  1. Hemoglobinopathy John Matthews and Dilys Rapson

  2. Hemoglobin structure α β β α heme

  3. Hemoglobins in normal adults α β α γ α δ β α γ α δ α HbA HbF HbA2 98% ~1% <3.5%

  4. Hemoglobin structure α β β α heme

  5. Heme

  6. Globin

  7. The Oxygen Dissociation Curve pAO2 pVO2 normal e.g. α2β2 abnormal e.g. β4

  8. Hemoglobin synthesis 25% 25% 0.5% 1.5% 48% α α γ δ β α α γ δ β 25% 25% 0.5% 1.5% 48% Chromosome 16 Chromosome 11

  9. Hemoglobinopathydefinition An inherited mutation of the globin genes leading to a qualitative or quantitative abnormality of globin synthesis

  10. Structural hemoglobinopathy Amino acid substitution in the globin chain e.g. sickle hemoglobin (HbS)

  11. The Thalassemias • Syndromes in which the rate of synthesis of a globin chain is reduced • beta thalassemia - reduced beta chain synthesis • alphathalassemia – reduced alpha chain synthesis

  12. Sickle Cell Anemia (HbSS) • β6 glu to val • ‘tactoids’ at low oxygen tension • sickled red cells • small blood vessel occlusion • tissue infarction

  13. Sickle Cell Anemia – blood film SickleCells Erythroblasts Howell-Jolly Body

  14. Sickle Cell Anemia – EM of red cell showing ‘tactoids’

  15. Sickle cell anemia – clinical features • Hemolysis • Occlusion of blood vessels by sickled red cells

  16. Sickle Cell Anemia - treatment • Opiates and hydration for painful crises • Pneumococcal vaccination • Retinal surveillance • Hydroxyurea • Transfusion for serious manifestations • Stem cell transplant • Support, folate, iron chelation

  17. Sickle Cell Trait • Heterozygous state for HbS (HbAS) • No serious clinical consequences • Sudden death during intensive training • Hematuria, isosthenuria (renal papillary necrosis)

  18. Beta thalassemia • Impaired production of beta chain • beta thalassemia minor – heterozygous (or trait) • beta thalassemia major - homozygous

  19. Beta thalassemia trait • No symptoms • Mild microcytic anemia

  20. Beta thalassemia major • No beta chain produced (no HbA) • Severe microcytic anemia occurs gradually in the first year of life • Marrow expansion • Iron overload • Growth failure and death

  21. Beta thalassemia major Male 18 years

  22. Beta thalassemia major treatment • Transfusion • Iron chelation • Stem cell transplant

  23. Alpha thalassemia

  24. Hemoglobinopathy-antenatal diagnosis • Test partners of heterozygous or affected individuals • Antenatal diagnosis from DNA obtained by chorionic villus sampling, or by amniocentesis
