  1. RUP Rational Unified Process Jef Bergsma

  2. De kernbegrippen (Phases) • Iterations • Inception • Elaboration • Construction • Transition

  3. Rup in eenplaatje

  4. - 4 - Requirements Please design and build me a house. I am not quite sure of what I need, so you should use your discretion. My house should have between two and forty-five bedrooms. Just make sure the plans are such that the bedrooms can be easily added or deleted. When you bring the blueprints to me, I will make the final decision of what I want. Also, bring me the cost breakdown for each configuration so that I can arbitrarily pick one. As you design, also keep in mind that I want to keep yearly maintenance costs as low as possible. This should mean the incorporation of extra-cost features like aluminum, vinyl, or composite siding. (If you choose not to specify aluminum, be prepared to explain your decision in detail.) Also, do not worry at this time about acquiring the resources to build the house itself. Your first priority is to develop detailed plans and specifications. Once I approve these plans, however, I would expect the house to be under roof within 48 hours. PPS: Perhaps what I need is not a house at all, but a travel trailer. Please advise me as soon as possible if this is the case.

  5. DezelfdeFunctie, Verschillende product kwaliteiten Functie vs Kwaliteiten

  6. Beschrijven • Wat je bedoelt is niet altijd gelijk aan wat je zegt of schrijft. • Wat je begrijpt is niet altijd gelijk aan wat de ander bedoelt. • 'De nieuwe applicatie moet in ieder geval sneller zijn dan de huidige' • Je kunt alleen realiseren wat in de requirements staat.

  7. Inception Wat willen we weten? • De scope • Oplossing of oplossingsrichting • Eisen en wensen • Risico’s • Globale planning • Werkwijze

  8. Inception

  9. Use Case • The Process Engineer is responsible for defining process models, organize process, and make process available for configuration. • The Project Manager is responsible for creating process instances that can be deployed in their project. • The Practitioner is a user who browses a RUP configuration to view process from a general-purpose vantage point such as to seek process guidance that is related to his/her role, current artifacts, and activities currently being performed
