  1. 15-440 Distributed Systems Lecture 22 Virtual Machines Tuesday Nov 16th, 2015 Some slides based on material from: Ken Birman @ Cornell, CS6410, EyalDeLara@ Utoronto, ECE1799 JP Singh, Princeton, COS 318, Alex Snoeren @ UCSD (CSE 120), OS Concepts (Sliberschatz, Galvin, Gagne 2013)

  2. Logistics Updates • P2 was due Friday Nov 13th. • HW3 due today in class • HW4 released Today • Due Dec 10th (*No Late Days*). • P3 released today/tomorrow • Lecture on Nov 19th by TA’s => go over P3 writeup • Teams => let TA’s know if project team change from P2 • No office hours for Yuvraj Nov 19th (travelling)

  3. Virtualization • “a technique for hiding the physical characteristics of computing resources from the way in which other systems, applications, or end users interact with those resources. This includes making a single physical resource appear to function as multiple logical resources; or it can include making multiple physical resources appear as a single logical resource” Adapted from: Ken Birman

  4. The idea of Virtualization: from 1960’s • IBM VM/370 – A VMM for IBM mainframe • Multiple OS environments on expensive hardware • Desirable when few machine around • Popular research idea in 1960s and 1970s • Entire conferences on virtual machine monitors • Hardware/VMM/OS designed together • Allowed multiple users to share a batch oriented system • Interest died out in the 1980s and 1990s • Hardware got more cheaper • Operating systems got more powerful (e.g. multi-user) Adapted from: Ken Birman

  5. A Return to Virtual Machines • Disco: Stanford research project (SOSP ’97) • Run commodity OSes on scalable multiprocessors • Focus on high-end: NUMA, MIPS, IRIX • Commercial virtual machines for x86 architecture • VMware Workstation (now EMC) (1999-) • Connectix VirtualPC (now Microsoft) • Research virtual machines for x86 architecture • Xen (SOSP ’03) • plex86 • OS-level virtualization • FreeBSD Jails, User-mode-linux, UMLinux Adapted from: Ken Birman

  6. Starting Point: A Physical Machine • Physical Hardware • Processors, memory, chipset, I/O devices, etc. • Resources often grossly underutilized • Software • Tightly coupled to physical hardware • Single active OS instance • OS controls hardware Adapted from: EyalDeLara

  7. What is a Virtual Machine? • Software Abstraction • Behaves like hardware • Encapsulates all OS and application state • Virtualization Layer • Extra level of indirection • Decouples hardware, OS • Enforces isolation • Multiplexes physical hardware across VMs Adapted from: EyalDeLara

  8. Virtualization Properties, Features • Isolation • Fault isolation • Performance isolation (+ software isolation, …) • Encapsulation • Cleanly capture all VM state • Enables VM snapshots, clones • Portability • Independent of physical hardware • Enables migration of live, running VMs (freeze, suspend,…) • Clone VMs easily, make copies • Interposition • Transformations on instructions, memory, I/O • Enables transparent resource overcommitment,encryption, compression, replication … Adapted from: EyalDeLara

  9. Types of Virtualization • Process Virtualization (Figure [a]) • Language-level Java, .NET, Smalltalk • OS-level processes, Solaris Zones, BSD Jails, Docker Containers • Cross-ISA emulation Apple 68K-PPC-x86 • System Virtualization (Figure [b]) • VMware Workstation, Microsoft VPC, Parallels • VMware ESX, Xen, Microsoft Hyper-V Adapted from: EyalDeLara

  10. Language Level Virtualization • not-really-virtualization but using same techniques, providing similar features • Programming language is designed to run within custom-built virtualized environment (e.g. Oracle JVM) • Virtualization is defined as providing APIs that define a set of features made available to a language and programs written in that language to provide an improved execution environment • JVM compiled to run on many systems • Programs written in Java run in the JVM no matter the underlying system • Similar to interpreted languages

  11. Types of VMs – Emulation • Another (older) way for running one OS on a different OS • Virtualization requires underlying CPU to be same as guest was compiled for while Emulation allows guest to run on different CPU • Need to translate all guest instructions from guest CPU to native CPU • Emulation, not virtualization • Useful when host and guest have differnet processor architectures • Company replacing outdated servers with new servers containing different CPU architecture, but still want to run old applications • Performance challenge – order of magnitude slower than native code • New machines faster than older machines so can reduce slowdown • Very popular – especially in gaming where old consoles emulated on new

  12. VMs – Application Containers • Some goals of virtualization are segregation of apps, performance and resource management, easy start, stop, move, and management of them • Can do those things without full-fledged virtualization • If applications compiled for the host operating system, don’t need full virtualization to meet these goals • Oracle containers / zones for example create virtual layer between OS and apps • Only one kernel running – host OS • OS and devices are virtualized, providing resources within zone with impression that they are only processes on system • Each zone has its own applications; networking stack, addresses, and ports; user accounts, etc • CPU and memory resources divided between zones • Zone can have its own scheduler to use those resources

  13. Types of System Virtualization • Native/Bare metal (Type 1) • Higher performance • ESX, Xen, HyperV • Hosted (Type 2) • Easier to install • Leverage host’s device drivers • VMware Workstation, Parallels Adapted from: EyalDeLara Attribution: http://itechthoughts.wordpress.com/tag/full-virtualization/

  14. Types of Virtualization • Full virtualization (e.g. VMWare ESX) • Unmodified OS, virtualization is transparent to OS • VM looks exactly like a physical machine • Para virtualization (e.g. XEN) • OS modified to be virtualized, • Better performance at cost of transparency Adapted from: EyalDeLara Attribution http://forums.techarena.in/guides-tutorials/1104460.htm

  15. What is a Virtual Machine Monitor? • Classic Definition (Popek and Goldberg ’74) • VMM Properties • Equivalent execution: Programs running in the virtualized environment run identically to running natively. • Performance: A statistically dominant subset of the instructions must be executed directly on the CPU. • Safety and isolation: A VMM most completely control accessto system resources.

  16. VMM Implementation Goals • Should efficiently virtualize the hardware • Provide illusion of multiple machines • Retain control of the physical machine • Which subsystems should be virtualized? • Processor => Processor Virtualization • Memory => Memory Virtualization • I/O Devices => I/O virtualization

  17. Processor Virtualization • An architecture is classically/strictly virtualizable if all its sensitive instructions (those that violate safety and encapsulation) are a subset of the privileged instructions. • all instructions either trap or execute identically • instructions that access privileged state trap Attribution: http://itechthoughts.wordpress.com/tag/full-virtualization/ Adapted from: EyalDeLara

  18. System Call Example • Run guest operating system deprivileged • All privileged instructions trap into VMM • VMM emulates instructions against virtual statee.g. disable virtual interrupts, not physical interrupts • Resume direct execution from next guest instruction Adapted from: JP Singh @ Princeton

  19. X86 Virtualization challenges • X86 not Classically Virtualizable • x86 ISA has instructions that RD/WR privileged state • …But which don’t trap in unprivileged mode • Example: POPF instruction • Pop top-of-stack into EFLAGS register • EFLAGS.IF bit privileged (interrupt enable flag) • POPF silently ignores attempts to alter EFLAGS.IF in unprivileged mode! => no trap to return control to VMM • Techniques to address inability to virtualize x86 • Replace non-virtualizable instructions with easily Virtualized ones statically (Paravirtualization) • Perform Binary Translation (Full Virtualization)

  20. Virtualizing the CPU • The VMM still need to multiplex VMs on CPUs • How could this be done? • # Physical CPUs more than #Virtual CPUs? • # Physical CPUs more than #Virtual CPUs? • Timeslice the VMs, each VM runs OS/Apps • Use simple CPU scheduler • Round robin, work-conserving (give extra to other VM) • Can oversubscribe and give more #VCPUs that actual

  21. Virtualizing Memory • OS assumes that it has full control over memory • Management: Assumes it owns it all • Mapping: Assumes it can map any Virtual-> Physical • However, VMM partitions memory among VMs • VMM needs to assign hardware pages to VMs • VMM needs to control mapping for isolation • Cannot allow OS to map any Virtual => hardware page • Hardware-managed TLBs make this difficult • On TLB misses, the hardware walks page tables in mem • VMM needs to control access by OS to page tables Adapted from: Alex Snoeren

  22. x86 Memory Management Primer • The processor operates with virtual addresses • Physical memory operates with physical addresses • x86 includes a hardware translation lookaside bufer (TLB) • Maps virtual to physical page addresses • x86 handles TLB misses in HW • HW walks the page tables => Inserts virtual to physical mapping

  23. Shadow Page Tables • Three abstractions of memory • Machine: actual hardware memory (e.g. 2GB of DRAM) • Physical: abstraction of hardware memory, OS managed • E.g. VMM allocates 512 MB to a VM, the OS thinks the computer has 512 MB of contiguous physical memory • (Underlying machine memory may be discontiguous) • Virtual: virtual address space • Standard 2^32 address space • In each VM, OS creates and manages page tables for its virtual address spaces without modification • But these page tables are not used by the MMU

  24. Three Abstractions of memory • Native • Virtualized Virtual Pages Virtual Pages

  25. Shadow Page Table (continued) • VMM creates and manages page tables that map virtual pages directly to machine pages • These tables are loaded into the MMU on a context switch • VMM page tables are the shadow page tables • VMM needs to keep its V => M tables consistent with changes made by OS to its V=>P tables • VMM maps OS page tables as read only • When OS writes to page tables, trap to VMM • VMM applies write to shadow table and OS table, returns • Also known as memory tracing • Again, more overhead... Adapted from: Alex Snoeren

  26. Memory Management / Allocation • VMMs tend to have simple memory management • Static policy: VM gets 8GB at start • Dynamic adjustment is hard since OS cannot handle • No swapping to disk • More sophistication: Overcommit with balooning • Baloon driver runs inside OS => consume hardware pages • Baloon grows or shrinks (gives back mem to other VMs) • Even more sophistication: memory de-duplication • Identify pages that are shared across VMs!

  27. Memory Ballooning

  28. Page Sharing

  29. Page Sharing

  30. I/O Virtualization • Challenge: Lots of I/O devices • Problem: Writing device drivers for all I/O devices in the VMM layer is not a feasible option •  Insight: Device driver already written for popular Operating Systems • Solution: Present virtual I/O devices to guest VMs and channel I/O requests to a trusted host VM (popular OS)

  31. Virtualizing I/O devices • However, overall I/O is complicated for VMMs • Many short paths for I/O in OSes for performance • Better if hypervisor needs to do less for I/O for guests, • Possibilities include direct device access, DMA pass-through, direct interrupt delivery (need H/W support!) • Networking also complex as VMM and guests all need network access • VMM can bridge guest to network (direct access) • VMM can provide network address translation (NAT) • NAT address local to machine on which guest is running, VMM provides address translation to guest to hide its address

  32. VM Storage Management • VMM provides both boot disk + other storage • Type 1 VMM – storage guest root disks and config information within file system provided by VMM as a disk image • Type 2 VMM – store as files in the host file system/OS • Example of supported operations: • Duplicate file (clone) -> create new guest • Move file to another system -> move guest • Convert formats: Physical-to-virtual (P-to-V) and Virtual-to-physical (V-to-P) • VMM also usually provides access to network attached storage (just networking) => live migration

  33. OS Component – Live Migration • VMMs allow new functionality like live migration • Running guest OS can be moved between systems, without interrupting user access to the guest or its apps • Very useful for resource management, no downtime windows, etc • How does it work? • Source VMM connects to the target VMM • Target VMM creates a new guest (e.g. create a new VCPU, etc) • Source sends all read-only guest memory pages to the target • Source sends all RD/WR pages to the target, marking them clean • Source repeats step 4, as some pages may be modified => dirty • When cycle of steps 4 and 5 becomes very short, source VMM freezes guest, sends VCPU’s final state + other state details, sends final dirty pages, and tells target to start running the guest • Target acknowledges that guest running => source terminates guest

  34. Live Migration of VMs

  35. Example VMM: XEN : Introduction • A Para-Virtualized Interface • Can host multiple and different OSes • Supports Isolation • Performance Overhead is minimum • Can Host up to 100 Virtual Machines • Trivia: started at Cambridge, sold for a lot of $$ • Open Source software, xen.org at the moment

  36. XEN : Approach • Drawbacks of Full Virtualization with respect to x86 architecture • Support for virtualization not inherent in x86 architecture • Certain privileged instructions did not trap to the VMM • Virtualizing the MMU efficiently was difficult • Other than x86 architecture deficiencies, it is sometimes required to view the real and virtual resources from the guest OS point of view • Xen’s Answer to the Full Virtualization problem: • It presents a virtual machine abstraction that is similar but not identical to the underlying hardware -para-virtualization • Requires Modifications to the Guest Operating System • No changes are required to the Application Binary Interface (ABI)

  37. Terminology Used • Guest Operating System (OS) – refers to one of the operating systems that can be hosted by XEN. • Domain – refers to a VM within which a Guest OS runs with applications on top of the OS. • Hypervisor – XEN (VMM) itself. • Guest OS’s (domU) and priviledge domain “dom0”

  38. XEN’s VMI : CPU • Problems • Inserting the Hypervisor below the Guest OS means that the Hypervisor will be the most privileged entity in the whole setup • If the Hypervisor is the most privileged entity then the Guest OS has to be modified to execute in a lower privilege level • Exceptions • Solutions • x86 supports 4 distinct privilege levels – rings • Ring 0 is the most and Ring 3 is the least • Allowing the guest OS to execute in ring 1- provides a way to catch the • privileged instructions of the guest OS at the Hypervisor • Exceptions such as memory faults and software traps are solved by registering the handlers with the Hypervisor • Guest OS must register a fast handler for system calls with the Hypervisor • Each guest OS will have their own timer interface Adapted from: Ken Birman

  39. XEN’s VMI: Device I/O • Existing hardware Devices are not emulated • A simple set of device abstractions are used – to ensure protection and isolation • Data is transferred to and fro using shared memory, asynchronous buffer descriptor rings – performance is better • Hardware interrupts are notified via a event delivery mechanism to the respective domains Adapted from: Ken Birman

  40. XEN : Cost of Porting Guest OS • Linux is completely portable on the Hypervisor - the OS is called XenoLinux • Lot of modifications to the architecture specific code was done in both the Oses • In comparing both OSes – Larger Porting effort for XP Adapted from: Ken Birman

  41. XEN : Control and Management • Xen exercises just basic control operations such as access control, CPU scheduling between domains etc. • All the policy and control decisions with respect to Xen are undertaken by management software running on one of the domains – domain0 • The software supports creation and deletion of VBD, VIF, domains, routing rules etc. Adapted from: Ken Birman

  42. XEN : Disk Management • Only Domain0 has direct unchecked access to the physical disks. • Other Domains access the physical disks through virtual block devices (VBDs) which is maintained by domain0. • VBS comprises a list of associated ownership and access control information, and is accessed via I/O ring. • A translation table is maintained for each VBD by the hypervisor, the entries in the VBD’s are controlled by domain0. • Xen services batches of requests from competing domains in a simple round-robin fashion.

  43. Summary • Introduction to Virtualization: why do it? • Different types of Virtualization: Container based, Language Based, Type I/II, Paravirtualized. • VMM techniques to virtualize the CPU, memory, I/O devices, etc • Example: XEN, open source VMM
