  1. GPS SECURITY& TRACKING SYSTEM X-TRAX GROUPGPS & SOFTWARE SOLUTIONS www.xtrax.it your world wide GPS partner

  2. Summary Summary: • 1. Location • 2. GPS Security & Tracking system • 3. Hardware solutions • 4. Software solutions • 5. Applications • 6. Certifications and approvals 2 X-TraX GPS & Software Solutions

  3. 1. Location 1. Location X-TraX s.n.c. di Mascarello Paolo e Limonta DavideHead office: Via Bosisio Orlando, 16 - 22035 Canzo(CO) - ITALY Latitude: 45°50’36” N; Longitude: 009°15’53” E; Altitude: 402 MtTel. +39.031.6121375; Fax +39.031.681557Mail: info@xtrax.it; Web: www.xtrax.itP. IVA / C.F. / N. Iscrizione Registro Imprese di Como: 03043380132CCIAA di Como R.E.A. N. 292652 3 X-TraX GPS & Software Solutions

  4. 2. GPS Security & Tracking system 2. GPS Security & Tracking system GENERAL DESCRIPTION: X-TraX GPS Security & Tracking System is a highly professional system, ideal for the monitoring and safety of vehicles, goods and people.It has been created paying special attention to every detail, in order to provide the maximum efficiency in any situation, 24 hours a day. Besides, thanks to the intelligent and flexible platform it’s possible to customize the system according to final users requirements, giving you the possibility to offer high level services that are difficult to find out on the market.It’s important to remind that all the systems offered by X-TraX have been developed by our own qualified staff, that has many years of experience in the security field.The system is based on latest concept hardware devices and fully certificated. They are:- AVL units (with integrated GSM/GPRS phone module and GPS receiver)- personal trackers (with integrated GSM/GPRS phone module and GPS receiver)- AVL units accessories (MDT with integrated car navigator and on board unit management software, hands free kit, R.F.I.D. system, temperature sensor, barcode reader and CanBus interface).Control Base Stations using this system require a network of qualified installers and technicians ready to intervene, as required, to meet with final users needs as promptly as possible in order to offer the best security service, in any conjuncture.Also the software platform is able to perform different solutions which are interesting and useful for the final user, as advanced logistic applications on PDA phones, fleet management by mobile phones or PDA or by web site (WebTraX). 4 X-TraX GPS & Software Solutions

  5. 2. GPS Security & Tracking system X-TRAX GPS SYSTEM GENERAL ARCHITECTURE: 5 X-TraX GPS & Software Solutions

  6. 3. Hardware solutions 3. Hardware solutions Hardware solutions offered by X-TraX are based on GSM/GPRS + GPS technologies. They are: AVL units, on board accessories and personal trackers.AVL UNITS: X-0 LITE X-8 X-2 X-8: AVL unitwith built-in GSM/GPRS Siemens tri-band module and 20 channelsSiRF Star III GPS receiver; External GSM and GPS antennas; Built-in rechargeable battery (Li-Polymer 830mAh); 8 digitalInputs (2 Positives and 6 Negatives) + 2 AnalogInputs + 7 digitalOutputs (3 Positives and 4 Negatives); Built-invibrationSensor.Complete and strong unit, itsupports a largerangeofaccessories.Easy to install, instantly locate and report your position by using GSM/GPRS devices or by web site.Suitable for logistic and security applications.Size: 166 x 102 x 37mm X-2: AVL unitwith built-in GSM/GPRS Siemens quad-band module and 20 channelsSiRF Star III GPS receiver; External GSM and GPS antennas; Built-in rechargeable battery (Li-Ion 860mAh); 2 digitalInputs (Positives) or programmableasAnalogs + 2 digitalInputs (Negatives) and Counters + 4 digitalOutputs (Negatives); Built-in 3D “G” Sensor.Complete and versatile unit, itsupports a largerangeofaccessories and functionalities.Easy to install, instantly locate and report your position by using GSM/GPRS devices or by web site.Suitable for logistic and high security level applications.Size: 115 x 73 x 32mm X-0 LITE:AVL unit with built-in GSM/GPRS Siemens quad-band module (or GSM/GPRS Simcom quad-band module) and 66 channels MTK GPS receiver; External GSM and GPS antennas + built-in GPS patch antenna; Built-in rechargeable battery (Li-Ion 860mAh); 4 digitalInputs (2 Positives and 2 Negatives) + 1 SOS Input (forPanicbuttononly) + 4 digitalOutputs (Negatives).The small size and the high reliability makes it easy to perform different and various applications.Easy to install, instantly locate and report your position by using GSM/GPRS devices or by web site.Suitable for logistic and high security level applications.Size: 60 x 77 x 26mm 6 X-TraX GPS & Software Solutions

  7. 3. Hardware solutions X-0 EASY X-0 GSM X-0 EASY:AVL unit with built-in GSM/GPRS Simcom quad-band module and 66 channels MTK GPS receiver; External GSM and GPS antennas; Built-in rechargeable battery (Li-Ion 860mAh); 4 digitalInputs (2 Positives and 2 Negatives) + 4 digitalOutputs (Negatives).The small size and the high reliability makes it easy to perform different and various applications.Easy to install, instantly locate and report your position by using GSM/GPRS devices or by web site.Suitable for logistic and security applications.Size: 60 x 77 x 26mm X-0 GSM:AVL unit with built-in GSM/GPRS Simcom quad-band module and withiut GPS receiver; External GSM antenna; Built-in rechargeable battery (Li-Ion 860mAh); 4 digitalInputs (2 Positives and 2 Negatives) + 4 digitalOutputs (Negatives).The small size and the high reliability makes it easy to perform different and various applications.Easy to install, instantly locate and report your position by using GSM/GPRS devices or by web site.Suitable for logistic and security applications.Size: 60 x 77 x 26mm X-2 TRAILER X-0 TRAILER X-2 TRAILER:Waterproof trailer tracker kit with built-in GSM/GPRS Siemens quad-band module and 20 channelsSiRF Star III GPS receiver; Internal GSM antenna; External GPS antenna; Built-in rechargeable battery (Li-Ion 10400mAh); 2 digitalInputs (Positives) or programmableasAnalogs + 2 digitalInputs (Negatives) and Counters + 4 digitalOutputs (Negatives); Built-in 3D “G” Sensor.Highly versatile kit suitablefordifferent and alsoparticularapplicationssuchastrailers, containers, boats, etc. Compact and strong waterproof housing (IP68). Easy to install, instantly locate and report your position by using GSM/GPRS devices or by web site.Suitable for logistic and high security level applications.Size: 190 x 115 x 50mm X-0 TRAILER:Waterproof trailer tracker kit built-in GSM/GPRS Siemens quad-band module (or GSM/GPRS Simcom quad-band module) and 66 channels MTK GPS receiver; Internal GSM antenna; Built-in GPS patch antenna; Built-in rechargeable battery (Li-Ion 10400mAh); 4 digitalInputs (2 Positives and 2 Negatives) + 4 digitalOutputs (Negatives).Highly versatile kit suitablefordifferent and alsoparticularapplicationssuchastrailers, containers, boats, etc. Compact and strong waterproof housing (IP68). Easy to install, instantly locate and report your position by using GSM/GPRS devices or by web site.Suitable for logistic and high security level applications.Size: 190 x 115 x 50mm 7 X-TraX GPS & Software Solutions

  8. 3. Hardware solutions XT-MDT 860 XT-MDT AVL UNITS ACCESSORIES: XT-VOX XT-MDT:Multi-function 4,3” touch-screen color LCD display withintegratednavigationsw and maps (optional).The already up-loaded touch-screen software is suitable to manage SOS report, Pin codes, Messages, Phone calls (personal Phone book) and street Navigation (optional). Moreover it can be totally customizable for different applications.It must be connected to the AVL unit by serial port and it’s completely configurable from remote by using Control Base Station software. XT-MDT 860:Multi-functionmonochrome LCD display forprofessionaluse.The already up-loaded software is suitable to manage SOS report, Pin codes, Messages and Phone calls (personal Phone book). Moreover it can be totally customizable for different applications. It doesn’t support the navigation software.It must be connected to the AVL unit by serial port and it’s completely configurable from remote by using Control Base Station software. XT-VOX: Hands free kit with speaker and high sensitive microphone. Useful for who want to manage the AVL unit built-in GSM phone for Voice calls. It must be connected directly to the AVL unit serial port.Size: 70 x 54 x 25mm XT-CAN 866 PLUS XT-PSYCO XT-RC XT-CAN 866 PLUS: Entry levelCanBus interface for multi brandvehicles.Itallowstoarm/disarm the system from the original key of the vehiclewithoutusinganyothertag. Italsodetectsanyunauthorizedintrusion.Veryquickinstallation and simpleusing.Itmustbeconnectedto the AVL unitbyphysicalInputs. XT-RC:Coded remote controlfor system arm/disarmfunction.Itprovidesalso a remote panicbutton and anauxiliarybuttonconfigurablefordifferentpurposes.Simpleusing and easy installation. Reducedsize and compact look.1 Receiver module + 2 Transmitters (battery included). XT-PSYCO: Encrypted transponder (active RFID solution) for driver remote identification and system arm/disarmfunctions.Quickinstallation and pocket size.Available in twoversions: XT-PSYCO 59 (standard version) and XT-PSYCO 67 (with “anti-grabber” technology).1 Receiver module + 2 Transmitters/Active Tags (battery included). 8 X-TraX GPS & Software Solutions

  9. 3. Hardware solutions XT-TEMP XT-RFID ZB XT-BARCODE XT-RFID ZB:Multi-fuction 2,4Ghz Radio transceiveraccessoryfor wireless sensors management.It’s possibletomanagedifferentsensors, at the sametime, using the sametransceiveraccessory, suchas wireless magneticcontactfordoorscontrol, wireless temperature sensor, wireless fleet/trailer ID sensor, coded transponder for driver ID recognizance. Eachactivesensorissuppliedwithinternal long life battery.It must be connected to the AVL unit by serial port and it’s completely configurable from remote by using Control Base Station software. XT-TEMP: Temperature detector kit with PT100 drill sensor.Professional and reliable solution for remote monitoring temperature.PT100 drill sensor diameter: 65mm XT-BARCODE: Opticalbarcode scanner. It’s suitable to read labels up to 8 cm width and from a distance of 5 cm max. As soon as the scanner read the coded label it will send the related sequence code number to the Control Base Station.It must be connected directly to the AVL unit serial port. …andmany more. 9 X-TraX GPS & Software Solutions

  10. 3. Hardware solutions X-TRACER X-WONDEX SHOWN ON TV PERSONAL TRACKERS: X-WONDEX: Personal tracker with built-in GSM/GPRS Simcom quad-band module and 20 channels SiRF Star III GPS receiver; Built-in GSM and GPS antennas; Built-in rechargeable battery (Li-Ion 1100mAh); Built-in speaker and microphone for Voice calls management; LCD display with back-light for messages management. For extended duration it’s also available with built-in Li-Ion 2200mAh rechargeable battery (X-WONDEX XL).The kit included an AC/DC travel battery charger, a car battery charger and a protection bag with belt strip.Powerful GPS, GSM/GPRS smart tracking device that is especially designed for personal remote positioning and emergency reporting (one panic button). It’s suitable for many applications such as human body or vehicle security, etc. Easy to use and to manage, instantly locate and report your position by using GSM/GPRS devices or by web site.Size: 79 x 51 x 26mm (X-WONDEX) / 79 x 51 x 31mm (X-WONDEX XL). X-TRACER: Personal tracker with built-in GSM/GPRS Simcom quad-band module and 66 channels MTK GPS receiver; Built-in GSM and GPS antennas; Built-in rechargeable battery (Li-Ion 1100mAh); Built-in microphone for Voice wiretapping. For extended duration it’s also available with built-in Li-Ion 2200mAh rechargeable battery (X-TRACER XL).The kit included an AC/DC travel battery charger, a car battery charger and a protection bag with belt strip.Slim and powerful GPS, GSM/GPRS smart tracking device that is designed for personal remote positioning and emergency reporting (one panic button). The compact size makes it easy to carry or hide the device to perform tracking.Easy to use and to manage, instantly locate and report your position by using GSM/GPRS devices or by web site. It doesn’t manage Voice calls (Voice wiretapping available only).Size: 82 x 44 x 18mm (X-TRACER) / 82 x 44 x 24mm (X-TRACER XL). 10 X-TraX GPS & Software Solutions

  11. 4. Software solutions 4. Software solutions Software solutions offered by X-TraX are: complete and professional platform for Control Base Stations 24 hours monitoring service (XT-FULL); web platform for final users self monitoring purposes (XT-WebTraX); MDT display software management (XT-MDTSW); customized and sophisticated applications based on GPS and GPRS technologies. XT-FULL: Professional and complete software platform for GPRS/GPS devices total management. It’s especially projected for 24hours Control Base Centers monitoring service that watch on final users vehicles under special contracts.The solution is composed of:. XT-Server/Front End software license (to be installed on your own local Server/PC).. MySql database structure protected by password – which contains all your customers devices . information and configurations (to be installed and configured on your own local Server/PC).. XT-Client software license – for AVL units and Personal Trackers 24hours monitoring and . management services (to be installed on your own local Client PC). XT-Client software is already . predisposed to manage MS MapPoint 2002-2004-2006 editions (that must be installed on your . local Client PC), Google Maps and MS Virtual Earth maps (by internet connection) - Please note . that maps licenses are not included.. GSM/GPRS external modem (DB9 Serial connection) for SMS and Data channels management (to . be connected on your own local Server/PC).. No vehicle limit management and no expiring license date.. This system is an “open platform”. This means that we can develop for you any extra . implementation or customization as your requirements (e.g. add how many Clients you want – . by network connection, provide you the XT-Client solution based on your local language, etc.). 11 X-TraX GPS & Software Solutions

  12. 4. Software solutions XT-Client: Main view 12 X-TraX GPS & Software Solutions

  13. 4. Software solutions XT-Client: Configuration panel 13 X-TraX GPS & Software Solutions

  14. 4. Software solutions 14 X-TraX GPS & Software Solutions

  15. 4. Software solutions XT-Client: History selection panel 15 X-TraX GPS & Software Solutions

  16. 4. Software solutions XT-Client: History report 16 X-TraX GPS & Software Solutions

  17. 4. Software solutions XT-Client: History trip shown on map 17 X-TraX GPS & Software Solutions

  18. 4. Software solutions XT-WEBTRAX: Logistic web site for final users self monitoring purposes. It’s an additional solution that works based on the over mentioned XT-FULL platform using the same data information sources available from your MySQL database. Every setting is manageable by the XT-Client dedicated panel from your local PC.The XT-WebTraX solution is composed of:. Complete PHP web site structure linked to the Control Base Center’s MySql database (XT-. FULL). Especially projected for logistic self monitoring purposes (to be installed on your own . local Server/PC). Is it also possible to customize the XT-WebTraX web site with your own . company brand name and logo, hiding any X-TraX references from the screen. The system is . predisposed to manage Google Maps.. Each final user is able to login on his private area by using a pre-defined ‘User name’ and . ‘Password’ which is previously configured from the Control Base Center’s administrator (by . XT-Client panel). Each final user can self monitor and manage only his own Group/Fleet.. From the XT-WebTraX web site the final user can manage the following functions: - GPS device real time localization (by GPRS); - see on map the trip of each single unit (by period/date ‘from’ > ‘to’) and view/print it as - detailed report (by period/date ‘from’ > ‘to’ and by filtering pre-defined Events); - monitoring all the entire Group/Fleet vehicles at the same time on the map screen - (automatically refreshing the position every 60 seconds); - check the currently physical Input & Output states and check for all the rest of data sent - from the GPS device (Speed, Coordinates, Heading, Altitude, Date/Time, Number of - available Satellites); - receiving/sending free Text Messages (by GPRS) from/to MDT displays which are installed - on board. 18 X-TraX GPS & Software Solutions

  19. 4. Software solutions . Is it possible to define how each final user has to manage the web service you are offering: - or ‘Pay per mode’ profile (the final user has to pay for any single operation he wants to - manage by web site). The XT-WebTraX administrator has to previously define a tariff for - any single operation that final user can manage on web site (by XT-Client panel); - or ‘No-limits mode’ profile (the final user has to pay you only a monthly or a yearly - contract and then he will be free to manage all the possible operations on web site). The - XT-WebTraX administrator has to previously pair this profile to the related final user (by - XT-Client panel).. This system is customizable as your requirements (e.g. put your own company brand name . and logo, provide you the solution based on your local language, etc.). Note: Our software is tested based on Windows 2000, Windows XP Professional and Windows Vista operating systems (Italian and English versions). Using other operating systems we can’t guarantee the good performance because of different software components for each platform. www.xtrax.it 19 X-TraX GPS & Software Solutions

  20. 4. Software solutions XT-WebTraX: General view – Single vehicle management 20 X-TraX GPS & Software Solutions

  21. 4. Software solutions XT-WebTraX: General view – Fleet management 21 X-TraX GPS & Software Solutions

  22. 4. Software solutions XT-WebTraX: Text messages management XT-WebTraX: Text messagessendingby GPRS (onlytounitsequippedwith MDT display accessory): 22 X-TraX GPS & Software Solutions

  23. 4. Software solutions XT-WebTraX: History management XT-WebTraX: History trip shown on mapfor single vehicle 23 X-TraX GPS & Software Solutions

  24. 4. Software solutions XT-WebTraX: History report (printable version) 24 X-TraX GPS & Software Solutions

  25. 4. Software solutions XT-WebTraX: Search function management 25 X-TraX GPS & Software Solutions

  26. 4. Software solutions XT-MDTSW: MDT software for users display management.The default XT-MDTSW software release can manage the following functions:. Diagnostic function (useful for the installer in order to self check if the system is working fine).. Pin Code management (for driver identification purpose, etc.) – In substitution of any remote . control or RFID device.. Text Messages management (for instantaneously sending/receiving free Text Messages or pre-. defined short Text Messages from/to XT-Client or XT-WebTraX platforms by GPRS channel).. Phone calls management (for managing incoming outgoing calls. Is it also possible to hide the . Phone keypad from the screen leaving available only a pre-defined Phone book) - Please note . that in order to manage this function the hands free kit is required.. Panic button (Panic button displayed on the main screen and useful in case of emergency).. XT-MDTSW is totally customizable as your requirements (e.g. put your own company brand . name and logo, complete translation in your local language, special developments for specific .applications, etc.).Note: Each XT-MDTSW is protected by activation license code which is provided from X-TraX. Each activation license works on the related MDT device only. 26 X-TraX GPS & Software Solutions

  27. 4. Soluzioni software XT-MDTSW: Main Menu & SOS Button XT-MDTSW: Pin Codes Menu XT-MDTSW: Diagnostic Menu > > 27 X-TraX GPS & Software Solutions

  28. 4. Soluzioni software XT-MDTSW: Phone & Phone Book Menu or > XT-MDTSW: Messages Menu > > 28 X-TraX GPS & Software Solutions

  29. 4. Software solutions CUSTOMIZED APPLICATIONS: X-TraX offer you the possibility to develop customized and sophisticated applications based on GPS and GPRS technologies as your need. 29 X-TraX GPS & Software Solutions

  30. 5. Applications 5. Applications GPS technology together with GPRS channel communication allowed to operate in different applications having the maximum flexibility and performance at the same time. Thanks to its qualified experience in developing special applications X-TraX can satisfy different requests coming from main fields.RESCUE AND MEDICALS APPLICATIONS:Medical is one of the most sensitive fields where high level professionality is needed in order to guarantee a quick and reliable service to people who needs help. In this case technology can help to optimize rescue services. 30 X-TraX GPS & Software Solutions

  31. 5. Applications TRANSPORTATION APPLICATIONS:Transportation is the most increasing field and it requests some of the most interesting and complete applications available on the market, such as Logistic fleet management (track & tracing, fuel consumption control, shipment monitoring, etc.) and Security service (advanced anti-theft system, 24 hours monitoring system, etc.). JOB APPLICATIONS:Because of different and various job, customizable and flexible applications are a must in order to have success in this field. Especially in this case X-TraX could help you to develop specific applications according to final users requirements, giving you the possibility to offer high level solutions that are difficult to find out on the market. 31 X-TraX GPS & Software Solutions

  32. 5. Applications THE RIGHT SYSTEM FOR YOUR APPLICATION: BICYCLESAdvised personal trackers:- X-TRACER- X-TRACER XL- X-WONDEX- X-WONDEX XL MOTORCYCLESAdvisedunits:- X-0 EASY- X-0 LITEAdvisedaccessories:- XT-WPCASE X0 Waterproof casingfor X-0 unit- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder(*) Suitablefor X-0 LITE unitonly CARSAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder - XT-CAN 866 PLUS Entry evelCanBus system(*) Suitablefor X-0 LITE and X-2 unitsonly CROSS-COUNTRY VEHICLESAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder - XT-CAN 866 PLUS Entry levelCanBus system(*) Suitablefor X-0 LITE and X-2 unitsonly VANSAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder - XT-VOX (**) Hands free kit- XT-MDT (**) Multi-function display(*) Suitablefor X-0 LITE and X-2 unitsonly(**) Suitablefor X-2 unitonly TRUCKSAdvisedunits:- X-0 LITE- X-2Advisedaccessories: - XT-RC Coded remote control- XT-PSYCO Encrypted transponder - XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensors management - XT-VOX (*) Hands free kit- XT-MDT (*) Multi-function display (*) Suitablefor X-2 unitonly 32 X-TraX GPS & Software Solutions

  33. 5. Applications TRUCK TRAILERSAdvisedunits:- X-0 TRAILER- X-2 TRAILERAdvisedaccessories: - XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensorsmanagement(*) Suitablefor X-2 TRAILER unitonly FRIGO TRAILERSAdvisedunits:- X-0 TRAILER- X-2 TRAILERAdvisedaccessories: - XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensors management - XT-TEMP (*) Temperature sensor(*) Suitablefor X-2 TRAILER unitonly CONTAINERSAdvisedunits:- X-0 TRAILER- X-2 TRAILERAdvisedaccessories: - XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensorsmanagement(*) Suitablefor X-2 TRAILER unitonly MOTOR HOMESAdvisedunits:- X-0 LITE- X-2Advisedaccessories: - XT-RC Coded remote control- XT-PSYCO Encrypted transponder - XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensors management - XT-VOX (*) Hands free kit- XT-MDT (*) Multi-function display(*) Suitablefor X-2 unitonly CARAVANSAdvisedunits:- X-0 TRAILER- X-2 TRAILERAdvisedaccessories: - XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensors management(*) Suitablefor X-2 TRAILER unitonly BOATSAdvisedunits:- X-0 TRAILER- X-2 TRAILERAdvisedaccessories: - XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensors management(*) Suitablefor X-2 TRAILER unitonly 33 X-TraX GPS & Software Solutions

  34. 5. Applications SCRAPERSAdvisedunits:- X-0 LITE- X-0 TRAILER- X-2Advisedaccessories: - XT-WPCASE Unit waterproof casing- XT-RC Coded remote control- XT-PSYCO Encrypted transponder- XT-MDT (*) Multi-function display(*) Suitablefor X-2 unitonly EXCAVATORSAdvisedunits:- X-0 LITE- X-0 TRAILER- X-2Advisedaccessories: - XT-WPCASE Unit waterproof casing- XT-RC Coded remote control- XT-PSYCO Encrypted transponder- XT-MDT (*) Multi-function display(*) Suitablefor X-2 unitonly ELEVATORSAdvisedunits:- X-0 EASY- X-0 LITEAdvisedaccessories: - XT-WPCASE Unit waterproof casing- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder(*) Suitablefor X-0 LITE unitonly TRACTORSAdvisedunits:- X-0 LITE- X-0 TRAILER- X-2Advisedaccessories: - XT-WPCASE Unit waterproof casing- XT-RC Coded remote control- XT-PSYCO Encrypted transponder- XT-MDT (*) Multi-function display(*) Suitablefor X-2 unitonly HARVESTERS & THRESHING MACHINESAdvisedunits:- X-0 LITE- X-0 TRAILER- X-2Advisedaccessories: - XT-WPCASE Unit waterproof casing- XT-RC Coded remote control- XT-PSYCO Encrypted transponder- XT-MDT (*) Multi-function display(*) Suitablefor X-2 unitonly LAWNMOWERSAdvisedunits:- X-0 EASY- X-0 LITEAdvisedaccessories: - XT-WPCASE Unit waterproof casing- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder(*) Suitablefor X-0 LITE unitonly 34 X-TraX GPS & Software Solutions

  35. 5. Applications AMBULANCESAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder- XT-MDT (**) Multi-function display(*) Suitablefor X-0 LITE and X-2 unitsonly(**) Suitablefor X-2 unitonly HELICOPTERSAdvisedunits:- X-0 EASY- X-0 LITEAdvisedaccessories: - XT-WPCASE Unit waterproof casing- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder(*) Suitablefor X-0 LITE unitonly TAXIAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder - XT-VOX (**) Hands free kit- XT-MDT (**) Multi-function display(*) Suitablefor X-0 LITE and X-2 unitsonly(**) Suitablefor X-2 unitonly BUSESAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder- XT-MDT (**) Multi-function display(*) Suitablefor X-0 LITE and X-2 unitsonly(**) Suitablefor X-2 unitonly TRAINSAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder- XT-MDT (**) Multi-function display(*) Suitablefor X-0 LITE and X-2 unitsonly(**) Suitablefor X-2 unitonly TRAMSAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder- XT-MDT (**) Multi-function display(*) Suitablefor X-0 LITE and X-2 unitsonly(**) Suitablefor X-2 unitonly 35 X-TraX GPS & Software Solutions

  36. 5. Applications SECURITY VANSAdvisedunits:- X-2- X-8Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder- XT-VOX Hands free kit- XT-MDT Multi-function display(*) Suitablefor X-2 unitonly ANIMAL TRANSPORTAdvisedunits:- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO Encrypted transponder- XT-RFID ZB (*) Multi-fuctiontransceiveraccessoryfor wireless sensors management- XT-VOX (*) Hands free kit- XT-MDT (*) Multi-function display- XT-TEMP (*) Temperature sensor(*) Suitablefor X-2 unitonly TRASH TRANSPORTAdvisedunits:- X-0 EASY- X-0 LITE- X-2Advisedaccessories:- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder- XT-RFID ZB (**) Multi-fuctiontransceiveraccessoryfor wireless sensors management- XT-MDT (**) Multi-function display(*) Suitablefor X-0 LITE and X-2 unitsonly(**) Suitablefor X-2 unitonly SNOWMOBILESAdvisedunits:- X-0 EASY- X-0 LITEAdvisedaccessories:- XT-WPCASE X0 Waterproof casingfor X-0 unit- XT-RC Coded remote control- XT-PSYCO (*) Encrypted transponder(*) Suitablefor X-0 LITE unitonly VENDING & CASH MACHINESAdvisedunits:- X-0 GSM- X-2 EASY- X-0 LITEAdvisedaccessories: - XT-RC Coded remote control- XT-PSYCO (*) Ecrypted transponder (*) Suitablefor X-0 GSM and X-0 LITE unitsonly SLOT MACHINESAdvisedunits:- X-0 GSM- X-2 EASY- X-0 LITEAdvisedaccessories: - XT-RC Coded remote control- XT-PSYCO (*) Ecrypted transponder (*) Suitablefor X-0 GSM and X-0 LITE unitsonly 36 X-TraX GPS & Software Solutions

  37. 5. Applications PARCELSAdvised personal trackers:- X-TRACER- X-TRACER XL- X-WONDEX- X-WONDEX XL PETSAdvised personal trackers:- X-TRACER- X-TRACER XL- X-WONDEX- X-WONDEX XL ANTI-KIDNAPAdvised personal trackers:- X-TRACER- X-TRACER XL- X-WONDEX- X-WONDEX XL JOB SECURITYAdvised personal trackers:- X-TRACER- X-TRACER XL- X-WONDEX- X-WONDEX XL PERSONAL SECURITYAdvised personal trackers:- X-TRACER- X-TRACER XL- X-WONDEX- X-WONDEX XL RESCUE (SOS)Advised personal trackers:- X-TRACER- X-TRACER XL- X-WONDEX- X-WONDEX XL …andmany more applications. 37 X-TraX GPS & Software Solutions

  38. 6. Certifications and approvals 6. Certifications and approvals Products offered by X-TraX are fully certificated in accordance with the following International Conformities and Compliances: RoHSCompliance (2002/96/CE)FCC Conformity (FederalCommunicationsCommission)CE Conformity Moreovertheyobtained the belowApprovals and Conformities: 95/54/CE Conformity (electromagnetic compatibility directive for electronic devices used in automotive environment) 99/5/CE R&TTE Conformity (Radio equipment and telecommunications terminal equipment) 38 X-TraX GPS & Software Solutions

  39. 39 X-TraX GPS & Software Solutions

  40. X-TraX s.n.c. Via Bosisio Orlando, 16 - 22035 Canzo(CO) - ITALYTel. +39.031.6121375 / Fax +39.031.681557Mail: info@xtrax.it / Web: www.xtrax.it X-TraX: GPS Security & Tracking System_Presentazione (01/2010_rev.03_UK) X-TraX GPS & Software Solutions
