  1. E E 6372 High Voltage Engineering

  2. Generation and Transmission • Started with DC • Edison in NYC in 1882 • Holburn in London in 1882 • Low voltage DC cannot deliver much power due to voltage drop • Utilization had to be at low voltage • No effective method to alter voltage levels (until solid-state switching developed a century later)

  3. Generation and Transmission • AC Systems developed later • Nikola Tesla filed 7 patents in 1887 for inventions including the transformer, AC generator and motor. • Tesla backed financially by George Westinghouse • 10 kV system at Depford transmitted power 28 miles to London in 1890 • Tesla/Westinghouse exhibit at World’s Fair in 1893 in Chicago led the USA development

  4. Generation and Transmission • Power transmitted is proportional to V2/ZL where V is the voltage and ZL is the surge impedance. • Typical ZL = 250  • A voltage of 100 kV would allow 40 MW • A voltage of 1000 kV would allow 4 GW

  5. Generation and Transmission • This incentive led to higher voltages such as current levels of 345 kV, 500 kV and 765 kV. • New technologies (solid-state high voltage and high power switches) allow better utilization of existing ROW’s: • Static VAR compensators • DC transmission lines • Underground cable systems better with DC

  6. Voltage Stresses • Normal operating voltages not a threat unless • Pollutants/contaminants compromise insulation • Structural damage to insulation • External voltages (mainly lightning) • Less important at higher voltages • Internal voltages • Mainly switching and faults • Load & generator fluctuations

  7. Voltage Stresses • The balance between stress on insulation and dielectric strength is called insulation coordination. • Voper_level < Vprot_action < Vinsul_rating • In classical approach, Safety Margin = Vinsul_rating – Vprot_action

  8. Testing Voltages • Must test for over-voltages as well as rated ac and dc levels • Simulate switching surges & lightning strikes • AC voltage tests: 1 minute at rated frequency • Dry test only for indoor equipment • Wet and dry tests for outdoor equipment • “Standard rain” used for wet tests

  9. Lightning Impulses • Short rise time: 1 ms – 10’s of ms • Standard: 1.2 ms rise with half peak at 50 ms 1.2 ms 50 ms t

  10. Switching Impulses • Equipment vulnerable to slow rise times at around 100 – 300 ms. • Standard test pulse is 250 ms rise time to half peak at 2.5 ms.

  11. DC Test Voltages • Hard to test cables due to large capacitance • Use DC test voltages • Some premature failures due to dc testing • Now use very low frequency (VLF) at about 1 Hz
