  1. Extending SharePoint through Web Parts and ASP.NET 최승현 대리(shchoi@microsoft.com) 한국마이크로소프트

  2. Built on .Net Framework • Windows SharePoint Server (WSS) v2 is built on top of the .Net Framework • WSS will ship as part of the OS; SharePoint Portal Server is built on top of WSS • WSS has made large investments in developer extensibility • By embracing .NET, WSS is positioned to leverage future advances in the platform

  3. Summary of .NET support • WSS will use ASP.NET instead of ISAPI for base page execution • Web Part Framework • Server Object Model for programmatic access to SharePoint data • We offer functionality as XML web services for access from remote machines

  4. Web Custom Controls • Controls map directly to the XML (CAML) tags used on the WSS site pages: • ListViewWebPart A web custom control that will output a SharePoint view • ListFormWebPart A web custom control that will output a SharePoint form. • ViewSelector A web custom control for representing a view selector. • ListProperty A web custom control that returns a property of a list • ProjectProperty A web custom control that returns a given web property

  5. Web Part Framework • Personalize your SharePoint home page to simplify and focus on the information that is most relevant to you. • Authors build custom solutions using Web Parts and Web Part Pages. • .NET developers extend SharePoint by encapsulating web services and enterprise data as Web Parts

  6. Extending the Platform • Web Part Pages • Scalable Dashboards v2 • Framework for extending SharePoint • Web Parts • ASP.NET web custom controls are the building blocks of Web Part Pages • Visual display of SharePoint liWSS, web services, corporate information, etc. • End users, authors, and developers

  7. Using Web Part Pages • Shared View and Personal View allows users to simplify and focus on the most important information. • Find and integrate data from many sources. • Layout and settings are easy to configure. • Catalogs offer new content to add to your page. • Information is available on other browsers.

  8. Portable Web Parts • Web Part is a .Net web custom control assembly • DWP files contain meta-data describing the instance of the part • Code doesn’t travel with the part • Box administrators must install the assembly

  9. DWP Sample

  10. FrontPage • Continues to be a great tool for customizing SharePoint sites • Visual presentations on web services without writing code using the DataView Web Part • Setting zone properties • Editing the Html page layout • Link fix-up of base-class parts

  11. HTML view of List Content Editor Page Viewer DataView XML/XSL Web Parts for Authors • Windows SharePoint Server: • Office: • Web Capture Web Part • Spreadsheet • PivotView • ChartView • Grid View of List

  12. Connecting Parts Together • Parts sending messages to other parts • RCA cables • Standardized client and server interfaces • Web Part interfaces • IList • IRow • ICell • IFilter • Transforms

  13. Key Features for Developers • An extension to the .Net Framework: • Installed when you install WSS v2 • Web Part Pages are ASP.NET pages • Web Parts are ASP.NET web custom controls • Scales out for large server farms • Use Visual Studio to quickly build, test, and deploy custom Web Parts.

  14. Web Part Zones • Stuff on the Page… • Web Part Zones are embedded directly on the page • Stuff in the db… • All users and just for me web parts inside zones are stored in the SharePoint WebParts table • Personalizations are stored in the SharePoint Personalizations table <SmartPages:WebPartZone runat="server" Title=“Left ZoneID=“…" Orientation="Vertical“ AllowCustomization=“true” AllowPersonalization=“true”/>

  15. Web Part Zones ASP.NET Page Web Part Framework ASP.NET Page Zone 1 Zone 3 Zone 2 Content DB Web Custom Controls

  16. Zone Properties • Layout Properties • ID • Orientation • ContainerWidth • Title • FrameType • Lockdown Properties • LockLayout • AllowCustomization • AllowPersonalization

  17. Properties • Base class properties • Custom Properties • Default property sheet for browseable properties with builder infrastructure • Use ToolParts for creating custom property UI • There are limited types because we are serializing properties: • string, bool, int, float, enum, System.DateTime, and System.Drawing.KnownColor

  18. Web Part Properties [Category("Custom Properties")] [WebPartStorage(Storage.PerUser)] [FriendlyNameAttribute("Custom Integer")] [Description("Type an integer value.") ] [Browsable(true)] [XmlElement(ElementName="SuperInt")] public int MyInt { get { return _myInt; } set { _myInt = value; } }

  19. Web Part Caching • Using code developers have the ability to cache rendered output • Two types of web part application caching • ASP.NET web server memory caching • Database caching • Web.config setting for which type

  20. Other Framework Features • Run-time filter enables the ability to turn parts on and off • Developers can add and remove Web Part menu items • Developers can create custom views of the Task Pane using ToolParts

  21. Web Part Code Access Security • Code access security (CAS) allows box administrators grant specific rights to assemblies • Goal of CAS is to separate access rights of the user from the access rights of the assembly • Admin can deny access to local resources for partial trusted assemblies • Admin can allocate trust based on signatures, strong names, and certificates

  22. Rights and Roles • WSS has 4 user roles • Reader—Cannot change web part properties • Contributor • Pages in webs—Can make personal changes • Pages in document libraries—Can make authoring changes along with personal changes • Web Designer—Can make authoring changes for all pages • Administrator—Can upload web parts to the web part catalog

  23. Security • Only registered set of web custom controls will run in SharePoint pages • Inline script in the page will not execute • Code behind in pages can be made to work • All Executable code (e.g. web custom controls, web parts, and code-behind classes) needs to be installed on physical web server

  24. GetSmartPageDocument SaveWebPart DeleteWebPart RenderWebPartForEdit GetWebPart AddWebPart GetWebPartProperties GetXmlDataFromDataSource GetWebPartCrossPageCompatibility GetSmartPageConnectionInfo GetWebPartsForDoc Web Services Object Model • Rich web service support for driving sites. • FrontPage uses these public web services for page authoring. • Path to web services: http://[servername]/_vti_bin/smartpgs.asmx
