  1. Madison Wire (Europe) ltd. Madison House – Davyfield Road Roman Road Industrial Estate Blackburn – Lancashire BB1 2LU England

  2. Welcome to Madison World

  3. Madison Wire (Europe) Ltd was formed in 1992 operating from a 6,000 square feet building in Nelson, Lancashire. Within 3 years, the rapid success of the company necessitated the move to our present location in Blackburn, Lancashire. A purposely designed factory totalling 28,000 sq. ft. Situated adjacent to junction 5 on the M65 allows for easy access to the UK motorway network.

  4. 2 x 210 ft (67m) steam c.v. lines with 2 coolers(enable to produce up to 3 km per hour) • steam hi-pressure boiler

  5. MWEL use 2 John Royle 15-1 CV extruders, coupled with up to 70 meters of high-pressure steam and water pipes. This enables us to produce cable up to 15mm diameter in all types of elastermeric compounds as well as silicone. Both lines are fully automated to ensure optimum quality and diameter control.

  6. The steam curing process enables maximum bonding / lock down between insulation, with or without reinforcing branding / minimizing sheath tear and maximizing terminal retention. Thus guaranteeing high Newton scale pull off strengths that cannot be achieved by any other curing process.

  7. silicone line(enable to produce 1500 m per hour) • printing line(enable to print 15 m per minute)

  8. 11 braiders(enable to braid 11 m per minute)

  9. 18 presses and applicators • 3 cutting strip machines

  10. 8 booting machines(MWEL is enable to make up to 300 sets per hour) • 3 prefeeders

  11. high voltage test equipment • flame test equipment • pull test equipment • hardness tester

  12. As a recognised cable manufacturer and supplier of insulators and terminals to the automotive industry, we predominantly supply reels of ignition cable and components to the worldwide assembly market. Our customers then assemble the products into finished HT leads supplying the OEM and aftermarket. Being experts in all three product groups enables us to offer an efficient service and technical expertise"

  13. Specialising in the manufacture of HT cable and HT lead components. Madison Wire (Europe) Ltd is able to supply all diameters of SILICONE, EVA, EPS, CPE and EPDM HT cable in all colours. The cable can be produced braided or un-braided with Kevlar or silicone sleeved resistor/suppression, wire-wound, reactive and copper conductors. All cable can be supplied printed to customer requirements.

  14. warehouse equipment - forklift, pallet trucks, containers unloading platform

  15. The most precious Madison`s assets: experienced and dependable people (engineers, hi-class specialists)

  16. With the ability to produce all types of HT cable and supply the most extensive range of components, MWEL delivers to the automotive industry globally. MWEL is the specialist supplier to the highly technical OE & aftermarket manufacturers in Europe and Asia. Our extensive range and stock facilities eliminates the need to source from numerous suppliers. Our unprecedented quality system, backed by ISO 9002, has ensured approval from large and niche car manufacturers. Having recruited experienced personnel from the aviation industry, MWEL have recently introduced a range of airfield lighting cables which has already been approved and installed at various UK and overseas airports.

  17. Directions of Madison export Blackburn - England

  18. Good bye and see you again in Madison`s World! Please feel free to contact us: Davyfield Road Roman Road Industrial Estate Blackburn Lancashire BB1 2LU England E-mail : sales@madison-wire.co.uk Web: www.madison-wire.co.uk Tel: +44 (0)1254 663555 Fax: +44 (0)1254 663222
