Valvular heart disease

seoras avatar
seoras
25 diapositives · 851 Views · Oct 15, 2014

Valvular heart disease. Dr Husain Tayib. Dr Husain Tayib. Valvuler heart disease. 1. Anatomy. Valvuler heart disease. 2. Causes of valve disease. Valve regurgitation * Congenital *Acute rheumatic carditis *Chronic rhe. Carditis

#valvular heart disease #valvular heart disease ppt #powerpoint #presentation
Valvular heart disease - slide 1
01 / 25Valvular heart disease
1 / 17

Télécharger la présentation

Valvular heart disease
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Valvular heart disease Dr Husain Tayib Dr Husain Tayib

  2. Valvuler heart disease 1 Anatomy

  3. Valvuler heart disease 2 Causes of valve disease Valve regurgitation * Congenital *Acute rheumatic carditis *Chronic rhe. Carditis * I E *Syphlitic aortitis *Dilated Valve ring *Senile degeneration e.g. dilated CMP *Traumatic valve rupture *Damage to chordae and papillary muscles e.g. M I Valve stenosis * Congenital * Senile degeneration *Rheumatic carditis

  4. Mitral stenosis Dr Husain Tayib

  5. Mitral stenosis

  6. 1 Aetiology and pathophysiology Mitral stenosis *Almost rheumatic in origin. 2/3 are Females Pure or predominant MS 40% of all RVD *Heavy calcification in elderly may produce a form of mitral stenosis. *Congenital MS { rare }. _ Mitral vave orifice progressively diminish by fibrosis, calcification of leaflets and fusion 0f cusps and subvalvular apparatus. _LA dilate…LA pressure rises …pulmonary congestion occurs … later pulmonary hypertension ….RVF _Atrial fibrillation occurs in most patients with risk of thromboembolism. _> 20% remain in sinus rhythm with small fibrotic LA and severe PH

  7. 2 MItral stenosis Pathophysiology of MV : * Normal valve area: 4-6 cm2 * Mild. mitral stenosis _ MVA 1.5-2.5 cm2 _ Minimal symptoms * Mod. mitral stenosis _ MVA 1.0-1.5 cm2 usually does not produce _ Symptoms at rest * Severe mitral stenosis _ MVA < 1.0 cm2

  8. 3 Mitral stenosis Pathophsiolgy JVP

  9. Mitral stenosis 4 Clinical features Clinical features *Dyspnia {pulmonary congestion } * Fatigue { low COP } *Oedema, ascitis {RVF } *Palpitation { AF } *Haemoptysis {pulmonary congestion, PE } *Cough {pulmonary congestion } *Chest pain {PH } *Symptoms of thromboembolic complication { e.g. stroke, ischaemic limb} Symptoms Symptoms *Dyspnia {pulmonary congestion } * Fatigue { low COP } *Oedema, ascitis {RVF } *Palpitation { AF } *Haemoptysis {pulmonary congestion, PE } *Cough {pulmonary congestion } *Chest pain {PH } *Symptoms of thromboembolic complication { e.g. stroke, ischaemic limb}

  10. 5 MItral stenosis Clinical features cont. Signs : • * Atrial fibrillation • * Mitral facies , tapping apex {Palpable 1st HS} • * Auscultation : Loud first HS, Opening snap • Mid-diastolic murmer, presyst. Accentuation • * Signs of raised pulmonary capillary pressure : • _Crepitations, _Pulmonary oedema, Effusion • * Signs of pulmonary hypertension: • RV heave, Loud P2

  11. Physical examination MItral stenosis 6 Auscultation

  12. Common Murmurs and Timing (click on murmur to play) Systolic Murmurs • Aortic stenosis • Mitral insufficiency • Mitral valve prolapse • Tricuspid insufficiency Diastolic Murmurs • Aortic insufficiency • Mitral stenosis S1 S2 S1

  13. Investigations Mitral stenosis 7 * ECG : LA hypertrophy , RVH , AF * Chest X-ray : Enlarged LA Pulmonary venous congestion * ECHO : Thick immobile cusps Reduced valve area Reduced rate of LV diastolic filling * Doppler : _ PG across MV _ Pulmonary artery pressure * Cardiac catheterization : _ Pulmonary wedge pressure _ PG between LA and LV

  14. 8 Mitral stenosis ECG MS+ AF

  15. Mitral stenosis 9 Chest X-ray PA view

  16. Mitral stenosis 10 Chest X-ray lat. View +Barium swallow

  17. 11 Mitral stenosis M-mode ECHO MS Normal

  18. Mitral stenosis 12 AO MV LA . 2-d ECHO

  19. 13 MItral stenosis 2-D mode Active ECHO.

  20. 14 Mitral stenosis Pw Dopler

  21. Mitral stenosis 15 Color dopler

  22. Mitral stenosis 16 Natural history *Progressive, lifelong disease, *usually slow & stable in the early years. *Progressive acceleration in the later years *20-40 year latency from rheumatic fever to symptom onset. *Additional 10 years before disabling symptoms

  23. Management : Mitral stenosis 17 *Medical management : _Digoxin for AF +beta blocker or calcium antagonist _Diuretics for pulmonary congestion _Anticoagulant to reduce risk of systemic emboli _Antibiotic prophylaxis against IE *Mitral balloon valvoplasty : _ Significant symptoms _Isolated MS _ No or trivial MR _Mobile noncalcific valve /subvalvular apparatus on ECHO _ LA free of thrombus *Mitral valve surgery : _Closed mitral valvotomy _ Open mitral valvotomy _Mitral valve replacement * Mechanical * Bioprosthesis

  24. Mitral stenosis 18 Mechanical valves

  25. Thank you
