  1. BIS, SMP & PcInterlockSoftware activities during LS1 Maxime Audrain On behalf of the MS-Software team: Arkadiusz, Jacek, Jean-Christophe and Kajetan. MPE workshop for LS1 - maudrain@cern.ch

  2. Menu • Overview • BIS & SMP activities • PcInterlock activities MPE workshop for LS1 - maudrain@cern.ch

  3. Overview (1/3) • Description of the activity: • Software developments for the BIS, SMP and PcInterlock during LS1. It involves follow-up of the Hardware upgrades and implementation of new requirements from operators and experts. • Why during LS1: • Mostly to be able to monitor the systems correctly when the machines restart at the end of LS1. • Risks and impacts if not done during LS1: • Unable to properly monitor and diagnose protection systems. MPE workshop for LS1 - maudrain@cern.ch

  4. Overview (2/3) • Activity time estimation: • Around 200story points for BIS, SMP and common components • Around 65 story points for the PcInterlock • Activities does not depend on the LS1 general schedule. • Manpower: • Internal man power, Software coordination team (around 5 persons) • Potential missing resources has to be identified • In MPE : Support from MPE/EP for specifications, milestones and HW deployments (Stephane). MPE workshop for LS1 - maudrain@cern.ch

  5. Overview (3/3) • Contributions from the other groups: • DIAMON monitoring, Sequencer task deployment, PM modules deployments from BE/CO • Andrea Moscatelli (SPS operator) for developments on the BIS project • No potential issues are identified (if follow-up is performed). • Safety measures: • Not relevant • Potential showstoppers: • Same office as Arek! (time is shared between projects) MPE workshop for LS1 - maudrain@cern.ch

  6. BIS & SMP architecture overview Presentation layer BIS GUI Logging DB … other clients … SMP GUI QPS PowerCycle tool Common functionalities Retrieve needed information and/or send commands BIS & SMP server : Decode data from the FESA class and process it. Publish it for clients Configuration DB Retrieve critical parameters for systems Subscribe and send requested commands BIS & SMP FESA classes : (Linux compatibles) FESA 3 prototype CISV MPE Generic FESA class: - Contains getter for all registers + History Buffers. - Contains generic needs for all FESA classes.. CIBG CISX CIBM Provide board specific properties (like operator parameter settings) inherit

  7. Common Software • Common GUI Components + Software components for board communications • General server infrastructure for BIS/SMP monitoring services • Generic FESA class design if FESA 3 provides Object features. MPE workshop for LS1 - maudrain@cern.ch

  8. BIS activities before LS1 • Follow-up of BICs deployment on the Linac 4 + Transfer line + Booster : • Deploy CIBM FESA class (Linux compatible) • Allow monitoring from the Linac 4 BIS supervision. MPE workshop for LS1 - maudrain@cern.ch

  9. BIS activities during LS1 • Deploy CIBM FESA class to all front-ends. Redefine the CIBG FESA class under Linux • Generic server specialization for identified clients : BIS GUI, SMP GUI, logging DB, QPS power-cycle tool,… • New GUI that fits operator and expert needs, with different views depending on the accelerator timing domains • Adaptation of the Pre-Current-Post operational checks • BIS 2 specificities to be foreseen during GUI re-definition. MPE workshop for LS1 - maudrain@cern.ch

  10. SMP • Modify SMP FESA classes for CISX and CISV boards to work under Linux controller. • Plug the GUI to the BIS&SMP server (Could be done after LS1). MPE workshop for LS1 - maudrain@cern.ch

  11. PcInterlock • Improve analysis functionalities. • Extends the interlocking to other Power Converters. • Log interlocking decisions. • Reinforce RBAC protection. MPE workshop for LS1 - maudrain@cern.ch

  12. Summary • 190 story points to be done during LS1 : ~54 % of total capacity. • Complete redesign of the BIS supervision for Operators and Experts. • A server to publish and log information from BIS & SMP. • Abstract software design for BIS & SMP. • Improvements to make the PC Interlock more flexible. MPE workshop for LS1 - maudrain@cern.ch

  13. Fin • Thank you for your attention • Do you have any questions ? MPE workshop for LS1 - maudrain@cern.ch
