  1. Software Testing

  2. Testing Levels (McConnel) • Unit Testing • Single programmer involved in writing tested code • Component Testing • Multiple programmers involved in writing test code • Integration Testing • Testing two or more independently developed, interacting modules together • Regression Testing • Use a set of tests that can be rerun when changes are made to the system

  3. Testing Transparency • White-box Testing • Tester has access to the code • Black-box Testing • Tester has no access to the code • Relies on functional descriptions

  4. Test Plan • Test plan consists of a set of tests and the expected results

  5. Code coverage • What parts of the code are actually executed by a test? • Statement coverage • What combinations of sections of code are executed by a test? • Conditional Coverage (all conditions are evaluated as true at least once and as false at least once)

  6. Boundary Values • Identify equivalence classes • Array declaration example: • Good test cases usually test the boundary values of inputs • Empty strings • Max number of array elements

  7. Finding Equivalence Classes:C++ Array Declaration

  8. Boundary-Value Analysis • Successful test cases frequently include values that are “directly on, above or beneath the edges of input equivalence classes and output equivalence classes.” (Myers) • Each edge of an equivalence class is subject to test • Result space is considered as well as input space

  9. Boundary-Value Analysis (Myers) • Write test cases for the ends of input ranges • Input range is [-1.0, 1.0] • Write cases for -1.0, 1.0, -1.0001, 1.0001 • Number of possible inputs is [1,255] • Write cases for 0, 1, 255, 256 • Write test cases for the ends of output ranges • Calculated SS Tax (FICA) is [$0,$6621.60] • Write cases that yield results: $0, $.01, $6621.60 , and $6621.61 • Number of possible output is [1,255] • Write cases for 0,1 255, 256 outputs • Use “your ingenuity” to search for other boundary conditions. • Boundaries are not always so obvious

  10. When to write tests? • “All in all, I think test-first programming is one of the most beneficial software practices to emerge during the past decade…” • Steve McConnell • If you have to write tests eventually anyway, why not write them first so they can be useful longer. • Detect bugs earlier • Think more about requirements • Think more about how others will use your code

  11. Research Results on Tests • Two studies • 80% of errors are found in 20% of the classes • 50% of errors are found in 5% of classes • Most of the cost of a system might be represented by a very small amount of code. • Error prone routines should be redesigned and/or re-implemented

  12. Characterizing Errors • 85% corrected within a single routine • Three most common causes of errors • Thin-domain knowledge • Fluctuating/Conflicting Requirements • Communication/Coordination Breakdown • Almost always the programmer’s fault • Typos/Spelling errors are very common • Three most expensive errors involved the change of a single character • ($1.6 Billion, $900 Million, $245 Million) • Misinterpretation of Design • 85% of errors can be fixed in a few hours • It pays to know where you make errors (personal process) and where your project makes errors

  13. Number of Errors to Expect • Industry average is estimated at 1-25 errors per 1000 lines of code • MS Applications Division gets 10-20/1000 lines in in-house tests: .5/1000 in released code. • Space shuttle claims 0 defects in 500,000 lines of code
