  1. bbsrc biotechnology and biological sciences research council Approaches to Storing and Querying Structural Information in Botanical Specimen Descriptions. Trevor Paterson The Prometheus Database Project

  2. Prometheus I: A Taxonomic Database (POET OODB) • A novel object-based representation of multiple overlapping taxonomic hierarchies – based on specimen circumscription. • Jessie Kennedy, Cédric Raguenaud, Mark Watson, • Martin Pullan, Mark Newman, Peter Barclay • PI refactor Oracle RDB JK, Gordon Russell, Andrew Cumming • PI Visualisation ToolsJK, Martin Graham • Prometheus II: Capturing Botanical Descriptions for Taxonomy (Oracle RDB) • A novel model for composing and recording taxonomic descriptions, using an ontology of defined terms. • JK, PB, GR, CR, Trevor Paterson, MP, MW, • Sarah McDonald, Kate Armstrong • PII Visualisation and Data Entry Tools • JK, MW, TP, Alan Cannon

  3. ‘Character Descriptions’ in Taxonomy • Characters are central to the taxonomic process they describe specimens, species and higher ‘Taxa’ (groups) • they are the means of recognizing and categorizing diversity (forming taxonomies) • they are a major data output/resource generated from the process • e.g. - for reuse by other taxonomists • - for reuse in other applications • e.g for specimen identification (field guides, keys etc.) e.g. taxon1: petals lanceolate, petal length 5 mm taxon2: petals ovate, petal length 2-4 mm Character 1 Character 2

  4. Consequences • loss of data ( not recorded ) • ambiguous / poorly-defined data • data not comparable between projects Problems with Taxonomic Characters • No formal methodology or model for recognizing and describing Characters • Language (terminology) used in descriptions is ill-defined (natural language based) • A taxonomic revision is often the work of one individual and can be highly idiosyncratic – (lack formalism, personal terminology)

  5. Prometheus System for Taxonomic Description • A standard conceptual model for the composition of character descriptions • Ontologies of defined and related ‘terms’ to record character descriptions • Store description data in electronic/database form

  6. The Prometheus II Character Model Representing Characters as Atomic Statements: Description Elements

  7. The Prometheus II Character Model An Ontology of Defined Terms for Unambiguous Character Description

  8. How do we record ‘which’ structure we are talking about: contextual localisation. • ie how do we unambiguously represent: • a general leaf • a basal leaf • an apical leaf • a leaf on a stem • a leaf on a branch • a leaf that is part of a whorl • or even more complex, how do we represent a region or a substructure on any of these potential leaves

  9. In order to provide a flexible, unambiguous yet non-prescriptive means of localizing structures ... • Our ontology records a PartOf relationship between structures to capture these potential structural relationships • This PartOf relationship is OPTIONAL, i.e. ontologically a leaf might be part of a stem, whorl, branch etc; but a given specimen may only some of these possible structural compositions • Only when a particular structural context is referred to in a description is its reality asserted • The PartOf relationship encompasses any compositional relationship, not only strict part/subpart, but also less clear associations and attachments.

  10. PartOf forms an acyclic, directed graph • Can be materialized as a tree hierarchy (by duplicating structures with more than one potential parent) The PartOf relationship in the ontology specifies all the possible compositional relationships between anatomical structures • a given structure can potentially be PartOf a number of Parent Structures

  11. 288 288.239 288.239.243 288.239.243.51 288.239.243.52 288.239.243.52.51 288.239.243.55 288.239.243.55.51 288.239.243.156 288.239.243.156.51 288.239.243.271 288.239.243.271.51 288.243 288.243.51 288.243.52 288.243.52.51 288.243.55 288.243.55.51 288.243.156 288.243.156.51 288.243.271 288.243.271.51 288 288.239 288.239.243 288.239.243.51 288.239.243.52 288.239.243.52.51 288.239.243.55 288.239.243.55.51 288.239.243.156 288.239.243.156.51 288.239.243.271 288.239.243.271.51 288.243 288.243.51 288.243.52 288.243.52.51 288.243.55 288.243.55.51 288.243.156 288.243.156.51 288.243.271 288.243.271.51 Inflorescence Floret Flower Column Androecium Specifying an exact structural context from the optional Part_Of hierarchy

  12. Software that we are developing for assisting a structured approach to taxonomic description uses the ontological PartOf hierarchy to organize data entry interfaces, for editing and scoring.

  13. The Project Definition Interface (Ontology  Proforma) Central organizing relationship for the ontology – ‘Partof’ hierarchy of structures. (‘Edit’ by filtering or adding necessary regions and generic structures.) Properties applicable to selected structure. (Expand to show states available).

  14. On a Project by Project basis a filtered version of the Ontology can be specified (A ‘Proforma’ Ontology) • where only the structures of interest for a given project are included • and ‘generic structures’ and ‘regions’ are explicitly added to the compositional tree • This then represents a description template or ‘Proforma’ used for a particular project • Therefore the actual structural ‘Paths’ used vary from project to project

  15. ONTOLOGY PROFORMA ONTOLOGY Regions 1 2 3 8 A B D F centre 4 9 1 2 3 E H hair A B D 6 5 10 apex spine 4 I C D E base hair 11 7 12 13 6 5 J K E L lower surface hair C D 13 L 7 14 15 hair upper surface E K E Generic Structures Creating a Proforma Ontology

  16. A Completed Proforma Interface

  17. Yet another level of complexity is added by allowing any structure to be duplicated at the time of project definition ... ... and in fact multiple instances of structures might be required at scoring time to record observations for separate distinguishable instances of the same structure

  18. 1 2 3 A B D ‘Leaf’ #1 [B#1] 4 E 2 3 B D [B#2] ‘Leaf’ #2 4 E 6 5 C D 7 13 E L proforma ontology Representing multiple copies of Structures • Structure B (Leaf) is cloned • The path of the Leafstructures B, D and Ein the proforma ontology has to include its ‘clone’ identity i.e. B#1 or B#2. • We might want to record data for multiple instances of each Leaf, and include an ‘instance’ identity: eg B#1: instance1,2,3...

  19. How can we store/represent (and query!) all this context/path information for structures in a relational database ? • We want to refer to a structure in the context of its parents • We need to take account of differences between project specific versions of the ontology • We need to allow for changes (additions) to the ontology over time • We want to be able to ‘clone’ more than one version of a structure • We want to be able to score multiple instances of the same structure

  20. Given that we are concerned with representing a structure hierarchy….. What do we know about Hierarchical Trees in Relational Databases? • A well-studied problem, various ‘solutions’ • adjacency lists - calculate transitive closure • proprietary tree traversal queries (‘connect by’) • node numbering algorithms – maintenance problems Need an easy and efficient solution • materialize the path – and traverse programmatically • what about XML? - as a native tree representation

  21. Materialized Path 288 288.239 288.239.243 288.239.243.51 288.239.243.52 288.239.243.52.51 288.239.243.55 288.239.243.55.51 288.239.243.156 288.239.243.156.51 288.239.243.271 288.239.243.271.51 288.243 288.243.51 288.243.52 288.243.52.51 288.243.55 288.243.55.51 288.243.156 288.243.156.51 288.243.271 288.243.271.51 ParentID - 1 2 3 3 5 3 7 3 9 3 11 2 13 13 15 13 17 13 19 13 21 NodeID 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 Node Numbering and Materializing the Part_Of hierarchy

  22. Could store a table of paths in the ontology...... ..but heavy maintenance costs with versioning and project additions ..instead could store the actual path with each description statement (Description Element)

  23. intuitively you can represent the whole structural hierarchy as an XML Tree....... XML and Trees ....Again Node numbering algorithms and XML node indexing algorithms exist for XML databases - -still got maintenance problems

  24. Or we can materialize the Path of each node as an XML fragment instead of as a string.. equivalent to the string: 288.239.243 As with the strings – these could be stored as a table of paths for the ontology...... .....or the path can be stored as part of each description Statement (DE)

  25. equivalent to the string 288(1).239(2).243(1)[3] These XML fragments can store more information than a simple string...... Even more data could be added to the XML as attributes - such as Term=“Flower” ParentNodeID=“X” Adding this additional information to a single string path is complex - e.g parsing out the brackets... - could store additional strings, such as: Inflorescence.Floret.Flower

  26. Testing the alternative representations of the Materialized Path for storage and retrieval of Structural Context Information in Plant Character descriptions As dot separated string, parsed programmatically by PL/SQL vs As an XML fragment parsed by Oracle XML database functions [note, because our XML fragment is recursive, it cannot be validated to an acceptable XSD schema to allow Oracle to Shred the XML to relational tables, therefore XML storage is essentially as a CLOB]

  27. (I) Paths stored as strings are in the format: 2270.288.243(2).413.172.423.504 ‘Traversing’ the path encoded in such strings can be achieved by combining various Oracle PL/SQL functions: eg INSTR (searches a string for a substring returning the index i) SUBSTR (returns a substring of length l, from index i, of a string) CONCAT (can concatenate strings and characters) TO_CHAR (allows conversion of integers to strings) These can be combined to write stored PL/SQL functions to automate path traversal: eg getParent (descStructure Number, path varchar2) returns StructureID getParentPath (descStructure Number, path varchar2) returns PathString select getParent (504, ‘2270.288.243(2).413.172.423.504') "Parent" from dual; Parent423 1 row selected

  28. (2) Stored XML Paths are in the format: • <Path nodeID="">> • <Term ID="2270" CloneID="1“> • <Term ID="288" CloneID="1"> • <Term ID="243" CloneID=“2"> • <Term ID="413" CloneID="1"> • <Term ID="172" CloneID="1"> • <Term ID="423" CloneID="1"> • <Term ID="504" CloneID="1“ InstanceID=“1” /> • </Term></Term></Term></Term></Term></Term> • </Path> • Oracle XPath expressions allow traversal up and down the tree in • a single query: • select unique • extractValue(PATH, '//Term[@ID="504"]/..@ID') “504Parent” from DE • where existsnode(PATH, '//Term[@ID="504"]') = 1 • and existsnode(PATH, '//Term[@ID="504"]/Term') = 0 ; • 504Parent 100, 235, 373, 423, 521, 553, 96 7 rows selected.

  29. Two test queries to compare the efficiency of String based query versus XML Query: Simple Query A: Find all information pertaining to Flowers -1st need the ID of Flowers – trivial look up ( ID = ‘243’) - then fetch all DescriptionElements that have flower in their path somewhere more Complex Query B: Find which descriptions have parts with scales [‘504’], and what these parts are:

  30. Simple Query A: Find all information pertaining to Flowers ( ID = ‘243’) (Avi) Using simple string comparison: where DE.structurepath like '%.243.%'(i.e. flower within the path) or DE.structurepath like '%.243(.%'(i.e. a clone of flower in the path) or DE.structurepath like '%.243' (i.e. flower at the end of a path) (Ai &Aii) Using an XPath expression in Oracle's SQL/XML Query language: where existsNode(path, '//Term[@ID="243"]') = 1 (Aiii) Using an XPath expression in OracleText’s 'contains' function (with a path_section index): where contains(path, 'HASPATH(//[@ID="243"])' ) >0 (Aiv & Av) Whilst with xml_section or auto_section indexing the query might resemble: where contains(path, '243 WITHIN TermIDattr') >0 or where contains(path, '243 WITHIN Term@ID') >0

  31. more complex example B: • to find which descriptions have parts with scales [‘504’], • and what these parts are: • we would want to search for: • scale ID being present in the path of a description element • and get the parent of scale [ie a single path traversal] • checking that • if presence has been scored for scale: it is present • that the DE is not marked ‘not scored’ • its necessary to scope the query • eg using ProformaID and OntologyID • could easily add increasing complexity/specificity • eg to look for the same information but only where applies to scales found on Flowers • get paths where flower ID [‘243’] precedes scale ID at any level • [traversal up and down the path]

  32. select distinct * from (select distinct "DescriptionID", "SpecimenID", t.term "Structure Possessing Scales", "Scale State" from (select de.idseq "DE_ID", getparent(504, de.structurepath) "ParentID", d.idseq "DescriptionID", d.specimen "SpecimenID", ('Present') "Scale State" from descriptionelement de, description d, term t, statelist s where (de.structurepath like '%.504.%' or de.structurepath like '%.504(%' or de.structurepath like '%.504') and de.description = d.idseq and de.describedstructure = t.idseq and de.not_scored_flag = 'F' and de.stategroup = 134 and s.de = de.idseq and s.state = 2325 ) x , term t where x."ParentID"=t.idseq ) UNION ( (select distinct "DescriptionID", "SpecimenID", t.term "Structure Possessing Scales", "Scale State" from (select de.idseq "DE_ID", getparent(504, de.structurepath) "ParentID",d.idseq "DescriptionID",d.specimen "SpecimenID", ('Quantitative Score') as "Scale State" from descriptionelement de, description d, term t where (de.structurepath like '%.504.%' or de.structurepath like '%.504(%' or de.structurepath like '%.504') and de.description = d.idseq and de.describedstructure = t.idseq and de.not_scored_flag = 'F' and ( de.stategroup != 134 or de.stategroup is null) ) x , term t where x."ParentID"=t.idseq) );

  33. select * from (( select "DescriptionID", "SpecimenID", t.term "Parent of Scale" , ('Quantitative Score') "ScaleState" from ( select DE.Description "DescriptionID", D.Specimen "SpecimenID", extractValue(PATH, '//Term[@ID="504"]/..@ID') "att" from descriptionelement DE, Description D where existsnode(PATH, '//Term[@ID="504"]') = 1 and existsnode(PATH, '//Term[@ID="504"]/Term') = 0 and DE.not_scored_flag = 'F' and DE.Description = D.idseq and (DE.stategroup is Null or DE.stategroup !=134) ) x, term t where x."att" = t.idseq )UNION ( select "DescriptionID", "SpecimenID", t.term "Parent of Scale" , ('Present') "ScaleState" from ( select DE.Description "DescriptionID", D.Specimen "SpecimenID", extractValue(PATH, '//Term[@ID="504"]/..@ID') "att" from descriptionelement DE, Description D, statelist s where existsnode(PATH, '//Term[@ID="504"]') = 1 and existsnode(PATH, '//Term[@ID="504"]/Term') = 0 and DE.not_scored_flag = 'F' and DE.Description = D.idseq and DE.stategroup =134 and s.de = de.idseq and s.state = 2325 ) x, term t where x."att" = t.idseq ));

  34. -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- DescriptionID SpecimenID Structure Possessing Scale State Scales ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 103 91 Blade Present 103 91 Blade Quantitative Score 103 91 Bract Present 103 91 Bract Quantitative Score 104 92 Bract Present 104 92 Bract Quantitative Score 105 93 Blade Present 105 93 Blade Quantitative Score 106 94 Filament Present 106 94 Nectary Quantitative Score 106 94 Sepal Quantitative Score 106 94 Stipe Present 107 95 Petal Quantitative Score 107 95 Stipe Quantitative Score 108 96 Nectary Present 108 96 Petal Quantitative Score ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 16 rows selected.

  35. Some Conclusions • to represent contextual information in plant descriptions we have stored a materialized representation of the compositional path for each structure being described – either as a delimited string or an XML fragment • our results show that this path is queried most efficiently in our database if stored as a string and queried using string comparison functions • however, storing the materialized path as an XML fragment provides an attractive alternative that allows more straightforward query design and might allow a richer and more readable representation of the information • storage, indexing and query XML datatypes is database dependent, but simple string-parsing functions are provided as part of most database systems • optimization of XML Query and indexing is complicated, although in many respects the syntax of XPath queries allows simpler query formulation than parsing the string path.

  36. www.prometheusdb.org Jessie Kennedy, Cédric Raguenaud, Mark Watson, Martin Pullan, Mark Newman, Peter Barclay, Martin Graham, Gordon Russell, Andrew Cumming, Sarah MacDonald, Kate Armstrong, Alan Cannon, Robert Kukla, Trevor Paterson
