  1. MapReduce 資工碩一 黃威凱

  2. Outline • Purpose • Example • Method • Advanced 資工碩一 黃威凱

  3. purpose 資工碩一 黃威凱

  4. Purpose • Data mining • Data processing 資工碩一 黃威凱

  5. example 資工碩一 黃威凱

  6. Example • Find the maximum temperature of year • National Climatic Data Center(NCDC) • The data is stored using a line-oriented ASCII format , in which each line is a record • There is a directory for each year from 1901 to 2001 ,each containing a gzipped file for each weather station with its readings for that year 資工碩一 黃威凱

  7. Example(Data format) 資工碩一 黃威凱

  8. Example(Gzipped file, example for 1990) • % ls raw/1990 | head • 010010-99999-1990.gz • 010014-99999-1990.gz • 010015-99999-1990.gz • 010016-99999-1990.gz • 010017-99999-1990.gz • 010030-99999-1990.gz • 010040-99999-1990.gz • 010080-99999-1990.gz • 010100-99999-1990.gz • 010150-99999-1990.gz 資工碩一 黃威凱

  9. Method 資工碩一 黃威凱

  10. Method • Analzing the data with Unix tools • Analzing the data with Hadoop 資工碩一 黃威凱

  11. Method(Unix tools) 資工碩一 黃威凱

  12. Method(Unix tools) • Here is the beginning of a run: • % ./max_temperature.sh • 1901 317 • 1902 244 • 1903 289 • 1904 256 • 1905 283 • ... • The complete run for the century took 42 minutes in one run single EC2 High-CPU Extra Large Instance. 資工碩一 黃威凱

  13. Method(Hadoop) • Use MapReduce • Map • Shuffle • Reduce 資工碩一 黃威凱

  14. Method(Hadoop) • Map function • Pull out the year and the air temperature • Transform key-value pairs 資工碩一 黃威凱

  15. Method(Hadoop) • Map function • The shuffle • Each reduce task is fed by many map tasks. 資工碩一 黃威凱

  16. Method(Hadoop) • Reduce function • Iterate through the list and pick up the maximum reading • Input • (1949, [111, 78]) • (1950, [0, 22, -11]) • Output: • (1949, 111) • (1950, 22) 資工碩一 黃威凱

  17. Method(Hadoop) • Data flow 資工碩一 黃威凱

  18. Method(Hadoop) • Java MapReduce-Mapper example 資工碩一 黃威凱

  19. Method(Hadoop) • Java MapReduce-Reduce example 資工碩一 黃威凱

  20. Method(Hadoop) • Java MapReduce-Job example Support multiple path 資工碩一 黃威凱

  21. Advanced 資工碩一 黃威凱

  22. Advanced • Case1 資工碩一 黃威凱

  23. Advanced • Case2 資工碩一 黃威凱

  24. Advanced • Case3 資工碩一 黃威凱

  25. Advanced • Combiner Functions on Map output • Example • Map input1: (1950, 0), (1950, 20), (1950, 10) • Map input2: (1950, 25), (1950, 15) • After shuffle: • Map1: (1950, [0,20,10]) • Map2: (1950, [25,15]) • No UseCombiner to reduce input • (1950, [0, 20, 10, 25, 15]) • Use Combiner to reduce input • (1950, [20, 25]) 資工碩一 黃威凱
