Windows Desktop Security

3. Windows Desktop Security  Assign a good & difficult administrator password.  Don’t ever enable the password remember option.  If a machine is cracked/lost, change all passwords.  Use & update Anti-virus s/w (e.g. AVG) regularly  Set up automatic updating on a regular basis  Schedule Virus Scans automatically.  Use Good spy removal software  Microsoft antispy or Spybot destroyer  Take the backup of Registry. Run regedit  Control Panel   Add / Rem S/w   remove  my Search Bar, Date manager  weather tool, Bonzy Buddy etc,

4. Windows Desktop Security  Keep OS up to date  Visit http://windowsupdate.microsoft.com regularly  Start  Settings  Control Panel  Automatic Updates  Install & run 'Critical Update Notification' patch.  Automatically checks and notifies about patches.  Keep your applications updated:  Update Web browsers and word processing applns.  Decide if the upgrade is appropriate for your h/w.  Backup your files:  Have critical files on any machine which is backed up.  Back up the entire system on a regular basis.

5. WDS - Risk of File Sharing  Reduce sharing files thru floppies.  Don’t open doubtful (.scr,.pif,.exe) attachments in mails.  Accessing a file over a n/w neighborhood.  Keep physical control of m/c & limit access to your system  Disable File and Print sharing button  Control Panel  N/w  LAN  Prop  F & P Sharing  Don't ever share the entire C: drive.  Share only the folder having files to be shared.  Establish a good password for shared access.  Enable sharing on IPX/SPX protocol instead of TCP/IP.  N/w  Prop  F&P Shg  Install  Protocol  IPX  N/w  Prop  Advanced  Advanced Settings Adapters & Bindings  F&P Shg  IPX/SPX  http://www.tifr.res.in/~cc/ipx.htm

6. Windows Desktop Security  DO NOT say yes to all questions while browsing.  Use Personal firewalls :  Norton internet security,  Zone Alarm or  Sygate personal firewall etc  Check what all Ports your PC is listening.  Usually 10-15 TCP/UDP ports will be listening.  Unusual: Series of high no. ports opening to some particular IP Sign of Virus/Spy  Remove the application not installed by you.  Download and run Microsoft's BSA  Ref: Google  ”Securing windows”

7. C:\>netstat -an |more Active Connections Proto Local Address Foreign Address State TCP 0.0.0.0:7 0.0.0.0:0 LISTENING TCP 0.0.0.0:9 0.0.0.0:0 LISTENING TCP 0.0.0.0:13 0.0.0.0:0 LISTENING TCP 0.0.0.0:17 0.0.0.0:0 LISTENING TCP 0.0.0.0:19 0.0.0.0:0 LISTENING TCP 0.0.0.0:135 0.0.0.0:0 LISTENING TCP 0.0.0.0:1025 0.0.0.0:0 LISTENING TCP 0.0.0.0:1035 0.0.0.0:0 LISTENING TCP 0.0.0.0:1730 0.0.0.0:0 LISTENING TCP 0.0.0.0:1731 0.0.0.0:0 LISTENING TCP 0.0.0.0:5000 0.0.0.0:0 LISTENING TCP 127.0.0.1:1027 0.0.0.0:0 LISTENING TCP 127.0.0.1:1031 0.0.0.0:0 LISTENING TCP 127.0.0.1:10110 0.0.0.0:0 LISTENING Proto Local Address Foreign Address State UDP 0.0.0.0:7 *:* UDP 0.0.0.0:9 *:* UDP 0.0.0.0:13 *:* UDP 0.0.0.0:17 *:* UDP 0.0.0.0:19 *:* UDP 0.0.0.0:500 *:* UDP 0.0.0.0:1028 *:* UDP 0.0.0.0:1029 *:* UDP 0.0.0.0:1058 *:* UDP 0.0.0.0:1289 *:* UDP 127.0.0.1:123 *:* UDP 127.0.0.1:1900 *:* UDP 127.0.0.1:2282 *:* UDP 158.144.49.8:123 *:* UDP 158.144.49.8:1900 *:*

8. Overview Advantage Linux Threats to Linux machines. Securing Linux better.   

9. Advantage Linux  User vs. administrator  Only root can install software or change system settings.  More difficult for viruses to spread.  Commands, utilities, even the desktop run separately from the Kernel.  Security updates are easier, quicker to deploy.

10. Threats to Linux machines  Reasons for Break-in.  Loose Passwords  Improper Permissions  Careless Security  Unwanted Vulnerable Services  Brute force password attacks  Buffer overflows in network services.  int main () {int buffer[10];  Aim: overwrite some control information to change the flow of control in the program. buffer[20]=10;}

11. Securing Linux Secure the console Set good passwords Set right permissions Secure the network connection Restrict Access Iptables Firewalls, Ports & Services Handling / Restricting Services Adding security to desktop 10. Keep the system up to date 1. 2. 3. 4. 5. 6. 7. 8. 9.

12. Securing the console  Physical Security  Password protect the screensaver.  Set a password on the boot loader (lilo / grub).  Use xlock or xautolock while away.  Do NOT normally login as root in own machine.  Set BIOS Password.  Machine in safe location.  Set boot hierarchy to HDD first (not CD,HDD).  Restrict Remote access.  Set up an idle timeout, to logout idle users.

13. Passwords Use strong, unique passwords (especially for root) Must have a minimum length of 8 characters. Must be alpha-numeric not based on dictionary words. Password must be changed every 30 days. Account will be locked out after 3 consecutive unsuccessful login attempts. Don’t write down passwords or User-id & password. Passwords must contain multiple characters (Lower / Upper Case, numbers, punctuation etc.) Root password should be very hard to crack.        

14. Permissions  Correct permissions & ownerships on all directories & files.  Never make files world-writable / world readable.  Search for world-writable files in pwd  find . -perm -2 -print  Improper file permissions in /dev : read/write directly to hardware like hard disks and network interfaces.  /dev files should only be writable by root & readable only by their group  Exception : /dev/tty, /dev/pty, /dev/null, /dev/zero.  find /dev -perm -2 -print  chmod -R 700 /etc/rc.d/init.d/*  Lock the /etc/services file so that no one can modify it

15. Securing the Network  Remove all unwanted users and groups.  Enable nospoof option in /etc/host.conf.  Don't create /etc/hosts.equiv or a .rhosts file  Don't run rlogind or rshd. (pw in plain text)  Run sshd to allow remote access via SSH  Use TCP Wrappers “tcpd”  Use /etc/hosts.deny & /etc/hosts.allow  hosts.allow overrides hosts.deny  Disable unwanted services thru xinetd.conf also  Ref: man hosts_access  http://linux.about.com/od/commands/l/blcmdl5_hostsal.htm  http://www.userlocal.com/security/securinginetdetc.php

16. More of /etc/access.[allow|deny]  /etc/hosts.deny  Only Local host allowed access  ALL:ALL  /etc/hosts.allow  sshd: ALL @.tifr.res.in  ALL: .tifr.res.in EXCEPT xyz.tifr.res.in  Allow localhost  ALL : 127.0.0.1  Allow another m/c to connect to any service  ALL : 192.168.1.2  Let all ssh except 192.168.1.3 and 192.168.1.4  sshd: ALL EXCEPT 192.168.1.3, 192.168.1.4

17. Firewalls  Hardware firewall - A device between Internet & LAN.  Software firewall: Software on a desktop/server that rejects certain types of network traffic.  Consider implementing a firewall. man iptables  Restrict n/w traffic to a machine or network segment.  Improves security and network performance.  Why do I need a software firewall?  Protects the m/c even if the h/w firewall is compromised.  Protects the m/c against compromised m/c s on n/w.  When can't one use a firewall?  Some services (like Samba) may use unspecified ports.  Some applications want to use arbitrary ports.

18. Iptables  System Settings > Security Level  System Settings > Server Settings > Services  Activate iptables in runlevels 3 & 5  Chains: INPUT, OUTPUT,FORWARD.  Effects : ACCEPT, DENY, DROP  List all iptables rules  # iptables –L  # iptables -A INPUT -s <SIP> -j DROP  # iptables -D <Chain name> <Rule no>

19. Iptables (Contd…)  Drop all incoming telnet packets  # iptables -A INPUT -j DROP -p tcp --destination-port telnet  Block any incoming tcp packets on 2nd Eth card (eth1)  # iptables -A INPUT -j DROP -p tcp -i eth1  Drop incoming sync ie. anything not initiated by our PC  # iptables -A INPUT -p tcp --syn -j DROP  Block by mac address  iptables -A INPUT --mac-source 00:0B:DB:45:56:42 -j DROP  Ref:  http://www.cae.wisc.edu/site/public/?title=liniptables  http://www.redhat.com/docs/manuals/enterprise/RHE L4Manual/refguide/chiptables.html

20. Ports  What are ports?  Network connection analogous to a lane highway.  Each type of traffic needs to be in its own lane  A port is analogous to a lane on the highway; different types of traffic (http, ftp, ssh, etc.) use different ports (80,21,22 etc)  What ports need to be open?  Open the ports for services you need to use and/or offer others.  SSH (remote access to your machine): 22  FTP (file sharing server): 21  Web server: 80  X (display graphics on remote machines): 6000  See /etc/services for an exhaustive list.  Close unused ports/terminate unwanted services.

21. Services / Daemons  Services :  Special applications that start before any login  Web server (httpd or Apache)  File services (samba, NFS, ftpd)  Print services (lpd, CUPS)  Remote access (telnetd, sshd, vncserver)  Management tools (crond, rhnsd)  Why can services be dangerous?  Many services offer themselves to local & remote m/c s  If a flaw exists in the program providing the service, an attacker can exploit this flaw and break into the machine  RULE: don't run any services you don't need.  RULE: if you're running a service, restrict access possible.

22. Handling Services  How services work ?  1 -- singleuser mode  2 -- multi-user without networking  3 -- normal multi-user text mode  4 -- custom runlevel, not normally used  5 -- normal multi-user, graphical desktop  Default level is chosen in /etc/inittab  How are Services started ?  /etc/inittab (startup configuration file)  /etc/rc.d/rc.sysinit (configuration file)  /etc/rc.d/rcN.d  xinetd (service that starts network services as u need)  Identify running services using redhatconfigservices OR /usr/sbin/ntsysv OR /sbin/chkconfig list

23. Restricting Services  What services are unnecessary & how to stop ?  Use ssh instead of the r* services (rlogin, rsh, etc.)  telnet, ftp, NFSrelated services (portlock, nfslock, netfs)  Substitute for ftp -- use scp and sftp  sendmail – can use SMTP server (mailhost.tifr.res.in)  redhatconfigservices : Highlight service & Stop  Uncheck the service not required for each run level.  Use /usr/sbin/ntsysv OR  /etc/rc.d/init.d/servicename stop OR  /sbin/chkconfig service off commands.  Secure each service using its configuration files.

24. Adding Security to Desktop  Prevent remote root login.  Login as a real user and then su to root.  /etc/securetty has no entry starting "ttyp" / "pts".  /etc/sshd_config change PermitRootLogin "no".  Insert StrictHostKeycheck in /etc/sshd_config.  Turn off / uninstall all unwanted services  chkconfig --list | grep on  Turn off boot time “ON” of unwanted services  e.g.: exec, finger, ftp, httpd, login, lpd, nfs, ntalk, rexd, sendmail, shell, talk, telnet, tftp, uucp etc  chkconfig uucp off  Use SSH rather than the "r*" commands  ssh -l id remotehost : secure remote login (rlogin / telnet).  ssh -l id remotehost command :issue remote command (rsh).  scp localfile id@remotehost:remotefile : secure copy (rcp).

25. Adding Security to Desktop (Contd..)  Disable unwanted suid and sgid files  find -type -perm -04000 -o perm 02000.  Eg.: gpasswd, wall, and traceroute  Install sxid to keep an eye on suid and sgid scripts.  http://linux.cudeso.be/linuxdoc/sxid.php  Install libsafe  Protects against Buffer Overflow Attacks in Process stacks  Install tmpwatch to delete the unused files from /tmp  Check for unwanted scripts in /root, /usr/local, /var/spool/mbox.

26. Adding Security to Desktop (Contd..)  Check your machine's uptime: uptime  Linux doesn't crash or reboot under normal conditions.  If rebooted, try to find out the actual reason behind it  Take regular backups  Use rpm -Va to find out if an rpm is modified.  Apply security patches / upgrade vulnerable software  patch -p1 < patch file  Check system logs (eg: /var/log/messages, /var/log/secure)  Detect Intrusions with proper tools  Use Tripwire / aide to detect unauthorized changes to files.  System logs should be checked regularly for any trouble.  Install a log-checking tool. Freeware: webalizer, awstats  Do penetration test with tools like nessus, nikto, and nmap and see how well your machine is secured.

27. System up2date  Install system updates as soon as they become available.  Register system with RedHat N/w: /usr/sbin/rhn_register  Config up2date :: up2date-config  update up2date itself :: up2date u up2date  Update a package using up2date u “packagename”  Updating Everything :: up2date update  Create a cron job to run up2date every night.  # mkdir /redhat to mount the Red Hat mirror.  Automount redhat mirror at boot in /etc/fstab  linuxserver:/redhat /redhat nfs intr, bg 0 0  Run script /usr/sbin/getupdates in crontab Monday midnight  0 0 * * 1 /usr/sbin/getupdates  0 min 0 hr All months
