Electrostatics

Electrostatics, also known as static electricity, focuses on charges at rest and involves two basic types of charge: positive and negative. In most situations, only negative charges can move. Neutral objects display equal amounts of positive and negative charges, leading to no net electric force. Key concepts include electric forces, which can attract or repel charges, the law of conservation of charge, and methods of charging such as friction, conduction, and induction. Understanding these principles helps us grasp how charges interact and the role of grounding in electrical systems.

prince
Télécharger la présentation

Electrostatics

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Electrostatics

  2. Electrostatics: the study of charges at rest. • AKA static electricity

  3. 2 types of charge: + and – • In the majority of cases, only the negative charges are mobile. • Neutral: equal amnts of + and – charge. No net electric force.

  4. Electric Force • Non-contact force • Opposite charges attract, like charges repel.

  5. Attractive forces lead one to conclude that at least one object is charged. • Repulsive forces provide convincing evidence that both objects must be charged.

  6. Polarization: the process of separating opposite charges in an object. (Creating poles)

  7. Law of Conservation of Charge • The total charge (difference between + and – charge) within an isolated system is always constant. • Charge can’t magically appear or disappear.

  8. Charging by friction • Ex: shuffling across the carpet in socks. • Outer electrons are the least strongly bound and most easily shed. • Different materials have different affinities (desire, love) for electrons. • When in contact, one material may give up some of its electrons to the other. • Depends on the materials.

  9. Insulators: hold on to outer e- • Conductors: weak hold on outer e-. Allow charges to flow freely

  10. Charging by Conduction • Involves touching a charged object to a neutral object, thereby transferring some charge. • Charge will spread out uniformly onto the second object.

  11. A + charged object brought into contact with something neutral will take e- away from that object, leaving both as a + charge. • Only e- are transferred.

  12. Charging by Induction • A method used to charge an object without actually touching it to any charged object.

  13. Ground: a large object that serves as an infinite source of e- or an e- sink. • Usually the Earth. • Grounding something allows excess charge to flow into the Earth.
