Engineering Calculation: Torque and Rotation Center Problem Solution

Solve rotational equilibrium problems using torque equations without forces involved. Calculate the weights and angles to determine the rotation center. Utilize trigonometry to find alpha and beam alignment.

shanon
Télécharger la présentation

Engineering Calculation: Torque and Rotation Center Problem Solution

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. CH12.Problems JH.131

  2. Take the lower center as rotation center then: • M2 (L/4) = M3 (3L/4) M2= 3 M3 • Now the upper center: • M1 (L/4) = (M2+M3) (3 L/4) • M1 = 3(M2+M3) = 3* 4 = 12kg • Only Torques, no forces!

  3. -Ta + Tc cos30 = 0 Tc Sin30 -240 = 0 Only forces no torques

  4. Project! Mg (L/2 sin alpha) is cw torque 2Mg (L) Sin(90-alpha) is CCW torque Then 2 Cos(alpha) = Sin(alpha) /2 Or Tan (alpha) = 4  alpha = 76 deg

  5. Any triangle =180; so, beam makes 60 with vertical
