  1. Chapter 7: 22540 - Computer Arch. & Org. (2) Parallel Computers

  2. Parallelism • Uniprocessor vs. Multiprocessors • Process per Processor  Process-Level Parallelism • Parallel Processing Program (Multithreading) • Multicore vs. Cluster • Single Chip vs. LAN Interconnect

  3. Parallel Processing Program • Amdahl’s Law Exercise: To achieve a speedup of 90 times faster with 100 processors, what percentage of the original computation can be sequential? Execution Time Execution Time Affected Execution After = ──────────────── + Time Improvement Amount of Improvement Unaffected

  4. Scaling • Strong Scaling Speedup achieved on a multiprocessor without increasing the size of the problem. Exercise: Consider sum of 10 scalars (10 sequential additions, Tadd) and sum of two 10 × 10 matrixes (100 parallel additions). What are the speedups for 10 & 100 processors?

  5. Scaling • Weak Scaling Speedup achieved on a multiprocessor while increasing size of the problem proportional to increase in # of processors. Exercise: Consider sum of 10 scalars (10 sequential additions, Tadd) and sum of two 100 × 100 matrixes (10,000 parallel additions). What are the speedups for 10 & 100 processors?

  6. Load Balance • Non Ideal Balance Processors don’t get equal amount of work. Exercise: Consider 10 sequential additions and 10,000 parallel additions using 100 processors. What is the speedup when a processor has 2% of the load instead of 1%? What about 5% of the load?

  7. Shared Memory Multiprocessors (SMP) • Single Physical Address Space • Uniform Memory Access (UMA) • NonuniformMemory Access (NUMA) • Synchronization (Lock) Processor Processor Processor ● ● ● Cache Cache Cache ● ● ● Interconnect I/OController MainMemory

  8. Message-Passing Multiprocessors • Private Physical Address Space • Send-Message & Receive-Message Routines Processor Processor Processor ● ● ● Cache Cache Cache ● ● ● MainMemory MainMemory MainMemory ● ● ● Interconnect I/OController

  9. Multithreading • Hardware Multithreading • Sharing Processor’s Functional Units Among Threads(Switch state from one thread to another when stalled) • Fine-Grained Multithreading • Switching State After Every Instruction • Coarse-Grained Multithreading • Switching State After a Cache Miss • Simultaneous Multithreading (SMT) • Multiple-Issue, Dynamically Scheduled Processor(Exploits thread-level & instruction-level parallelism)

  10. SISD, MIMD, SIMD, SPMD • Single-Instruction Single-Data • Uniprocessor • Multiple-Instruction Multiple-Data • Multiprocessor • Single-Instruction Multiple-Data • Vector/Array Processor (Data-Level Parallelism) • Single-Program Multiple-Data • Different Code Sections Execute in Parallel (MIMD)

  11. Chapter 7 The End
