  1. fly

  2. Group members • Eugene • Ignatius • Adrian • Tristan

  3. Eugene

  4. Ignatius

  5. Adrian

  6. Tristan

  7. The poor • No money • No basic survival necessities • No new clothes • Usually in debt

  8. Young adults • Not much income • Has not much wisdom in life • Is more prone to scams than adults

  9. Teenagers • Rebellious • Stubborn

  10. Elderly • Weak • Frail • Sick • Sight problems • Cannot hear

  11. The ELDERLY • Important: low resistance to the weather elements

  12. The Idea 1 • Umbrella that is connected to waist-belt • Thiswill be connected to the waist to save space for the elderly

  13. The Idea 2 • Auto-washing machine • It will provide a certain amount of comfort for the user

  14. The Idea 3 • Windbreaker • The idea is to install a DIY heater into the windbreaker to keep the elderly warm

  15. Windbreaker • Expensive • No pockets

  16. Voting!

  17. Voting 2 Colours of the windbreaker

  18. Voting 3

  19. Voting 4

  20. Conclusion Idea 1, black, waterproof, shiny appearance

  21. The Jacket • This is an example:

  22. Modifications • Add cost of heater into the amount

  23. Modification: Price • S$195 S$120 (decrease by S$75) • Profit maybe about 10% instead 30% • Decrease by 20%, about S$20

  24. Placement of added parts (Pocket) (Pocket) (Pocket) (rear) Heater

  25. Heater • Uses rechargeable battery: Energy Source • Small and compact

  26. Heater>Heating coil • We are going to use a heating coil that will tap into a battery within a battery holder through wires which will also conduct heat throughout the jacket.

  27. Heater>heating coil>for parts • Nichrome wire

  28. Heater>heat • The heating coil will utillize the heating element(air or water)and send that heat throughout the jacket through wires

  29. Factor 1 • Materials on the jacket: Fur Cotton Copper wire

  30. FACTOR 2 • Materials for the heater • Motor • Hardcover casing

  31. Heater materials • Hardcover case:->Styrofoam & tampered glass • Resin?? • Motor??

  32. Final Heater Design • The heater itself is the plastic container • The switch is the syringe - Up is off and down is on • The conducting wire is sewn into the bottom rim of the jacket • Another pair of heating wires leading to the sleeves could have been stuck on with red tape • The batteries are any size just so long as contact between the aluminum foil is made

  33. The heater The switch is the syringe which contains the battery and heating coil is in the heating box The conducting wire is sewn into the bottom rim of the jacket The syringe and the heating box can be put into the pocket.

  34. Finished product

  35. SCAMPER • Applying scamper to our design

  36. S=substitute • We substituted a windbreaker into a jacket

  37. C=COMBINE • We combined the jacket and windbreaker

  38. A=adapt • We adapted to the various needs of the project

  39. M=MODIFY • We used a reflective cloth instead of using aluminum

  40. P=PUT TO OTHER USE • The 4 different categories can use this

  41. E-ELIMINATE • Remove the idea of a bulky heater

  42. Our blog ipwfly.wordpress.com

  43. Credits • Facebook • Google • The people who participated in our survey

  44. The end • We have come to the end of our presentation • Thank you for your attention
