  1. TLS MODELLING OF ANISOTROPY IN MACROMOLECULAR REFINEMENT Martyn Winn CCP4, Daresbury Laboratory, U.K. York, April 11th 2002

  2. Aims • Mean square atomic displacements (static and dynamic) are an important part of model of protein. • Atomic displacements are likely anisotropic, but rarely have luxury of refining individual anisotropic Us. Instead isotropic Bs. • Intermediate descriptions??

  3. Contributions to atomic U U = Ucrystal + UTLS + Uinternal + Uatom Ucrystal : overall anisotropic scale factor w.r.t. crystal axes. UTLS : rigid body displacements e.g. of molecules, domains, secondary structure elements, side groups, etc. Uinternal : internal displacements of molecules, e.g. normal modes of vibration, torsions, etc. Uatom : anisotropy of individual atoms

  4. Rigid body model

  5. General displacement of atom (position r w.r.t. origin O) in rigid body: u = t + D.r For small libration : u t +   r Rigid body motion

  6. TLS parameters • Corresponding dyad: uu = tt + t r - rt - r  r • Average over dynamic motion and static disorder gives atomic anisotropic displacement parameter (ADP): UTLS  <uu> = T + ST r - r S - r L r • T,L andS describe mean square translation and libration of rigid body and their correlation. • T  6 parameters, L  6 parameters, S  8 parameters

  7. Use of TLS UTLS  <uu> = T + ST r - r S - r L r • Given refined U’s, fit TLS parameters - analysis • Use TLS as refinement parameters TLS  U’s  structure factor - refinement

  8. TLS in refinement • TLS parameters are contribution to displacement parameters of model • Can specify 1 or more TLS groups to describe contents of asymmetric unit (or part thereof) • 6 + 6 + 8 = 20 parameters per group (trace of S is undetermined) • Number of extra refinement parameters depends on how many groups used!

  9. At what resolution can I use TLS? • Resolution < 1.2 Å - full anisotropic refinement • Resolution ~ 1.5 Å - marginal for full anisotropic refinement. But can do detailed TLS, e.g. Howlin et al, Ribonuclease A, 1.45 Å, 45 side chain groups; Harris et al, papain, 1.6Å, 69 side chain groups. • Resolution 1.5 Å - 2.5 Å model molecules/domains rather than side chains. • Sandalova et al 2001 - thioredoxin reductase at 3.0 Å - TLS group for each of 6 monomers in asu

  10. Implementation in REFMAC Suggested procedure: • Choose TLS groups (currently via TLSIN file). • Use anisotropic scaling. • Set B values to constant value. • Refine TLS parameters (and scaling parameters) against ML residual. • Refine coordinates and residual B factors.

  11. NCS • Different molecules in asymmetric unit may have different overall thermal parameters. • Refine independent overall TLS tensors for each molecule. • REFMAC can then apply NCS restraints to residual B values of NCS-related molecules.

  12. TLSIN TLS Chain O NAD binding RANGE 'O 1.' 'O 137.' ALL RANGE 'O 303.' 'O 340.' ALL TLS Chain O Catalytic RANGE 'O 138.' 'O 302.' ALL TLS Chain Q NAD binding RANGE 'Q 1.' 'Q 137.' ALL RANGE 'Q 303.' 'Q 340.' ALL TLS Chain Q Catalytic RANGE 'Q 138.' 'Q 302.' ALL

  13. Choice of TLS groups • chemical knowledge, e.g. aromatic side groups of amino acids, secondary structure elements, domains, molecules • best fit of TLS to ADPs of test structure, e.g. Holbrook & Kim (1984); rigid-body criterion applied to ADPs, e.g. Schneider (1996) • dynamic domains identified from multiple configurations, e.g. more than one crystal form (DYNDOM), difference distance matrices (ESCET), MD simulations.

  14. TLS - refmac5 interface • Select TLS & restrained refinement at top of interface • Specify TLS in and TLS out files. • TLS Parameters folder: • Number of cycles, e.g. 20 • Fix Bfactors to e.g. 20 (value not crucial, but option is recommended)

  15. What to look for in output • Usual refinement statistics. • Check R_free and TLS parameters in log file for convergence. • Check TLS parameters to see if any dominant displacements. • Pass XYZOUT and TLSOUT through TLSANL for analysis • Consider alternative choices of TLS groups

  16. TLSOUT TLS Chain O NAD binding RANGE 'O 1.' 'O 137.' ALL RANGE 'O 303.' 'O 340.' ALL ORIGIN 94.142 6.943 75.932 T 0.5200 0.5278 0.5031 -0.0049 -0.0040 0.0081 L 0.11 0.08 0.04 -0.03 0.02 0.06 S -0.014 0.020 0.002 0.022 0.000 -0.016 -0.005 0.022 . . .

  17. Equivalent isotropic B factors • TLS tensors  UTLS for atoms in group. • UTLS BTLS and anisotropy A • Also have individually refined Bres • Hence, BTOT = BTLS + Bres

  18. Running TLSANL XYZIN: output coordinates from refmac with residual B factors (BRESID keyword) TLSIN: output TLS parameters from refmac TLSIN: ANISOU records including TLS and residual B contributions ATOM records containing choice of B (ISOOUT keyword) AXES: If AXES keyword set, file of principal axes in molscript format

  19. Output of TLSANL Origins (T and S, but not L, origin-dependent): • Origin of calculation • Centre of Reaction Axial systems for each tensor: • orthogonal • librational “Simplest” description: 3 non-intersecting screw axes + 3 reduced translations

  20. Displaying derived ADPs ORTEP: http://www.ornl.gov/ortep/ortep.html Mapview: http://www.chem.gla.ac.uk/~paule/chart/ xtalview: http://www.scripps.edu/pub/dem-web/toc.html Rastep in RASTER3D : using the script: grep NAD file.pdb | rastep -auto -Bcol 5. 35. > ellipsoids.r3d render -jpeg < ellipsoids.r3d > ellipsoids.jpeg Xfit: http://www.ansto.gov.au/natfac/asrp7_xfit.html povscript: http://people.brandeis.edu/~fenn/povscript

  21. 11 a.a. (8% of TLS group) 30% probability level

  22. Ex. 1 - mannitol dehydrogenase Hörer et al., J.Biol.Chem.276, 27555 (2001) 1.5 Å data 3 tetramers in a.s.u. TLS refinement with 1 group per monomer Free-R 23.6%  20.9% Tetramer B’s before TLS B’s after TLS crystal contacts ABCD 27.1 13.3 38 EFGH 18.0 13.3 50 IJKL 18.6 13.3 49

  23. Ex. 2 - light harvesting complex Complex is nonamer. Each monomer contains:  peptide  peptide 2 x B850 bacteriochlorophyll 1 x B800 bacteriochlorophyll 2 x carotenoids Crystallographic asu = 3 monomers

  25. TLS models a) 1 group for a.s.u. (20 parameters) b) 1 group per NCS unit (3 x 20 pars) c) 1 group per molecule (18 x 20 pars) d) 3 groups per peptide + 1 group per pigment (total 30 x 20 parameters)

  26. Ex. 3 - peptide-MHC complexes Markus Rudolph Class I peptide-MHC complexes (1.7 Å – 1.9 Å) Alpha chain – 1 or 2 TLS groups Beta chain – 1 TLS group Bound peptide – 1 TLS group Free R decrease 22.3 to 21.1 in best case. Eigenvalues of L for peptide: 64.7 0.9 -4.1

  27. Example 4 - GAPDH • Glyceraldehyde-3-phosphate dehydrogenase from Sulfolobus solfataricus (M.N.Isupov et al, JMB, 291, 651 (1999)) • 340 amino acids • 2 chains in asymmetric unit (O and Q), each molecule has NAD-binding and catalytic domains. • P41212, data to 2.05Å

  28. GAPDH: R factors Model TLS groups R factorRfree 1023.8 30.4 2 1* 25.1 29.4 3 1 21.4 25.9 4 2 21.2 26.2 5 4 21.1 25.8 * B factors constant at 20 Å2

  29. TLS values - 1 TLS group Eigenvalues of reduced translation tensor: 0.267 Å2 0.112 Å2 –0.005 Å2 Eigenvalues and pitches of screw axes: 1.403 ()2 0.888Å 1.014 ()2 1.472Å 0.204 ()2 1.214Å

  30. Screw axes - 1 TLS group

  31. Contributions to equivalent isotropic B factor

  32. B’s from NCS-related chains

  33. Correlations between NCS-related B's Model TLS groups R factorRfree CorrCoeff 1023.8 30.4 0.537 2 1* 25.1 29.4 - 3 1 21.4 25.9 0.752 4 2 21.2 26.2 0.812 5 4 21.1 25.8 0.821 CorrCoeff - mean correlation coefficient between (residual) B factors of NCS-related chains

  34. Application of NCS restraints Model TLS groups NCSR factorRfree CorrCoeff 10no 23.8 30.4 0.537 6 0 yes 25.0 30.3 0.989 5 4 no 21.1 25.8 0.821 7 4 yes 22.0 25.7 0.999 NCS - whether NCS restraints applied

  35. Example 5: GerE • transcription regulator from Bacillus subtilis (Ducros et al). • 74 amino acids • six chains A-F in asymmetric unit • C2, data to 2.05Å

  36. GerE

  37. GerE: R factors ModelTLS groups R factorRfree 1 0 21.9 29.3 2 6 21.3 27.1

  38. Contributions to equivalent isotropic B factor

  39. B’s from NCS-related chains

  40. GerE: NCS ModelTLS groups NCSR factorRfree CorrCoeff 1 0 no 21.9 29.3 0.519 3 0 yes 22.5 30.0 0.553 2 6 no 21.3 27.1 0.510 4 6 yes 21.4 27.2 0.816 NCS - whether NCS restraints applied CorrCoeff - mean correlation coefficient between (residual) B factors of NCS-related chains

  41. Choice of TLS groups 6 groups - each group split between 2 chains (for illustration only!) ModelTLS groups R factorRfree 1 0 22.5 30.0 2 6 21.4 27.2 5 6 22.2 28.6

  42. Choice of TLS groups

  43. Choice of TLS groups

  44. Inclusion of bound waters 6 TLS groups, with some waters included, Waters R factorRfree None 21.4 27.2 1 shell, cutoff 2.8 21.5 27.4 1 shell, cutoff 3.2 21.5 27.2 2 shell, cutoff 3.2 21.6 27.2

  45. Acknowledgements • BBSRC (CCP4 grant) • Garib Murshudov • Miroslav Papiz (LH2) • Stefan Hörer (mannitol dehydrogenase) • Markus Rudolph (MHC) • Misha Isupov (GAPDH) • Valerie Ducros, Jim Brannigan, Tony Wilkinson (GerE)
