  1. Cool Programs in Prolog CS 581 02/28/05 Flora Tan

  2. A Graph Example • A connected graph. • Vertices 1, 2, 3, 4, 5. • Edges are the connecting lines. • Find all paths between any two vertices. • Easy to implement in Prolog.

  3. Prolog • List the edges as facts. edge(1,2). edge(1,3). edge(1,4). edge(2,3). edge(2,5). edge(3,4). edge(3,5). edge(4,5).

  4. Prolog • Add the rules. Options: • The edges are bi-directional. We could list out another eight edges as facts. Ex: edge(2,1), edge(3,1), edge(3,2), edge(4,1), edge(4,3), edge(5,2), edge(5,3), edge(5,4) • Use disjunction. connected(X,Y) :- edge(X,Y) ; edge(Y,X).

  5. Prolog • Add the rules. Options (continue): • Alternatively, we could write this as two rules. connected(X,Y) :- edge(X,Y). connected(X,Y) :- edge(Y,X). • But we don’t want to do this. An infinite loop. edge(X,Y) :- edge(Y,X).

  6. The rest of the code. path(A,B,Path) :- travel(A,B,[A],Q), reverse(Q,Path). travel(A,B,P,[B|P]) :- connected(A,B). travel(A,B,Visited,Path) :- connected(A,C), C \== B, not(member(C,Visited)), travel(C,B,[C|Visited],Path). Note the following: Conjunction Goal matching Recursive search List processing – reverse, member Accumulator Prolog

  7. Base case travel(A,B,P,[B|P]) :- connected(A,B). Inductive case travel(A,B,Visited,Path) :- connected(A,C), C \== B, not(member(C,Visited)), travel(C,B,[C|Visited],Path). A path from A to B is obtained if A and B are connected. A path from A to B is obtained provided that A is connected to a vertex C different from B that is not on the previously visited part of the path, and one continues finding a path from C to B. Prolog

  8. Running the program • Load the program into SWI-Prolog ?- [swi('demo/test')]. • Run the program. ?- path(1,5,P). P = [1, 2, 5] ; P = [1, 2, 3, 5] ; P = [1, 2, 3, 4, 5] ; P = [1, 4, 5] ; P = [1, 4, 3, 5] ;

  9. Continue • The paths. P = [1, 4, 3, 2, 5] ; P = [1, 3, 5] ; P = [1, 3, 4, 5] ; P = [1, 3, 2, 5] ;

  10. Why is this cool? • Graph search algorithms uses DFS/BFS and Adjacency List/Adjacency Matrix. • Prolog uses Depth First Search. • Other graphs examples: searching a maze, Dijkstra’s algorithm, graph coloring. • Coding in C is about 300 lines because we have to implement our own DFS and Adjacency List/Matrix.

  11. Adjacency List – an array of pointers to linked lists 1 -> 2 -> 3 -> 4 2 -> 1 -> 3 -> 5 3 -> 1 -> 4 -> 5 4 -> 1 -> 3 -> 5 5 -> 2 -> 3 -> 4 Adjacency Matrix – a 2D array of integers 1 2 3 4 5 1 0 1 1 1 0 2 1 0 1 0 1 3 1 0 0 1 1 4 1 0 1 0 1 5 0 1 1 1 0 Adjacency List / Matrix

  12. References • Programming in Prolog by W. F. Clocksin and C. S. Mellish. • Prolog tutorial • http://www.csupomona.edu/~jrfisher/www/prolog_tutorial/2_15.html
