  1. Feedback theorem Op amp example Buck voltage regulator example

  2. Results

  3. ExampleOp amp PD compensator circuit R1 = 1.6 kΩ R2 = 16 Ω R3 = 1.6 kΩ C = 0.1 µF Op amp model Ro = 50 Ω Gop(s) = Goo/(1+s/w1) Goo = 105 f1 = 10 Hz

  4. Buck voltage regulator example
