Assembly & Machine Languages

1. Assembly & Machine Languages CSCI130 Instructor: Dr. Lynn Ziegler

2. LAYER Order High-order P.L.: Visual Basic 1 System SW: O.S. 3 Data Representation 5 Layered Architecture

3. Higher-level Programming Languages • (3GL) High-level languages are in the middle • Use English-like phrases and mathematical notation • x = x+1; • A limited vocabulary with precise meaning • Make us think at a higher-level of abstraction • Noattention to technical and hardware details • Like O.S. • Much larger instruction set for programmers • Multiplication

4. Higher-level Programming Languages (PLs) • (1GL) Machine language programming • limited set of instructions • binary numbers: • opcodes, absolute memory addresses and data • Memory addresses • (2GL) Assembly language • English mnemonics for binary opcodes • Decimal data • Labels for memory addresses and variables • limited instruction set • Use human languages to program • Largevocabulary (space and time to search) … opcode lookup • 500,000 words - 1,000,000 words (including scientific words) • Synonyms • Context

5. CPU - Connects to main memory (MM) thru abus - Bus = bundle of wires - Transfers data between CPU and memory - Width of bus determines speed - e.g. 32-bit bus (Higher  faster) - Where is data stored when copied to CPU?

6. CPU • Divided into CU and ALU • CU (Control Unit) • Orchestra organizer • Oversees transfer of data between MM and CPU • Accesses info in ROM (e.g. during reboot) • Has abunch of memory registers • ALU (Arithmetic Logic Unit) • Contains circuits to do computations • Built for each basic/hardwired operation (+,-, x, /, =,>,<, NOT) • Includes a special register accumulator AC to hold results

7. The History of Computing • ENIAC (February 14, 1946) • weighed over 30 tons, and consumed 200 kilowatts of electrical power

8. An ALU in 1957 • This was an arithmetic unit you sit back and admire. It was part of Honeywell's Datamatic 1000 computer. (Image courtesy of Honeywell, Inc.)

11. Modern CPUs

12. Programs & Algorithms • Characteristics of an algorithm: • List of steps to complete a task • Each step is PRECISELY defined and is suitable for the machine used • Increase the value of X • Jump! • Add 5 to variable X • The process terminates in a finite amount of time • No infinite loops • Written in an English-like language (Pseudocode)

13. Programs & Algorithms • Program: A formal representation of a method for performing some task • Written in a programming language understood by a computer • Detailed and very well-organized (computers just do what they are told) • Follows an algorithm … method for fulfilling the task • Plan to do something VS the actual performance

14. Combining Limited Instructions • Computing an answer to an equation: • 5*3 + 62 – 7 • Assume our computer can’t directly multiply, subtract, or raise to power • Multiplication task: • 1: Get 1st number, Number_1 • 2: Get 2nd number, Number_2 • 3: Answer = 0 • 4: Add Number_1 to Answer • 5: Subtract 1 from Number_2 • 6: if Number_2>0, go to step 4 • 7: Stop

15. Assembly Language • Machine code consists of the • binary instructions, data & addresses • can directly be executed by the CPU • We as humans are not good in working with sequences of 1’s and 0’s • We prefer to use an English-like style(English mnemonics and decimal numbers) • This is called the assembly language • It has 1-to-1 correspondence to machine code • one instruction for every 3-bit Opcode and decimal numbers for addresses and data • Slight other changes

16. Assembly Language • Additional problems addressed: • Most commands like LOAD, STOR, JUMP and ADD require memory addresses • How do we know which address in memory is free to use? • We also assumed that PC will contain 0 initially • Our program will be loaded to first memory location…is this always true? • What if we have multiple executing programs on the same machine? • Which will get the 0 address then?

17. Assembly Language • In reality, when we program, we don’t concern ourselves with such low level details This is handled by the operating system. • From now on, we use variables/labels instead of addresses and totally forget about memory • 110 10010  ADD Counter which must initialized

18. 0 clock 16-3000 MHz (~3.0 GHz)

19. Assembly Language of a Computer

20. Simple VB-like program 1 • Private Sub cmdSimple () • Dim X As Integer • X = inputbox(…) • Msgbox x • End Sub • READ • STOR X • LOAD X • WRITE • HALT • X: 0

21. Simple VB-like program 2 • Private Sub cmdSimple () • Dim X As Integer • X = inputbox(…) • If X>0 then • Msgbox x • End If • End Sub

22. Assembly Version for program 2 • READ • STOR X • LOAD X • JPOS Disp • HALT • Disp: WRITE • HALT • X: 0

23. Simple VB-like program 3 • Private Sub cmdSimple () • Dim X As Integer • Dim Y As Integer • Y = 0 • X = inputbox(…) • If X>0 then • Msgbox x • Else • Msgbox y • End If • End Sub

24. Assembly Version for program 3 • READ • STOR X • LOAD X • JPOS Disp • LOAD Y • WRITE • HALT • Disp: WRITE • HALT • X: 0 • Y: 0

25. VB-like program 4 • Private Sub cmdSimple () • Dim X As Integer • Dim Y As Integer • Dim Z As Integer • X = inputbox(…) • Y = inputbox(…) • Z = 0 • If X>Y then • Msgbox X • ElseIf X=Y then • Msgbox Z • Else • Msgbox Y • End If • End Sub

26. Assembly Version for program 4 • READ • STOR X • READ • STOR Y • LOAD X • SUB Y • JPOS MaxX • JZER Equal • LOAD Y • WRITE • HALT • MaxX: LOAD X • WRITE • HALT • Equal: LOAD Z • WRITE • HALT • X: 0 • Y: 0 • Z: 0

27. VB-like program 5 • Private Sub cmdSimple () • Dim Sum As Integer • Dim N As Integer • N = inputbox(…) • Do • Sum = Sum + N • N = N -1 • Loop While N>0 • Msgbox Sum • End Sub

28. Assembly Version for program 5 • READ • STOR N • Loop: LOAD Sum • ADD N • STOR Sum • LOAD N • SUB One • STOR N • JPos Loop • LOAD Sum • WRITE • HALT • Sum:0 • N: 0 • One:1

29. VB-like program 6 • Private Sub cmdSimple () • Dim Sum As Integer • Dim N1 As Integer • Dim N2 As Integer • N1 = inputbox(…) • N2 = inputbox(…) • Do • Sum = Sum + N2 • N2 = N2 -1 • Loop While N2>=N1 • Msgbox Sum • End Sub

30. Assembly Version for program 6 • READ • STOR N1 • READ • STOR N2 • Loop: LOAD Sum • ADD N2 • STOR Sum • LOAD N2 • SUB One • STOR N2 SUB N1 JPOS Loop JZER Loop LOAD Sum WRITE HALT Sum:0 N1: 0 N2: 0 One:1

31. VB-like program 6 • Program to print a 1 if an input number is even (multiple of 2) and 0 otherwise • Try it out in SimHymn: http://www.csbsju.edu/Computer-Science/Useful-Links/Launch-CS-Applications.htm VB-like: Dim Sum As Integer Dim N As Integer N = InputBox(…) Do N = N - 2 Loop While N > 0 VB-like: If N = 0 Then MsgBox 1 Else MsgBox 0 End If

32. READ • STOR N • LOOP: LOAD N SUB Dec STOR N JPOS Loop JZER Even LOAD Zero WRITE HALT • Even: LOAD One WRITE HALT • Dec: 2 • N: 0 • One: 1 • Zero: 0

33. A Simple 8-bit Computer • Use a simplified version of real computers to understand machine language programs • 32 8-bit main memory registers • 5 bits (25 registers)to represent an address • 00000 to 11111 • PC holds memory addresses 5-bit PC • For simplicity, assume only positive and negative integers (2’s complement notation) • 8-bit AC

34. 0 clock 16-3000 MHz (~3.0 GHz)

35. A Simple 8-bit Computer • Two 1-bit flags • zflag: 1 if AC zero, 0 otherwise • pflag: 1 is AC is positive, 0 otherwise • ALU supports the following basic operations • Addition, subtraction, if AC=0, if AC>0 • 8 instructions (next slide) • 3 bits (8 instructions) • 000 to 111 • 8 bits per memory location  rest 5 bits of the instruction contain the address of the input data to the instruction • III AAAAA • 8-bit IR • Memory holds 8-bit data or instructions

36. The Machine Language • Instruction set depending on CPU • Hardwired • Binary code for each instruction (Opcode) • Different CPUs might have different operations for which circuits exit in the ALU • Programs can only use those opcodes • The set of all opcodes (i.e. instructions) together is known as the machine language

37. Assembly Language • Computers can only understand machine code • Programs written in assembly must be translated to machine code to be executable by CPU • The assembler is responsible for that • Stored in memory and executed before any assembly program can be executed • (english-like) assembly source code  (binary) machine code • Does a lookup for each word (Opcodes) • Other things (find empty memory locations for my variables) • The result is called object code

38. Machine Language of a Computer

39. A Simple 8-bit Computer • Input/Output (from user perspective) • LOAD 30: 100 11110  register 30 in memory is designated as an input cell • A LOAD with address 30 causes machine to access an input device • The user is asked to provide an input (input box) • Program waits/pauses meanwhile • The input is saved in address 30 and loaded to AC • STOR 31: 100 11111  register 31 in memory is designated as an output cell • The contents of AC is saved in address 31 • Machine also copies data to output device • User sees the output on his/her screen (message box)

40. VB-like program 6 • Private Sub cmdSimple () • Dim Sum As Integer • Dim N1 As Integer • Dim N2 As Integer • N1 = inputbox(…) • N2 = inputbox(…) • Do • Sum = Sum + N2 • N2 = N2 -1 • Loop While N2>=N1 • Msgbox Sum • End Sub

41. Assembly Version for program 6 • READ • STOR N1 • READ • STOR N2 • Loop: LOAD Sum • ADD N2 • STOR Sum • LOAD N2 • SUB One • STOR N2 SUB N1 JPOS Loop JZER Loop LOAD Sum WRITE HALT Sum:0 N1: 0 N2: 0 One:1

42. Machine-like Version for program 6 • 0: LOAD 30(10011110) • 1: STOR 17(10101001) • 2: LOAD 30(10011110) • 3: STOR 18(10101010) • 4: LOAD 16(10001000) • 5: ADD 18(11001010) • 6: STOR 16(10101000) • 7: LOAD 16(10001000) • 8: SUB 19(11101011) • 9: STOR 16(10101000) 10: SUB 17(11101001) 11: JPOS 4(01100100) 12: JZER 4(01000100) 13: LOAD 16(10001000) 14: STOR 31(10111111) 15: HALT(00000000) 16: 0(00000000) 17: 0(00000000) 18: 0(00000000) 19: 1(00000001)

43. Von Neumann Machine • Will see how hardwired operations are accomplished later one • Comparison and addition • Build up other operations/tasks using those basic/hardwired operations ones • Programmed operations

44. Fetch-Execute Cycle • Programs are made up of instructions • Fetch-Decode-Execute • CU supervises the fetch-execute cycle • Fetches one instruction from memory • Decodesinstruction • Increments PC • Executes instruction

45. Fetch-Execute Cycle • To supervise the fetch-execute cycle, the CU has two registers • PC (program counter) • Contains the address of the next instruction in memory to fetch • Initially points to first instruction of a program • After fetching an instruction, it is incremented by one unless there is a jump to some other instruction • IR (instruction register) • Holds the current instruction • Also has a timing clock • Clock chip that generates a steady stream of electric pulses • At every pulse, the CPU proceeds by one step • Fetch, send data to ALU, etc … • Higher frequency clocks result in faster computers • 16-3000 MHz (~3.0 GHz)
