 5 1 Slide modified from another presentation

  32. CFS and PAST • Files are replicated prior to storage---copies are stored at adjacent locations in the hashed-id space • Make use of indexing systems to locate nodes on which they store objects or from which they retrieve copies • IDs are hashed to a 1-dimensional space • Leaves/Joins result in several file copies---could be a bottleneck

  33. OceanStore • Focused on long term archival storage (rather than file sharing)---e.g., digital libraries • Ensure codes --- class of error-correcting codes that can reconstruct a valid copy of a file given some percentage of copies

  34. Distributed Indexing in P2P • Two requirements: • A lookup mechanism to track down a node holding an object • A superimposed file system that knows how to store and retrieve files • DNS---a distributed object locator: M/C names to IP addresses • P2P indexing tools let users store (key, value) pairs---a distributed hash system

  35. Chord • It is a major DHT architecture • Forms a massive virtual ring in which every node in the distributed system is a member---each owning part of a periphery. • If hash value of a node is h, and the lower value is hL, and the higher is hH, then the node with h owns objects in the range: hL< k <= h • E.g., if a,b, c hash to 100, 120, and 175, respectively, then b is responsible for IDs in the range 101-120; c is responsible for 121-175. • When a new node joins, it computes its hash and then joins at the right place in the ring; then the corresponding range of objects are transferred to it. • Potential problems---adjacent nodes could be far apart in distance • Statistics: Average path length in an internet is 22 network routers leading an average length of 10 milliseconds; this further slowed by slow nodes

  36. Chord---cont. • Two mechanisms in Chord: • Applications that repeatedly access the same object---Chord nodes cache link information so that after the initial lookup each node on the path remembers (its IP addresses) all nodes on the path for future use. • When a node joins the Chord system, at hashed location hash(key), it looks up the nodes associated with hash(key)/2, hash(key)/4, hash(key)/8, etc. This is in a circular range. • It uses a binary search to locate an object resulting in log(N) search time; but this is not good enough---cached pointers help the effort • Frequent leaves creates dangling pointers—a problem • Churn—frequent joins/leaves---results in several key shuffles---a problem

  37. N5 N10 N110 K19 N20 N99 N32 N80 N60 Document Routing – Chord • MIT project • Uni-dimensional ID space • Keep track of log N nodes • Search through log N nodes to find desired key

  38. Pastry • Basic idea: Construction of a matrix (of size r x logrN) of pointers at each participating node---r is a radix and N is the size of the network; If N = 165 and r =5, then each matrix is of size 16 x 5. • Maps keys to a hashed space (like others) • By following the pointers, a request is routed closer and closer to the node owning the portion of the space that an object belongs to. • Hexadecimal addresses: with r=5, the address has 5 hexadecimals: 65A1FC as in the example. • Top row has: indices from 0 to F representing the 1st hexadecimal in the hash address. For 65A1FC, there is a match at 6, so it has another level of index: 0-F representing the 2nd position in the address. For the current node, there is a 2nd level match at 5; so this node is extended to next level from 0-F: once again there is a match at A which is further expanded to the 4th level; This has 0-F in the 4th position, current one matching at F. This is further expanded to 5th level from 0-F (not shown in Figure 25.5). Thus, it has 16 x 5 matrix of pointers to nodes. • To take care of joins/leaves, Pastry periodically probes each pointer (finger) and repairs broken links when it notices problems • It uses an application-level multicast (overlay multicast architecture)

  39. Doc Routing – Tapestry/Pastry 43FE 993E 13FE • Global mesh • Suffix-based routing • Uses underlying network distance in constructing mesh 73FE F990 04FE 9990 ABFE 239E 1290

  40. Node Failure Recovery • Simple failures • know your neighbor’s neighbors • when a node fails, one of its neighbors takes over its zone • More complex failure modes • simultaneous failure of multiple adjacent nodes • scoped flooding to discover neighbors • hopefully, a rare event Slide modified from another presentation

  41. Comparing Guarantees Model Search State Chord Uni-dimensional log N log N Multi-dimensional CAN dN1/d 2d b logbN Tapestry Global Mesh logbN Pastry Neighbor map logbN b logbN + b

  42. Remaining Problems? • Hard to handle highly dynamic environments • Usable services • Methods don’t consider peer characteristics
