Proving that a Quadrilateral is a Parallelogram

Proving that a Quadrilateral is a Parallelogram. Lesson 5.6. 1. If both pairs of opposite sides of a quadrilateral are parallel, then the quadrilateral is a parallelogram (reverse of the definition).

luke
Télécharger la présentation

Proving that a Quadrilateral is a Parallelogram

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Proving that a Quadrilateral is a Parallelogram Lesson 5.6

  2. 1. If both pairs of opposite sides of a quadrilateral are parallel, then the quadrilateral is a parallelogram (reverse of the definition). 2. If both pairs of opposite sides of a quadrilateral are congruent, then the quadrilateral is a parallelogram (converse of a property). 3. If one pair of opposite sides of a quadrilateral are both parallel and congruent, then the quadrilateral is a parallelogram.

  3. 4. If the diagonals of a quadrilateral bisect each other, then the quadrilateral is a parallelogram (converse of a property). 5. If both pairs of opposite angles of a quadrilateral are congruent, then the quadrilateral is a parallelogram (converse of a property).

  4. ACDF is a . A D AF  DC AFB  ECD ΔAFB  ΔDCE FB  EC AB  ED AC  FD BC  FE FBCE is a . Given Opposite s of a are . Opposite sides of a are . Given ASA (2,3,4) CPCTC CPCTC Same as 3 Subtraction property. If both pairs of opposite sides of a quadrilateral are , it is a .

  5. In order for QUAD to be a parallelogram, opposite angles have to be congruent. Q = 3x(x2 – 5x) = 3x3 – 15x2 A = 3x3 – 15x2 Therefore, Q & A are congruent. U = (x2)5 = x10 D = x10 Therefore, U & D are congruent. With opposite angles congruent, QUAD is a parallelogram.
