  1. Engineering a Set Intersection Algorithm for Information Retrieval Alex Lopez-Ortiz UNB / InterNAP Joint work with Ian Munro and Erik Demaine

  2. Overview • Web Search Engine Basics • Algorithms for set operations • Theoretical Analysis • Experimental Analysis • Engineering an Improved Algorithm • Conclusions

  3. Web Search Engine Basics • Crawl: sequential gathering process • Document ID (DocID) for each web page 2 SIGIR 1 • Cool sites: • SIGIR • SIGACT • SIGCOMM 3 SIGACT SIGCOMM 4 http://acm.org/home.html

  4. Indexing: List of entries of type <word, docID1 , docID2 , . . . , > E.g. <cool, 1> <SIGACT, 1, 3> <SIGCOMM, 1, 4> <SIG, 1, 2, 3, 4> 1 2 3 4 SIGIR SIGACT SIGCOMM • Cool sites: • SIGIR • SIGACT • SIGCOMM

  5. Postings set: Set of docID’s containing a word or pattern. SIGACT {1,3} SIGCOMM {1,4} 1 2 3 4 SIGIR SIGACT SIGCOMM • Cool sites: • SIGIR • SIGACT • SIGCOMM

  6. Search Engine Basics (cont.) Postings set stored implicitly/explicitly in a string matching data structure • PAT tree/array • Inverted word index • Suffix trees • KMP (grep) ...

  7. String Matching Problem • Different performance characteristics for each solution • Time/Space tradeoff (empirical) • Linear time/linear space lower bound [Demaine/L-O, SODA 2001]

  8. Search Engine Basics (cont.) A user query is of the form: keyword1keyword2 …  keywordn where  is one of {and,or} E.g. computer and science or internet

  9. Evaluating a Boolean Query The interpretation of a boolean query is the mapping: • keyword postings set • and (set intersection) • or  (set union) E.g. {computer}  {science}  {internet}

  10. Set Operations for Web Search Engines • Average postings set size > 10 million • Postings set are sorted

  11. Intersection Time Complexity • Worst case linear on size of postings sets: Θ(n) {1,3,5,7}  {1,3,5,7} • On size of output? {1,3,5,7}  {2,4,6,8}

  12. Adaptive Algorithms • Assume the intersection is empty. What is the min number of comparisons needed to ascertain this fact? Examples {1,2,3,4}  {5,6,7,8}

  13. Much ado About Nothing • A sequence of comparisons is a proof of non-intersectionif every possible instance of sets satisfying said sequence has empty intersection. • E.g. • A={1,3,5,7} • B={2,4,6,8} • a1 < b1 < a2 < b2 < a3 < b3 < a4 < b4

  14. Adaptive Algorithms • In [SODA 2000] we proposed an adaptive algorithm that intersects k sets in: k · | shortest proof of non-intersection | • steps. Ideal for crawled, “bursty” data sets

  15. How does it work? • <SIGACT, 1, 3, i, n> 1,_,3,... i n DocID universe set

  16. Measuring Performance • 100MB Web Crawl • 5000 queries from Google

  17. Baseline Standard Algorithm • Sort sets by size • Candidate answer set is smallest set • For each set S in increasing order by size • For each element e in candidate set • Binary search for e in S • If e is not found remove from candidate set • Remove elements before e in S

  18. Upper Bound: Adaptive/Traditional Two-Smallest Algorithm

  19. Lower Bound: Adaptive/Shortest Proof

  20. Middle Bound: Adaptive/ Encoding of Shortest Proof

  21. Side by Side Middle Bound Lower Bound

  22. Possible Improvements • Adaptive performs best in two-three sets • Traditional algorithm often terminates after first pair of sets • Galloping seems better than binary search • Adaptive keeps a dynamic definition of “smallest set” • Candidate elements aggressively tested

  23. Example {6, 7,10,11,14} {4, 8,10,11,15} {1, 2, 4, 5, 7, 8, 9}

  24. Experimental Results Test orthogonally each possible improvement • Cyclic or Two Smallest • Symmetric • Update Smallest • Advance on Common Element • Gallop Factor/Binary Search

  25. Binary Search vs. Gallop

  26. Advance on Common Element

  27. Small Adaptive Combines best of Adaptive and Two-Smallest • Two-smallest • Symmetric • Advance on common element • Update on smallest • Gallop with factor 2

  28. Small Adaptive

  29. Small Adaptive • Small Adaptive is faster than Two-Smallest • Aggregate speed-up 2.9x comparisons • Faster than Adaptive

  30. Conclusions • Faster intersection algorithm for Web Search Engines • Adaptive measure for set operations • Information theoretic “middle bound” • Standard speed-up techniques for other settings THE END

  31. Query Log Total # of elements in a query Number of queries for each total size

  32. Example {6, 7,10,11,14} {4, 8,10,11,15} {1, 2, 4, 5, 7, 8, 9, 12}
