Green Products Patricia Anna Buling
Overview: • ToppsProducts • HydroBallTechnics • MonoDraught • MacroAir
Topps Products • For whenit’s not a new roof youneed, but a better roof
SystemInformation • Specializes in: • Metal, Asphalt, EPDM, Hypalon, Concrete, Polyurethane, Transite
Product Information • Roof Coatings • ToppsSeal – Base Coat • ToppsSeal – Standard Grade • ToppsSeal – PF
Product Information • Roof Repair • PolyCore • PolyPrene • RivetGuard
Product Information • ProductsAvailable • Surface Prep • Rust Arrestor • Wall Treatment • Reflex Wall Coating
Product Comparison Ability to move with your roof and relative resistance to cracking Ability to hold together and avoid breaking Resistance to moisture passing through the coating; lower number shows greater moisture resistance Capacity to absorb water vs protect Comparitive ability of the coating system to remain adhered to roof surface under adverse conditions Higher tear strength, greater resistance to withstand minor defects caused after installation, eg. roof movement and foot traffic
Why TOPPS? • EnergySavings • Greater Roof/Wall Service • Weatherproof • Better for the environment Before After
Awards & Certificates The Enterprise Challenge (TEC) Award SGBC Green Building Product Certification ISO14001 Certification HydroBall is the only ATC company in South East Asia to obtain ISO accreditation for its Environmental Management Systems TEC Award is Singapore’s most prestigious award, presented by The Prime Minister Office The Green Building Product Certification by Singapore Green Building Council is the only globally-recognized certification for ATC systems in the world today; HydroBall System is the only brand certified in the “LEADER” Category with maximum of “4-ticks”
ElectricityConsumption Target for Conservation Chillers use at least 35% of electricity consumption! 59% x 60% = 35.4% Biggest potential for energy conservation
ProvenTechnology Chiller without HydroBall System Chiller with HydroBall System
ProvenTechnology 0.934 0.762 = 18.4 % Savings =
Hydroball Systems SS 553 published Dec 09 Spring Singapore Board • Ball Technics • Simplified solution compared to Taprogge • Over 1.7K installations • Established 1989 • Taprogge GmbH • Pioneered sponge ball • for cleaning in 1954 • - Over 12K installations • CQM • Over 2.2K installations • Most promising Israeli Cleantech coy (2007) • Established 1994 WSA - Brush type systems BrandComparison Absence of prime movers (eg. motorized pumps & compressors) Able to withstand High Pressure (Above 20 bars) Little or No Water Wastage HVS Engineering - Established in 2004 NC ZONE Maintainability (ie. high mean-time between servicing) Durable and corrosion resistant Non-mixing of Fluids (esp. between condenser in and out water)
WhyHydroBall? • Totally non-powered • No mixing of hot and cold water in condenser • No loss of water • Totally effective against particulate fouling • Does not affect normal • chiller operations • GUARANTEED PERFORMANCE
MonoDraught • SunPipe Natural Daylight System
Range of Systems • Diamond Dome Sunpipe • Conservation Sunpipe • Square Sunpipe • Square Ceiling Diffuser
Suitable Applications • Commercial
SuitableApplications • Commercial
SuitableApplications • Residential
Roof Applications Flat Felt Roof; Slate Roof; Tiled Roof; Bold Rolled Tile Roof; Green Roof; Thatched Roof
Accessories: Light Control • Light Kit • Black-out diffuser with magnetic pads • Motorised light shut off dampers
Accessories: Fire & Sound Control • Fire Choke Collar • Fire Guard Diffusers • Acoustic • Diffuser
Accessories: Security • Security grillage • Security fixings • Chemical fixings • Anti-ligature • diffusers
MacroAir Fans AIRVOLUTION – quiet and comfortable airflow. available from 8 to 24 feet in diameter AIRSPAN – higher velocities for cooling larger spaces. available in 20 and 24 foot diameters AIRSOL – the original solar-powered HVLS fan. costs nothing to run. available from 16 to 20 feet in diameter AIRECO – the original HVLS guard fan. can be mounted to a pole, wall, or ceiling. 6 feet in diameter AIRSTAR – when looks are as important as airflow. available from 8 to 20 feet in diameter and ideal for commercial and custom residential applications
AIRVOLUTION • 8 – 24 feet in diameter • 53,623 - 275,694 CFM • Operates quietly • 1.0 HP motor • Energy-efficient • Creates a comfortable environment while delivering substantial cost
AIRSPAN • 20 or 24 feet in diameter • 237,231 – 376,804 CFM • Covers up to 20,000 sqft • 1.5 HP (20 FT model) and 2.0 HP (24 FT model) • Energy-efficient • Our largest, highest output fan and the ideal solution for • industrial, warehouse, and commercial spaces
AIRSOL • 100% solar-powered • 16 to 20 feet in diameter • 115,332 – 151,030 CFM • Optional auxiliary backup power supply • Costs nothing to run • Highest CFM per watt fan combined with solar technology
AIRSTAR • 8 to 20 feet in diameter • 32,032 – 151,030 CFM • Sleek design • Functions quietly • Energy-efficient • Perfect for when design is as important as airflow
AIRECO • 6 feet in diameter • 28,035 CFM • Available with or without a guard • Mounts to walls, poles, and ceilings • Runs 8 hours for only 25 cents • Can be used anywhere that a small, powerful fan is • needed -indoors or out
FanSpecifications UMH (Universal Mounting Hardware) Frame Motor Gearbox Safety Retainer Locks Blade Assembly
Safety MacroAir’sPatented Interlocking Safety System
Safety • Guy wires ensure stability and reduce the load on the center mount, substantially reducing safety risks
Why MacroAir? • Reduce A/C Costs • Avoid condensation and mold issues • AMCA Certified – the only HVLS fan manufacturer with an external certification • Tested fan performance
