MOOD LIGHT PCB ASSEMBLY

MOOD LIGHT PCB ASSEMBLY. V.2.2 - By Phil Townshend 2008. ASSEMBLING THE PCB. Hold up the PCB as shown below – try to locate the holes shown. RESISTORS. The first component is a resistor value 1Kohm, (brown, black, red). It is not important which way round it goes. RESISTORS.
