  1. Conference - 2002 APPX Release 4.1

  2. APPX 4.1 is the single, most significant release in the history of the product! APPX Release 4.1

  3. Three Major Areas of Focus • GUI Design by Specification • RDBMS Enhancements • Performance APPX Release 4.1

  4. OS Requirements • HPUX 11 • AIX 4.3.3 • Solaris 8 • Windows NT 4 SP6 • Windows 2000 • Red Hat Linux 6.2 • SCO 5.0.4p • NCR SVR4 MP RAS 03.02.00.39 • OS400 5.1 APPX Release 4.1

  5. RDBMS Requirements • Oracle 7, 8 • Sybase 12 • DB2 6.1 (Windows NT/2000) • DB2 7.1 (Unix) • SQL Server 2000 • Access 2000 APPX Release 4.1

  6. Upgrade Considerations... • OS Release • RDBMS Release • Data files are compatible • Design files changed • Design files cannot be downgraded APPX Release 4.1

  7. FREE Features in APPX 4.1!!! • APPX Reportwriter (SQL) • APPX Client (GUI) • APPX/ODBC Driver • Language Translation • Four sessions per user • Web Interface to APPX Backend • APPX Client in a Browser • APPX/Net APPX Release 4.1

  8. Only Four Chargeable Items!!! • User Rights • Designer Rights • RDBMS Interfaces • Maintenance • Software Updates • Tech Support APPX Release 4.1

  9. GUI Design by Specification • Menu processes • Input processes APPX Release 4.1

  10. GUI Demo Application • Included with APPX 4.1 • Application DMO 00 • Database DMO • Requires APPX GUI Client APPX Release 4.1

  11. GUI Menus/Inputs • Title Bar • Wallpaper/Background Color • Pull-down Menus • Toolbar buttons • Right-Click Menu • Buttons • Frames • Labels • Pictures • Fields APPX Release 4.1

  12. Title Bar Attributes • Title bar Color • Title Text • Text Alignment (Left/Right/Center) • Text Font/Scaling/Style/Color • Resource (Icon) • Buttons (Help/Return/End) APPX Release 4.1

  13. Window Attributes • Resource (Wallpaper) • Background Color • Border Style • Border Color APPX Release 4.1

  14. Pull-Down/Right-Click Menus • Defined as GUI Attributes of Optional Children • Multiple pull-down menus • Multiple pullout menus • Menu Item Resource (Icon) • Menu Item Icon location (Left/Right of text) • Shortcut keys • Menu Item Text (Font/Scaling/Style/Color) • Menu Item Background color APPX Release 4.1

  15. Pull-Down/Right-Click Menus • Separator Lines (Before/After) • Invisible? • Enabled? • Menu Item Tooltips APPX Release 4.1

  16. Named Resources • Isolate graphics from application • Different graphic for each “state” • Identifies graphic location type • Server • Client • Identifies graphic location • Pathname • url APPX Release 4.1

  17. Named Resources • Graphic formats supported • GIF • Animated GIF • JPEG • BMP APPX Release 4.1

  18. Cached Files • Stored in memory • Implemented via ILF statements • CREATE • SCRATCH • OPEN • Possible uses • Increase runtime performance • Constrained Scans • Temporary copy of disk file APPX Release 4.1

  19. Desktop Integration via the APPX Client • Client-side printing • Send file to client • Retrieve file from client • Run a “document” on client • Run a program on client APPX Release 4.1

  20. File Level Event Points • Triggered by file I/O • Defined as “rules” for a file • File Open • Post Read • Pre Update • Post Update • File Close APPX Release 4.1

  21. File Level Event Points • Possible uses • Enforcing referential Integrity between files • Key change • Delete related records • Updates to related files APPX Release 4.1

  22. APPXIO • Support for variable length records • Support for compressed records • Save disk space • Quick restructures • Support for larger file sizes • Up to 4GB for Unix • Up to 2GB for Windows APPX Release 4.1

  23. “Fast” Queries • “Automatic” Fast Queries • Query record selection will use indexes • APPX will pick the “best” index to use • Designer can supply “hints” • BEG AT • END AT • APPX will skip the sort if possible • APPX will sort in memory if possible • APPX_RUN_MEM • APPX_DISK_SORT_THRESHOLD APPX Release 4.1

  24. “Fast” Queries • “Designed” fast queries • Optimize complex selection logic • New event point • ESTABLISH PCF RANGE • New subroutine • PROCESS QUERY RECORD APPX Release 4.1

  25. “True” Subroutines • ILF Statements • PASS statement enhanced • RECEIVE statement implemented • Use with • GOSUB • Process invocation ILF statements • Automatic/Optional child processes • Nested subroutine “calls” supported APPX Release 4.1

  26. “True” Subroutines • PASS Statement • Pass arguments to “subroutines” • Returned results from “subroutines” • RECEIVE Statement • Receive arguments • Automatic data type conversion • Localize variables APPX Release 4.1

  27. RDBMS Interfaces • Major rewrite of RDBMS interfaces • Significantly improved performance • Major new features • Support for more databases APPX Release 4.1

  28. RDBMS Interfaces • Significantly improved performance • Quick restructures • Use ALTER TABLE when possible • Faster record I/O • SQL Statement Caching • Retrieve rows by Row ID • Partial Record I/O • Cached Files APPX Release 4.1

  29. RDBMS Interfaces • Major new features • Commit • COMMIT statement • Process Commit Mode • Compatibility • PCF Cycle • End • Manual • Rollback • ROLLBACK statement • SAVE PNT statement APPX Release 4.1

  30. RDBMS Interfaces • Major new features • Field Overrides when creating tables • Field Name • Field Type • Nullability • Table Sizing when creating table • FMS Group enhanced • Better data type conversions APPX Release 4.1

  31. RDBMS Interfaces • Support for more databases • Oracle • ODBC for Windows • MS SQL Server • MS Access • DB2 (Beta status) • Sybase (Beta status) • ODBC for Unix/Linux (Beta status) APPX Release 4.1

  32. RDBMS Interfaces • FMS Groups • Replaced control strings with specifications • Added Table sizing options • Added a few RDBMS runtime options • Added Identities for remote logins • User IDs • Passwords APPX Release 4.1
