  1. Smart Choice for Wireless NetworkZTE CDMA Solution

  2. Contents • ZTE CDMA Overview • ZTE’s diversified & customized solutions

  3. ZTE Corporation China's largest listed telecommunication solution provider • Growth of Income from Main Business Lines: 23.03 billion RMB (over 3 billion USD) by the end of 2006 • Partners with over 500 operators in more than 100 countries • ZTE has become China’s largest telecommunications equipment exporter, and one of the leading CDMA equipment vendors in the world Growth of Income from Main Business Lines ZTE CDMA Volume (Line)

  4. ZTE the China’s largest listed CDMA Provider • No.1in the worldwide CDMA contract share in 2006 • No.1in the worldwide CDMA BTS provider in 2006 • Over 12000 BTSs have been delivered in 2006 • 110 million lines in the world (BSS Volume) • The total capacity of ZTE CDMA Softswitch products globally applied reaches up to 60 million lines Global CDMA Contract Distribution Source: Teleinfo Institute, China Academy of Telecommunication Research of MII

  5. ZTE CDMA Worldwide Presence 110 million lines over 70 countries with nearly 120 operators 50 CDMA2000 1xEV-DO network over 40 countries GoTa network over 20 countries ZTE Corporation (Headquarter)

  6. ZTE Global R&D Xi’an R&D: Radio frequency and intelligent antennas New Jersey, USA Stockholm, Sweden: WCDMA Chengdu R&D: Network Management Dallas, USA Chongqing R&D: OSS and VAS Beijing R&D: WDM and optic Vienne, France: ZTE Europe’s R&D and training centre San Diego, USA Tianjin R&D Shanghai R&D ZTE University CDMA Standard: San Diego R&D CDMA CN: Nanjing R&D CDMA RAN: Shenzhen R&D CDMA Handset: Shanghai R&D ZTE Support Center Islamabad, Pakistan R&D Nanjing R&D Shenzhen R&D Bangalore, IndiaR&D

  7. Devoting to CDMA standards and development • ZTE was the first Chinese IT and telecoms manufacturer listed in Business Week’s Information Technology 100. • ZTE invest in standards and patents to keep at the top of future technology. • ZTE has submitted over 1800 contributions to international standards organisations Standard Patent Partners ZTE is a member of over 50 international standardisation organisations, include 3GPP2, 3GPP, ITU, IEEE, ETSI and CDG. • ZTE is GoTa patent owner and have over200 patents of GoTa, including over30 key technology (system part). • . Grant GoTa IPR to other vendors : Nortel • Strategy Partners : Qualcomm, Nortel, Cisco, Intel, TI ……

  8. ZTE CDMA Time-to-market Strategy • ZTE is time-to-market leadership of CDMA • Considering future of technology & network • customer-oriented System designing 110 million lines in the world, Q3 2007 E2E All-IP 3GCN+BSSB,Ap Interface, IOS5.0 GoTa CDMA- based trunking system (global application) Launched Project on CDMA2000 1x 2007 ZTE started CDMA R&D. 2006 2005 2004 2003 2002 2000 EV-DO Rev. A (commercial contract) 1995 All-IP solutions: BSCB, BTSB CDMA2000 1xEV-DO system Demonstrated

  9. DO Rev. 0 Demo 1X GA DO Rev. 0 Trial ZTE Roadmap Supporting Sustainable Growth DO Rev.A GA DO Rev.B R&D DO Rel. 0 GA UMB Demo 1xEV-DO Rev B functionality & services DO Rev.A Trial All-IP CN GA UMB GA UMB Trail All-IP CN R&D 1X CN IS95 CN All-IP CN Trial IMS GA Rel. 4 IMS GA Rel. 2 IMS Trail Rel. 1 IMS GA Rel. 3 IMS Beta Support GOLD BCMCS-Q2,2006 VT on EV-DO Rev.A-Q2,2007 VoIP on EV-DO Rev.A-Q4,2007 Platinum BCMCS - Q3,2008

  10. ZTE CDMA Cost Saving Core Network ZXC10 MSCe/MGW All-IP Platform Maximum traffic 60,000 Erlang Flexible configuration IMS ZXC10-MSC/VLR Maximum capacity 600,000 Subs Flexible configuration ZXC10 HLRe Maximum capacity 6,000,000 subscribers Flexible configuration ZXC10-HLR/AuC Maximum capacity 1,200,000 subs Flexible configuration AGW ZXPDSS P200 All-IP Platform Maximum active PPP: 160,000 Maximum throughput: 3.2G ZXC10-PDSN (P100) Maximum supported data subscribers: 120,000 Maximum active PPP: 10000 Maximum throughput；200Mbps Support Cluster Largest capacity and flexible configuration will help to reduce the CAPEX & OPEX. 2000 2004 2005 2006 2007

  11. PSTN/PLMN MSCe Transmission MGW MGW BSC BSC ZTE CDMA All-IP Core Network • Industry trends for CN evolution: • Split Architecture, lower CAPEX/OPEX • TDM to IP, common IP bearer network • Converged network in IMS/MMD ZXC10 MSCe/MGW All-IP Platform CSCFMGCF ZXPDSS P200 All-IP Platform AGW • Cost saving core network solutions • Reducing CAPEX & OPEX • Unified hardware platform • Smooth migration to IMS A/Ap A/Ap

  12. ZTE CDMA BSS Solutions • Multiple BTSs for diversified solutions ZXC10-BSCB (All-IP based) Maximum capacity: BHCA 4700k, 50,000 Erlang Maximum Throughput: 6G Flexible Configuration ZXC10-BSC Footprint: 700*600 Flexible Configuration ZXC10-CBTS (All-IP BTS) Support CDMA2000 1x & EV-DO Maximum 12 CS /Rack Flexible configuration Footprint 600*600 ZXC10-BTSB ( All-IP Super BTS) Support CDMA2000 1x & EV-DO Flexible configuration Support multi-frequency Maximum 120 carrier-sectors ZXC10-BTS Support CDMA2000 1x & EV-DO Flexible Configuration Maximum S222 /Rack ZXC10-CBTS 01 (Outdoor All-IP Macro BTS) Maximum 12CS/Rack Flexible configuration ZXC10-MBTS (Outdoor) Support CDMA2000 1x & EV-DO Flexible Configuration Weight: 37kg/Box Support extension coverage solution ZXC10-MBTS (Outdoor) Support CDMA2000 1x Flexible Configuration Weight: 37kg Support extension coverage solution 2000 2004 2005 2006 2007

  13. ZXC10-BTS R-Series ZXC10-CBTS ZXC10-BTSB ZXC10-BTS M-Series • City /Urban areas • Commercial center and residential area • Village • Small town / Country ZXC10-CBTS ZXC10-CBTS O1 ZXC10-BTS Series ZXC10-BTS R-Series ZXC10-BTS R-Series ZXC10-BTS M-Series ZXC10-BTS M-Series • Temporary installations required for peak usage demands, such as Exhibitions, conventions • The regions restricted by geographical environment and climate condition ZXC10-CBTS O1 ZTE CDMA Wireless Coverage Solution • Series of full-band products, such as large-/medium-/small-capacity macro base stations, micro base stations and RF remote stations with indoor coverage and super-long-range coverage. The Abis interface supports star networking, chain networking and ring networking. It also supports E1/T1 transmission, satellite transmission, microwave transmission, Ethernet transmission, and SDH transmission

  14. 3rd Party MSS 3rd Party BSS 3rd Party LE Nortel Lucent Ericsson Alcatel Datang (China) LG Huawei Nortel Motorola Ericsson Samsung LG NEC (NEAX) Ericsson (AXE) C-DOT Alcatel (OCB) Siemens (EWSD) Lucent (5ESS) IOS IOS V5.2 CDMA Network planning & optimization tools ZTE CN ZTE RAN Equipment Config Data Wireless Network Performance A Interface ZXPOS CNT1, CNA1 CNS1, CNO1 … OMC Analysis CDMA Network Alarm Resource Utilization Ratio Performance stat. Drive Test Call Track Report IOT and network planning & optimization

  15. ZTE CDMA Manufacture Outline • ZTE CDMA manufacture profile • 18000 ㎡ workshops • 6 Floors • 18 production lines • A new manufacturing center of CDMA in ZTE Industrial Park with 413233 ㎡ will be available by the end of 2007.

  16. Highlights of ZTE CDMA Solutions No.1 worldwide CDMA Contract share (2006) No.1 worldwide CDMA contract share (, 2006) World’s first All-IP Solution provider World’s first All-IP Solution provider World’s first CDMA based trunking system provider World’s first CDMA based trunking system provider The CDMA provider serving the largest number of countries and operators in the world The CDMA provider serving the largest number of countries and operators in the world World’s biggest CDMA Services provider World’s biggest CDMA Services provider World’s first CDMA & GSM Gateway (GSM1X) provider World’s first CDMA & GSM Gateway (GSM1X) provider No.1 CDMA Provider in South Asia No.1 CDMA Provider in South Asia No.1 CDMA Provider in North Africa & Middle East No.1 CDMA Provider in North Africa & Middle East No.1 CDMA Provider in Asia & Pacific (Except Japan & South Korea) No.1 CDMA Provider in Asia & Pacific (Except Japan & South Korea) No.1 domestic CDMA Handset provider in China No.1 domestic CDMA Handset provider in China

  17. Contents • ZTE CDMA Overview • ZTE’s diversified & customized solutions • ZTE CDMA All-IP Solution • ZTE CDMA EV-DO Solution • ZTE CDMA WLL Solution • ZTE GoTa Solution • ZTE Managed Service Solution • ZTE Network Planning & Optimization Solution • ZTE CDMA Terminal Solution

  18. WIN ZTE CDMA Solution Billing Server App Platform NMS HLR AAA PDSN Core Network MSCe Packet Data Network Internet PDS MGW PHR BTS Access Network IP Network Transmission DAC BSC DSS AN-AAA DAS Terminals FWT PCMCIA Card Mobile Handset

  19. ZTE Managed Service Solution ZTE Network Planning & Optimization Solution ZTE CDMA All-IP Solution ZTE CDMA Solution ZTE CDMA WLL Solution ZTE Terminal Solution ZTE CDMA EV-DO Solution ZTE GoTa Solution ZTE’s Diversified & Customized Solutions

  20. + CDMA Handset CDMA Network VAS (Value Added Services) VAS Platform Network Management Marketing Win-win cooperation with China Unicom • Strategic Partnership with China Unicom • No. 1 CDMA VAS provider: SMS, LBS, WIN, MMS, VMS, WAP, CRBT, Video Streaming, BREW etc • No. 2 CDMA Handset vendor

  21. Network situations Subscriber situations Purpose Analysis Why & How to build network Service suggestion & operation suggestion Revenue situations Feasibility Analysis Competitors situations Advantage situations Win-win cooperation with China Unicom • ZTE CDMA Solution for China Unicom Growth Rate of China Unicom CDMA Network Market Distribution of China Unicom

  22. GSM1X CDMA GSM Win-win cooperation with China Unicom • Diversity Solution in Dual-network ZTE H550 Dual-mode • ZTE’s G&C dual-mode mobile system is a system that supports users to freely roam between GSM and CDMA networks. • One handset and two networks

  23. Phase 4: Focus on quality and KPI Step 3 Win-win cooperation with China Unicom • Capacity : 13,500,000; Covered 96% middle cities and 88% counties or towns, 30% villages and roads Phase 1 • Step 2: Add 1x data, improve coverage, Add new services such as SMS/PPS/Data … • Rollout achieved national coverage • Step1: small capacity & large coverage Phase 2 Focuses on services and coverage • Capacity: 35,000,000, built 1x packet data network, simple IP services, WAP, 1x data card etc • Step 4: Target network, capacity, coverage, services and customer care. Benchmark KPI of China Mobile • Step 3: Continue improvement on coverage, focus on rural coverage and indoor coverage • Capacity: 70,000,000 subs

  24. Contents • Trust yourself trust ZTE • ZTE’s diversified & customized solutions • ZTE CDMA All-IP Solution • ZTE CDMA EV-DO Solution • ZTE CDMA WLL Solution • ZTE GoTa Solution • ZTE Managed Service Solution • ZTE Network Planning & Optimization Solution • ZTE CDMA Terminal Solution

  25. PSTN/PLMN MSCe Transmission IP Network SIP-T MGW MGW TrFO ZXC10 MSCe ZXC10 MSCe BSC BSC A1p A1p PSTN H.248 H.248 A2p A2p ZXC10 MGW ZXC10 MGW ZXC10 BSC ZXC10 BSC BTS RTO ZTE All-IP CDMA Solution • All-IP Deployment for Softswitch: No TMSC • Central MSCe with Distributed MGWs: Save long-distance transmission • Less investment on sites and accessories • Need less transmissions for inter-connecting • Need less investment for service deployment • Can be evolve to IMS smoothly • TrFO & RTO • Ap Interface (IOS 5.0) • Saving transmission investment (over 80%)

  26. ZTE All-IP based solution for SLT • Operator: Sir Lanka Telecom • To become the hub of telecommunications in South Asia • System Capacity: 550,000 subscribers • 2 3GCN • 2 BSC • 330 BTS • 800M CDMA WLL with All-IP Platform • Within only three weeks, ZTE helped SLT successfully launch the CDMA service in Sri-Lanka • Sri Lanka Telecom's 2nd quarter (2006) profits up 112% • Subscriber is more than450,000 on September 2007.

  27. All-IP Based Solutions for SLT (Cont.) What SLT benefits from the All-IP based network? • SLT in 2005 • At the end of 2005 (two months after commercial launch), more than 40,000 subscribers were provisioned. • SLT’s Group net profits for the first quarter of 2006 topped 1.3 billion rupees($12,143,858). • SLT in 2006 • Second quarter of 2006 Sri Lanka Telecom's 2nd quarter profits up 112% …. SLTs earnings are being lifted by the wireless CDMA services introduced last November. …. (the report from LBO)http://www.lankabusinessonline.com/fullstory.php?newsID=669631945&no_view=1&SEARCH_TERM=5 • SLT in 2007 • First quarter of 2007During the first quarter 42,000 new connections have been issued pushing CDMA subscribers to 311,400.http://www.lankabusinessonline.com/fullstory.php?newsID=83110845&no_view=1&SEARCH_TERM=5… it hopes to secure 50,000 CDMAs by the end of the year.http://sundaytimes.lk/070520/FinancialTimes/ft311.html Current subscriber is more than 260,000 at end of 2006.

  28. Contents • Building better future with CDMA2000 • Trust yourself trust ZTE • ZTE’s diversified & customized solutions • ZTE CDMA All-IP Solution • ZTE CDMA EV-DO Solution • ZTE CDMA WLL Solution • ZTE GoTa Solution • ZTE Managed Service Solution • ZTE Network Planning & Optimization Solution • ZTE CDMA Terminal Solution

  29. 1X & EV-DO simultaneous RFS CHM EV-DO Rel.0 /Rev.A CDMA2000 1x + EV-DO Software RFS CHM CDMA2000 1x CDMA2000 1x Software Software Upgrade ZTE CDMA EV-DO Solution • ZTE provide the best cost efficient CDMA2000 1x EV-DO solution • Same BSS platform for 1x and DO service, no separate DO BSC is required; • 1x traffic and DO traffic dynamically shares the bandwidth of Abis link between BSC and BTS. • Maximum 6Gbps data throughput per BSC, enable ZTE BSS for future technology evolution

  30. ZTE EV-DO Rev.A solution for Skytel in Mongolia • Operator: Skytel • ZTE signedthe world first commercial EV-DO Rev.Acontract with Skytel • Skytel is Mongolia's largest CDMAmobile telecoms network provider • Capacity • 286,000 lines • 134 BTS • Subscriber is more than 150,000

  31. ZTE CDMA EV-DO Solution for Mobilkom in Czech • Frequency range410-412.75MHz/ 420-422.75MHz • Mobile service in whole Czech Republic • The first EV-DO Rev.A network in Europe • Services: • EV-DO Rev.A • GoTa • CDMA2000 1x • Operator: Mobilkom • System capacity: • 200,000 lines • 350 BTSs • 450M Block L CDMA WLL ZTE customizes 450M L block system for MobilKom

  32. Contents • Trust yourself trust ZTE • ZTE’s diversified & customized solutions • ZTE CDMA All-IP Solution • ZTE CDMA EV-DO Solution • ZTE CDMA WLL Solution • ZTE GoTa Solution • ZTE Managed Service Solution • ZTE Network Planning & Optimization Solution • ZTE CDMA Terminal Solution

  33. ZTE CDMA WLL Solution • Support V5 interface and A/Ap interface Village Small town / Country • Newly-built commercial center and residential area • Saturated copper infrastructure • Hard to pave coaxial cables CDMA WLL Spares Population Areas Hot Spot Areas • Restricted by geographical environment and climate condition • Temporary installations required for peak usage demands, such as Exhibitions, conventions

  34. ZTE CDMA WLL Solution in India of BSNL • Operator: BSNL • System capacity: • Over 6.5 Million lines • More than 8200 BTSs • 800M CDMA WLL with MSC • Limited Mobility • Voice, Data, G3 FAX … • The largest CDMA WLL network in South-Asia • FWT and handset is welcome and comfortable for end users

  35. ZTE CDMA WLL Solution in India of BSNL (Cont.) • ZTE CDMA WLL Solution for BSNL • Wide Area Coverage • Series BTS: Macro-BTS, Micro-BTS, Remote RFS • Flexible networking modes • Diversified Service Solutions • Voice, Data, G3 FAX … • Powerful engineering capacity • Customer first strategy • BSNL CDMA WLL Marketing • Both fixed line telephony & Mobile telephony • Brand: Tarang • Lower tariff • Terminals almost free of charge • Limited Mobility • Package price for Data services

  36. Contents • Trust yourself trust ZTE • ZTE’s diversified & customized solutions • ZTE CDMA All-IP Solution • ZTE CDMA EV-DO Solution • ZTE CDMA WLL Solution • ZTE GoTa Solution • ZTE Managed Service Solution • ZTE Network Planning & Optimization Solution • ZTE CDMA Terminal Solution

  37. ZTE CDMA GoTa Solution BSS MSC HLR CDMA System • BSS • MSS • PDSS SMS BTS MSS MGW Transmission BSC BTS • DSS • Dispatching Subsystem • Professional trunking Service AAA PDSN BTS PDSS IP Network Dispatching Console Dispatching Console DSS DAS PHR PDS

  38. GoTa and CDMA Solution in Norway • FirstCDMA based Trunking system in Europe • Professional GoTa Handset, Trunking, CDMA20001x EV-DO high speed data service • 125k lines, 450MHz

  39. Malaysia Electcoms GoTa System • National Wide coverage • Enhanced Digital Trunking System • Advantage technology • Progress, Innovation and advance • National Wide coverage • 50,000 Subs and 99 BTS • Professional Trunking Services • Push to Talk • Private Call • Group Call • Broadcast Call • VAS

  40. Malaysia Electcoms GoTa System (Cont.) • The Electcoms GoTa network is being built in three phases • Phase 1: the network covering the Kuala Lumpur region (has been completed) • Phase 2 and Phase 3 will reportedly expand the Phase 1 system to cover the whole of Malaysia.

  41. Ghana National Security Information System • National wide coverage • 10 Regions and total capacity of 50,000 Subs, Turn-key project. • 2 Phases • Phase I • 70 BTS, 24K subs for 10 region's capital cities, all Great Accra • Stage I: Ceremony celebration with the capacity of 10k subs,15BTS, and 2000 G650 • Stage II: remaining 55 BTS and terminals available by the end of 2007. • Phase II • 110 BTS, 26K subs for all 128 District Cities and boarders GoTa Equipment Center in Accra

  42. Police and Security Guards Commander and Army Leader Officials MP Ghana National Security Information System (Cont.) • Ceremony: 50th anniversary of Ghana Independence • Capacity: 10k subs,15BTS, and 2000 terminals • Active subs was over 600

  43. GoTa Serves Qingdao Olympic Sailing Test Match • Providing City Emergency Response System to guarantee the Olympic pre-test match in July 2007 • Serving for Qingdao Olympic Sailing test match in August 2007 • Providing dispatching and communication services • Serving for the government departments of Qingdao Emergency Response System • Capacity • 1400 terminals • 22 BTSs

  44. Contents • Trust yourself trust ZTE • ZTE’s diversified & customized solutions • ZTE CDMA All-IP Solution • ZTE CDMA EV-DO Solution • ZTE CDMA WLL Solution • ZTE GoTa Solution • ZTE Managed Service Solution • ZTE Network Planning & Optimization Solution • ZTE CDMA Terminal Solution

  45. ZTE CDMA Managed Services • Managed Services is a tailor-made solution developed by ZTE to satisfy its Customer’s needs • Managed Services is not only establish and maintain a perfect network but also maximize the benefits of both customer and ZTE. Your Requirement OA&M Outsourcing • High network operation quality • speed up grasp new technology and launching new services • Enhance subscriber satisfaction • Minimize operating cost • Improve profit margin ZTE Network daily Maintenance Managed Services Solution Network Operation Mgmt. Administration Service Services Provisioning Tech & Processes Transfer Long Term Operation Capable Team

  46. Central office of Kasapa ZTE Managed Services for Kasapa in Ghana • This 3-year Managed Services Contract signed between ZTE and Kasapa International Ltd in June 2007. • ZTE will be responsible for the management, operation and performance of that network and IT infrastructure. Kasapa’s O&M employees will be transferred to ZTE. • Kasapa win the Ghana Qos Award in 2006 • Kasapa gain subscribers very quickly: 240,000 subs in 10 month

  47. ZTE Managed Services for Kasapa in Ghana (Cont.) • Based on understanding what KASAPA really needs, ZTE developed a tailor-made Managed Services for KASAPA.

  48. Contents • Trust yourself trust ZTE • ZTE’s diversified & customized solutions • ZTE CDMA All-IP Solution • ZTE CDMA EV-DO Solution • ZTE CDMA WLL Solution • ZTE GoTa Solution • ZTE Managed Service Solution • ZTE Network Planning & Optimization Solution • ZTE CDMA Terminal Solution

  49. DT Testing Alarm Information Collection OMC Data Collection CQT Testing ZTE Network Planning & Optimization Solution • Experience with 110 million lines in nearly 120 operators Proposal of network planning & optimization Network situations Analysis Network Simulation Executing Testing & Debugging Pigeonholing & commissioning

  50. Network Planning & Optimization in Different Environment Density City Mountainous City Railway /Highway
