  1. Why Elevator Air Conditioner?

  2. Why Elevator Air Conditioner? ►Improve air quality inside car cabinet. ►Maintain equivalent air conditioned environment with other area in building.

  3. Why Elevator Air Conditioner? ►Fresh and circulated air can be cleaned up by the air filter. ►Lower noise level compare to traditional fan system.

  4. Facts

  5. Facts ►Air conditioned cabinet is a design mandate for most skyscrapers. ►Priority option for building architect's. ►Commonly requested equipment for living premises, hotels, commercial buildings, shopping arcades etc.

  6. Facts ►Proven evidence on improving the temperature or ventilation problem. ►Increase interests from overseas buyers. ►Lower installation and maintenance cost with new technology.

  7. Common Installation

  8. Common installation ►Luxury passenger lift ►Observation lift ►Shuttle lift ►Hotel lift ►Foot bridge outdoor lift ►Hospital lift

  9. Job Reference

  10. Job Reference 工商業項目 朗豪坊商場 官塘 223 IFC 國際金融中心 I, II 朗豪坊寫字樓 中國染廠大廈 信德中心 新都城 II 期商場 一號九龍 ICC環球貿易廣場 AIG Tower MEGA BOX 東方報業集團 東灜游廣場 藍馬廣場 佐敦薈

  11. Job Reference 住宅項目 貝沙灣1-6期 天璽 君匯港 富匯豪庭 爵悦庭 珀麗灣 新屯門中心 葡萄園 帝琴灣 羅便臣道 31號 帝濤灣 地利根德閣 翔龍灣 嘉亨灣 萬景峰 日出康城 君匯港 都會駅,城中駅 嘉亨灣 海濱南岸 星匯居

  12. Job Reference 酒店項目 朗豪坊酒店 美麗華酒店 君悅酒店 香格里拉酒店 富豪酒店 彌敦酒店 W HOTEL

  13. Job Reference 澳門項目 威尼斯人渡假村 四季酒店 十六浦酒店 MGM美高梅金殿 豪景花園II 期 雍景花園 新葡京賭場酒店 澳門商業銀行 湖畔壹號 COD夢幻之城 君悦灣 澳門行政長官辦公室

  14. Job Reference 其它項目 各區港鐵站 各區天橋觀光升降機 快活谷馬場 行政大樓 香港中文大學 浸會醫院歐樹洪大樓 聖德肋撒醫院 樂富 永光堂 沙田馬場包廂升降機 房署總部觀光升降機 沙田坳道聖十字堂

  15. Job Reference 浸會醫院 旅游觀光塔 Manhattan Place 澳門威尼斯人渡假村 and many more…. 干德道39號 朗豪坊酒店 新濠天地 東方報業集團 環球貿易廣場 綠意居 海濱南岸 新屯門中心 碧海藍天 銅鑼灣地鐵站 畢架山峰 翔龍灣

  16. Technical Data

  17. Technical Data Model TLP-25/E TLP-32/E TLP-25-H TLP-32-H Series CoolingCapacity (kw) (btu/h) HeatingCapacity (kw) Air Flow Rate (CMH) Compact Type, No water Drips Design 2.5 3.2 2.5 3.2 9,000 12,000 9,000 12,000 / / 2,200 2,200 430 530 430 530

  18. Technical Data Model TLP-25/E TLP-32/E TLP-25-H TLP-32-H Power Input (kw)Running Current (A) Power Supply Noise Level db(A) Refrigerant 1.0 1.2 1.0 1.2 4.8 5.8 4.8 5.8 1P-220V-50Hz 48 <50 <48 <50 R22 / R407C

  19. Technical Data Model TLP-25/E TLP-32/E TLP-25-H TLP-32-H Dimensions (mm) Weight (kg) Safety Devices Control Options W460 x D620 x H440 W580 x D640 x H520 W460 x D620 x H440 W580 x D640 x H520 40 48 40 48 Thermal Protector, Fuse Timer Delay Protector, Water Sensor Wireless Remote Control, Timer Control Anti-bacterial Filter, Tailor Made Air Box,Special Function Control Box, Booster Fan

  20. Technical Data Air Conditioning Unit Insulated Flexible Air Duct Insulated Air Boxes Insulated Air Boxes False Ceiling W/Louvre Return Air Outlet Cool Air Inlet Compact Type Series Lift Car Cabinet

  21. Technical Data ►ECOLUX (since 1994) ►Environmental friendly option of refrigerant 407C model ►With Japanese brand compressor unit

  22. Technical Data ►Hong Kong design with mass production in China ►Tailored models also available for smaller lift cars

  23. Key Features of ECOLUX

  24. Key Features of ECOLUX ►Self-evaporation faction for condensate. Basic Structure of ECOLUX Air Condition System

  25. Key Features of ECOLUX Compact in size for the ease of installation.

  26. Key Features of ECOLUX

  27. Key Features of ECOLUX ►Long life span of over 6 to 10 years. ►Timer on/off function control (7 days/24 hrs). ►Wireless remote control.

  28. Key Features of ECOLUX ►Energy saving for high efficiency of cooling system. ►Condensate level control protection system. ►Anti-bacterial filter optional.

  29. Future Maintenance

  30. Future Maintenance ►Regular inspection of system operation. ►Regular cleaning of filter and condensate pump.

  31. Future Maintenance ►Annual overhaul with chemical cleaning of coils. ►Lubrication of moving parts.

  32. Introduction of APEX

  33. Introduction of APEX ►Developer and owner of ECOLUX brand name. ►Expert in elevator air conditioning system installation, repair and maintenance service since 1992.

  34. Introduction of APEX ►Specialized in providing total solution for lift and machine room ventilation. ►Major client in Hong Kong as listed. ►Exploring overseas market.

  35. Hong Kong Major Client 迅達升降機(香港)有限公司 奧的斯電梯(香港)有限公司 富士達(香港)有限公司 星瑪電梯(香港)有限公司 日立電梯工程(香港)有限公司 通力電梯(香港)有限公司 好歷(香港)有限公司 其士(香港)有限公司 菱電升降機服務有限公司 蒂森克虜伯電梯(香港)有限公司 長安工程有限公司 品豐機電工程有限公司

  36. Overseas Market India Vietnam Malaysia Thailand Middle East and more ……

  37. Introduction of APEX Extended scope of works : ►Installation of travelling cable ►Machine room E and M or builder's works ►Lift interior decoration works. ►Engineering and decoration works for office and depot. ►Commercial type air conditioning systems.

  38. ContactsAPEX Engineering & Design Ltd. / Apex International Technology Ltd.Address: 9/F Sunward Commercial Building, 27 Fuk Wa Street, Kowloon, Hong KongWebsite: www.apex-eng.com / www.elevatorairconditioner.comEmail: enquiry@apex-eng.comTel.: (852) 2720 9970 / Fax: (852) 2720 9098Mobile: (852) 9094 1357 (Hong Kong) / (86) 13823700375 (China)
