  1. Intel Ultimate Engineering ExperienceBuild an App

  2. Team • Ashish Amresh • Asst. Professor, College of Technology and Innovation, ASU • Game Design • Software Design • Ryan Scott • Senior Computer Science, ASU • Game Development, App Development • Glenn Craver • Senior Computer Science, ASU • Game Development, App Development

  3. Snapshot

  4. Today

  5. Introduction • Objectives • Learn programming with C# • Learn to use XNA platform • Learn how to develop simple Apps • What should you know • How to use a computer • Ability and open mind to learn new tools and technologies • What do you need (working at home) • http://creators.xna.com/Resources/Essentials.aspx • You'll need XNA Game Studio Express(GSE), Visual C# Express Edition, and DirectX Software Development Kit(DirectX SDK). • A simple paint program: http://www.getpaint.net/index.html

  6. Learning C# • What programming language is the best? • Python, C#, Java, C++ • Language differences • Native vs. Managed • Why C# • Managed code • Easy to learn • Object-oriented • Technical Requirements • 32 or 64 bit • Single or multi-core

  7. How does a Computer Work Hard Drive • Data Storage / shelf • Read and write • Memory (RAM) • Shopping cart • Temporary storage for all our actions • CPU • Checkout machine • Faster the processor the more it can crunch out • Motherboard • Floor / store layout • Good motherboard is necessary to maintain good flow between all components • Output/Graphics Card/Input • Peripherals or accessories, access data and display it

  8. Visual Studio: Hello world • First open Visual Studio 2008 and you will see a start page • Go to File -> New Project -> Visual C# ->"Console application“ • Name it Tutorial1

  9. Visual Studio: Hello World • Learning the basics of a program • using System; • usingSystem.Collections.Generic; • usingSystem.Text; • namespace Tutorial1 • { • classProgram •     {        • staticvoid Main(string[] args) •         { •         } •     } • } • The first thing you might notice is the different colors.  Dark blue signifies a code/command that C# recognizes.  Light blue indicates a class, while the regular text is for user defined names.

  10. Visual Studio: Hello World • Program Components • Namespace • Synonymous with a windows folder, a collection of classes used for grouping • Class • Class is a more specific collection than namespace, it holds methods and variables. In C# everything we deal with resides in some class • Methods and Main • Methods are the work horses that do all the crunching of data for your class. The main is a specialized method that is run as soon as a program starts. • Scope • The scope of a namespace, class or method is defined by the { }. It is important to know while programming which scope you are dealing with • Using Statements • Using statements are useful to call other namespaces, so you can bring in additional features that you need into your program.

  11. Visual Studio: Hello World namespace Tutorial1 { classProgram     {        staticvoid Main(string[] args)         { Console.WriteLine("Hello World!"); Console.ReadLine();         }     } } • Our first program: • type this inside of the Main() scope • Console.WriteLine("Hello World!"); • Console.ReadLine();

  12. Learning C#: Variables namespace Tutorial1 {     class Program     {         static void Main(string[] args)         { intherohitpoints;             string myname; boolisalive;         }     } } • Types • Numbers • Int • Float • Double • Char • Unicode • String • Set of unicodes • Bool • True or false • Void

  13. Learning C#: Variables • Declaration and Assignment

  14. Learning C#: Variables String yourName BoolisBlack BoolisActive Int DNA Int _hitPoints Intmax_number • Naming Conventions • Use nouns • Bools can have verbs • Do not capitalize the first letter • Be descriptive • Do not abbreviate • Do not use prefixes or suffixes

  15. Learning C#: Operations namespace Tutorial1 {     class Program     {                static void Main(string[] args)         {             double x, y;             x = 30.0;             y = 3.5; Console.WriteLine(x % y); Console.ReadLine();         }     } } • Operators • + • - • * • / • % (modulus) 5%2 =1 or 30 % 3.5 = 2

  16. Learning C#: Operations • Operator shorthand • X += Y is equal to X = X+Y • X -= Y is equal to X = X - Y • X *= Y is equal to X = X * Y • X /= Y is equal to X = X / Y • X++    is equal to X = X +1 • X- -is equal to X = X -1 • Debugging • Use the short hand, and use the Debugger to step in to the code by setting break points. • Runtime vs. buildtime errors

  17. Learning C#: Using Variables/operations

  18. Learning C#: Conditionals • Operators • < is less than • > is greater than • <= is less than or equal to • >= is greater than or equal to • == is equal to • != is not equal to • && logical “and” • ||logical “or” Example:  ((X>3)&&(X<6)) hitPoints == 3

  19. Learning c#: Loops • do/while loop

  20. Learning c#: Conditionals • The "if" Statement •  static void Main(string[] args) •         { • int x; •             x=20; •             if (x > 0) •             { •                 x -= 1; • Console.WriteLine(x); •             } •         }

  21. Learning c#: Conditionals • The "if" Statement

  22. Learning C#: conditionals Console.WriteLine("Your favorite color is blue");                     break;                 case "Red":                 case "red": Console.WriteLine("Your favorite color is red");                     break;                 case "purple":                 case "Purple": Console.WriteLine("Your favorite color is purple");                     break;                 case "1": Console.WriteLine("You were supposed to pick a color");                     break;                 default: Console.WriteLine("Your favorite color isn't on my list.");                     break;             } Console.ReadLine();         } • Switch Statement • static void Main(string[] args) •         { •             string favoriteColor; • Console.WriteLine("What if your favorite color?"); •             //Incase you were wondering the next statement is reading whatever •             //is typed and assigning it to favorite color when enter is pressed • favoritecolor = Console.ReadLine(); •             //Just so you know I always type my cases and breaks prior to typing code. •             //It just seems easier to me. Do whatever you like though •             switch (favoriteColor) •             { •                 case "blue": •                 case "Blue":

  23. Learning C#: Loops • For Loop • namespace Tutorial1 • { •     class Program •     { •         static void Main(string[] args) •         { •             for (inti = 0; i < 10; i++) •             { • Console.WriteLine(i); •             } • Console.ReadLine(); •         } •     } • }

  24. Learning C#: Simple Calculator • Task: • Using loops and conditional statements create a simple calculator application that will take command line inputs and operations (+ - * / %) and process the output. • The flow of the calculator will be as follows: • Enter the first number • Enter the operation • Enter the second number • Write the answer • Ask if you would like to calculate another set of numbers

  25. Learning c#: Simple calculator • { • case"+": • Console.WriteLine(number1 + number2); • break; • case"-": • Console.WriteLine(number1 - number2); • break; • case"*": • Console.WriteLine(number1 * number2); • break; • case"/": • Console.WriteLine(number1 / number2); • break; • case"%": • Console.WriteLine(number1 % number2); • break; • default: • Console.WriteLine("I'm sorry, that wasn't a valid choice"); • break; •                 } • Console.WriteLine("Do you want to calculate another set of numbers?"); •                 choice = Console.ReadLine(); •             } • while (choice != "n" && choice != "N"); •         } • staticvoid Main(string[] args) •         { • int number1, number2; • string numb1,numb2,operrand; • string choice; • do •             { • Console.WriteLine("Enter a Number"); •                 numb1= Console.ReadLine(); • Console.WriteLine("Enter an operator, ie +,-,*,/"); • operrand = Console.ReadLine(); • Console.WriteLine("Enter a second number"); •                 numb2 = Console.ReadLine(); • Console.WriteLine("The answer is: "); •                 number1 = int.Parse(numb1); •                 number2 = int.Parse(numb2); • switch (operrand)
