  1. DEWATERING PRESS Client References April, 2008

  2. Table of Contents 1. Dairy Products Plant (Waste Activated Sludge) 2. Abattoir (Dissolved-air Flotation Floss & Waste Activated Sludge) 3. Chemical Plant(Dissolved-air Flotation Floss & Waste Activated Sludge) 4. Sewage Treatment Plant (Digested Sludge) 5. Sewage Treatment Plant (Direct from Oxidation Ditch) 6. Sewage Treatment Plant (Oxidation Ditch) 7. Automobile Wrecker (Chemically Precipitated) Designed by Hi-Rose

  3. Reference - Dairy Products Plant (Waste Activated Sludge) - Flow & Chart Flocculation Tank Sedimentation Tank Aeration Tank Return Sludge WAS Thickening Tank Storage Tank VOLUTE DEWATERING PRESS：ES-131 Dewatering Zone Chart Sludge Cake Designed by Hi-Rose

  4. Reference - Abattoir (Dissolved-air Flotation Floss & Waste Activated Sludge) - Flow & Chart Aeration Tank Sedimentation Tank Aeration Tank DAF Return Sludge WAS Storage Tank VOLUTE DEWATERING PRESS：ES-131 Flocculation Tank Chart Sludge Cake Designed by Hi-Rose

  5. Reference - Chemical Plant (Dissolved-air Flotation Floss & Waste Activated Sludge) - Flow & Chart Volute Sedimentation Tank Aeration Tank DAF Return Sludge WAS Storage Tank VOLUTE DEWATERING PRESS：ES-202 Flocculation Tank Chart Sludge Cake Designed by Hi-Rose

  6. Reference - Sewage Treatment Plant (Digested Sludge )- Flow & Chart Volute & Belt Press Primary Sedimentation Aeration Tank Secondary Sedimentation Return Sludge WAS Thickener Digestion Tank Storage Tank VOLUTE DEWATERING PRESS：ES-302 Chart (Comparison) Dewatering Zone Sludge Cake Designed by Hi-Rose

  7. Reference - Sewage Treatment Plant (Direct from Oxidation Ditch)- Flow & Chart Flocculation Tank Oxidation Ditch Sedimentation Tank Thickening Tank Return Sludge WAS Storage Tank VOLUTE DEWATERING PRESS：ES-201 Thickening Zone Chart Sludge Cake Designed by Hi-Rose

  8. Reference - Sewage Treatment Plant (Oxidation Ditch)- Flow & Chart Flocculation Tank Oxidation Ditch Sedimentation Tank Thickening Tank Return Sludge WAS Storage Tank VOLUTE DEWATERING PRESS：ES-303 Volute Cylinder Chart Sludge Cake Designed by Hi-Rose

  9. Reference - Automobile Wrecker (Chemically Precipitated)- Flow & Chart Flow Control Tank Reactor Tank Sedimentation Tank Storage Tank VOLUTE DEWATERING PRESS：ES-101 Flocculation Tank Chart Sludge Cake Designed by Hi-Rose

  10. Quick Reference Other Applications… Type of Industry Type of Sludge Note: Above charts are for your quick reference. Note: Please feel free to ask for further information. Designed by Hi-Rose

  11. VOLUTE Units Installed Currently, 1020 units installed worldwide!! Japan : 900 Overseas : 120 Municipal Applications : 300 Industrial Applications : 720 Clients in overseas Australia, Canada, China, Czech Republic, Germany, Hong-Kong, Latvia, Netherlands, Russia, Slovakia, S. Korea, South Africa, Taiwan, Ukraine, USA, etc… Contact Us … 1926 Nippa-cho, Kohoku-ku, Yokohama, Japan 223-0057 Tel: +81 45 540 8580 Fax: +81 45 540 8588 Website : http://www.amcon.co.jp/english Squeeze Sludge, Squeeze Cost !! Designed by Hi-Rose
