Frequency Distributions in Statistics

DESCRIPTION

Learn about frequency, percentage, and cumulative distributions in statistics, with practical examples and graphing techniques. Explore the importance of normal curves and data interpretation.

1 / 37

Télécharger la présentation

Frequency Distributions in Statistics

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. FREQUENCY DISTRIBUTIONS & GRAPHING

  2. Statistics • Ordering & Grouping of Information • N = 50, a test score of 83% • where does it fit in the class?? • N = 25, a GRF value of 27 N/kg • where does it fit in the sample??

  3. Nomenclature • Frequency: number of cases or subjects or occurrences • represented with f • ie f = 12 for a score of 25 • 12 occurrences of 25 in the sample

  4. Nomenclature • Percentage: number of cases or subjects or occurrences expressed per 100 • represented with P or % • ie f = 12 for a score of 25 when n = 25 • P = 12/25*100 = 48%

  5. Caveat (Warning) • Should report the f when presenting percentages • ie 80% of the elementary students came from a family with an income < $25,000 • different interpretation if n = 5 compared to n = 100 • report in literature as • f = 4 (80%) OR • 80% (f = 4) OR 80% (n = 4)

  6. Numerator Monster Headline: State Farm distributes more than $1 billion in repayments to policyholders More than $34 million in Illinois Pantagraph, 6/13/00

  7. Numerator Monster Pantagraph, 6/13/00

  8. Numerator Monster Pantagraph, 6/13/00

  9. Frequency Distribution of Test Scores • 40 items on exam • Most students scored >34 • skewed • more scores at one end of the scale

  10. Cumulative frequency • Cumulative Frequency: how many subjects in and below a given score (SPSS???)

  11. Cumulative percentage • Cumulative Percentage: what % of subjects in and above a given score

  12. Cumulative percentage • Cumulative Percentage: what % of subjects in and below a given score

  13. Eyeball data check: Graphing with SPSS • Stem and Leaf plot (quick viewing of data distribution) • Bar Chart: each score separate bar • Histogram: malleable bar graph • Polygon: line graph (not available on SPSS)

  14. Fast look at shape of distribution shows f numerically & graphically stem is value, leaf is f Stem and Leaf(SPSS: Explore command) Frequency Stem & Leaf 2.00 Extremes (=<25.0) 2.00 28 . 00 2.00 29 . 00 1.00 30 . 0 1.00 31 . 0 3.00 32 . 000 1.00 33 . 0 6.00 34 . 000000 3.00 35 . 000 4.00 36 . 0000 8.00 37 . 00000000 Stem width: 1 Each leaf: 1 case(s)

  15. Format of Bar Chart Y axis (ordinate) f X axis (abcissa) scores/categories

  16. Test score data as Bar Chart

  17. Rules for Frequency Distributions • 10 to 20 groups of score intervals

  18. Rules for Frequency Distributions • 10 to 20 groups of score intervals • intervals of the same size

  19. Rules for Frequency Distributions • 10 to 20 groups of score intervals • intervals of the same size • score interval size calculated as (Max - Min) / # score intervals

  20. Rules for Frequency Distributions • 10 to 20 groups of score intervals • intervals of the same size • score interval size calculated as (Max - Min) / # score intervals • Need more information about calculating by hand?

  21. Format of Histogram Y axis (ordinate) f Can be manipulated X axis (abcissa) Scores / categories

  22. Test score data as Histogram

  23. Test score data as revised Histogram

  24. Shapes of Distributions • Scores arranged from low to high creates a distribution • with large n, distribution becomes smoother (a curve) • characteristic curves are named

  25. Normal Curve (bell-shaped) f high low scores

  26. Bell Curve Importance f high low scores Height or weight or VO2 or GRF or Vision or Skill

  27. Bell-curve importance • Natural data typically follows the normal curve • height, weight, strength, aerobic capacity, vitamin intake • The Happiness Meter • Basis of inferential statistics

  28. Skewed Distribution f Positive Skewness high low scores

  29. Skewed Distribution f Negative Skewness high low scores

  30. Male & Female Strength

  31. Interesting Distribution Assessment f Expected distribution of agent-paid claims (State Farm Ins.) high low $$ amount

  32. Interesting Distribution Assessment f Observed distribution of an agent-paid claims (suspicious.) high low $$ amount

  33. Table 4.1 data as Histogram Normal Curve

  34. Table 4.1 data as Histogram

  35. Always plot out data as a first step in the analysis

  36. Percentiles(Percentile Ranks) • Percentile: Values above and below which certain percentages of cases fall. • ie Doctors • 25% earn < $100,000 • 25% earn > $225,000 • How to divide scores into these ranks?

  37. Percentiles (Quartiles) Data from Table 4.1
