  1. Automotive Embedded Computer dsPIC DSC Informatii configurare Generare clock WDT Reset Protectie cod Codec AUDIO WM5810

  2. Informatii configurare dsPIC

  3. Generator clock – schema bloc

  4. Executia instructiunilor

  5. SURSE CLOCK

  6. REGISTRU CONFIGURARE OSCILATOR – FOSC ( 0xF8000 )

  7. REGISTRU CONTROL OSCILATOR – OSCCON (SFR)

  8. Cicli exec. instructiuni

  9. dsPIC -WDT

  10. Functii pt. conf. oscilator /* from p33FJ32MC302.h _FOSCSEL( OPT1_ON & OPT2_OFF & OPT3_PLL ) Oscillator Source Selection: FNOSC_FRC Fast RC oscillator FNOSC_FRCPLL Fast RC oscillator w/ divide and PLL FNOSC_PRI Primary oscillator (XT, HS, EC) FNOSC_PRIPLL Primary oscillator (XT, HS, EC) w/ PLL FNOSC_SOSC Secondary oscillator FNOSC_LPRC Low power RC oscillator FNOSC_FRCDIV16 Fast RC oscillator w/ divide by 16 FNOSC_LPRCDIVN Low power Fast RC oscillator w/divide by N Two-speed Oscillator Startup : IESO_OFF Disabled IESO_ON Enabled */

  11. /* • _FOSC( OPT1_ON & OPT2_OFF & OPT3_PLL ) • Clock switching and clock monitor: • FCKSM_CSECME Both enabled • FCKSM_CSECMD Only clock switching enabled • FCKSM_CSDCMD Both disabled • Single configuration for remappable I/O: • IOL1WAY_OFF Disabled • IOL1WAY_ON Enabled • OSC2 Pin function: • OSCIOFNC_ON Digital I/O • OSCIOFNC_OFF OSC2 is clock O/P • Oscillator Selection: • POSCMD_EC External clock • POSCMD_XT XT oscillator • POSCMD_HS HS oscillator • POSCMD_NONE Primary disabled • */ • _FWDT(FWDTEN_OFF);

  12. Codec audio WM8510

  13. Interfata codec audio - dsPIC
