Practice Histology Slides

Explore our interactive histology slides where you can test your knowledge of tissue types. Click on the slide to reveal the answer. From connective tissues like bone and hyaline cartilage, to various epithelial tissues including simple cuboidal and stratified squamous, this resource covers a broad spectrum of histological samples. You’ll also learn about muscle tissues like cardiac and skeletal muscle, as well as specialized cells such as goblet cells and neurons. Perfect for students and professionals looking to enhance their understanding of histology.

kyne
Télécharger la présentation

Practice Histology Slides

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Practice Histology Slides Click for the slide, click again for the answer…

  2. 1. Name this type of connective tissue. bone

  3. 2. Name the type of epithelial tissue at the pointer. simple cuboidal

  4. 3. Name this specific epithelial tissue? stratified squamous – non keratinized

  5. 4. Name the type of connective tissue at the pointer. hyaline cartilage

  6. 5. What is the tissue type on this slide? nervous

  7. 6. What type of muscle tissue is this? cardiac What are the structures at the end of the arrows? intercalated discs

  8. 9. What type of connective tissue is this? areolar

  9. 10. What is the cell type at the pointer? goblet cell

  10. 11. What two epithelial tissues are on this slide? keratinized stratified squamous simple cuboidal with goblet cells

  11. 12. What type of epithelial tissue is this? transitional

  12. 13. What is the connective tissue shown here? reticular

  13. 14. What is the type of epithelium shown here? Stratified squamous – keratinized

  14. 15. What type of epithelial tissue is this? pseudostratified ciliated columnar epithelium with goblet cells

  15. 16. What type of connective tissue is this? dense irregular

  16. 17. What type of epithelial tissue is this? stratified columnar

  17. 18. What type of connective tissue is this? adipose

  18. 19. What type of tissue is this? elastic tissue

  19. 20. What type of muscle tissue is shown here? cardiac muscle

  20. 21. What is the cell type at the pointer? neuron

  21. 22. What is the tissue shown here? skeletal muscle
