This order sheet is designed for the programming and verification of the MC96F8208S device. Please fill in the required information in the bold fields, including package options, customer details, device specifications, and ROM code size. Ensure to select the appropriate writing options and consider the boot code protection settings. All unused areas must be filled with 0x00, and verification must be completed along with standard checksum. This sheet is essential for accurate programming and quality assurance at the factory.
E N D
FPO ORDER SHEET v1.2 Factory Programming Order & VERIFICATION SHEET MC96F8208S- NHF Please fill in the bold areas. Package Information : D, B, U 1. Customer Information 2. Device Information Company Name Package □ 20 SOP (D) □ 20 PDIP (B) □ 20 QFN (U) □Wafer Chip sales code:( ) Application Order Date YYYY MM DD Tel : Fax : Name & : Signature ROMCode Size 8 K byte 4. Writing Option 3. code file Information □ Enable External RESETB □ Enable Boot code Protection Boot code area ○ 3.8kB (0x100~0xFFF) ○ 1.7kB (0x100~0x7FF) ○ 768B (0x100~0x3FF) ○ 256B (0x100~0x1FF) □ Enable Hard Lock Check Sum File Name .HEX You must fill unused area with 0x00 (Code area : 0000H ~ 1FFFH) (Please check mark info ) 5. CODE Verification 6. Remark Verification Date : Marking : standard Check Sum : Name:
