  1. SUPAMIC FILTER Newly Invented & Made ONLY in Korea < Nylon-6 Rod with Nylon-6 Media >

  2. Outline of Supamic Filter • 1-1.Services ‐ Cold Rolling Process (Stainless Steel, Carbon Steel, Aluminum) ‐ Filtration process for Mineral oil * Emulsion oil is also filtrated. ‐ ZM Process ‐ ETC.

  3. Outline of Supamic Filter • 1-2. Flow chart of Filtration system *Oil performs cooling and lubrication on cold rolling process. The used and dirty oil is filtrated through filtration system, and it can be reused continuously. The core of filtration system is Supamic filter. Rolling Mill Filtration System Filtration System

  4. Outline of Supamic Filter • 1-3. Clean & coolant system Rolling Mill Supamic Filter

  5. Our Supamic filter We can supply 4 kinds of filter element according to client needs. *Filtering accuracy of Nylon-6 fiber & Glass fiber : 2.0㎛ Solid more than 2.0㎛ is less than 10mg in the oil after filtering

  6. Outline of Supamic Filter • 1-4. The principle of filtering The drawing of Supamic Filter ③Clean & coolant oil ④Ejecting pressurized air • Osmosis adhesive method The media performs that oil flows at a fixed rate during filtering dirty oil or coming out the sludge. Backwashing Process The media can continue the excellent & accuracy filtering for a long lifetime. ②Sludge clings to the surface of the filtering media ⑤Sludge comes out and removed by pressurized air ①Used & dirty oil flows into filtration system : osmotic action

  7. Outline of Supamic Filter • 1-6. Installation Supamic filter is installed on the back of mounting plate. After upsetting the mounting plate, it sets into filter tank. Two filter tanks (300ℓ, 100ℓ) 2 layers of mounting plate (Installed filter element is item code. YE-NN-400) According to filtration system, the quantity of mounting plate is decided.

  8. Our Supamic filter (Rod) • 3-1. Concept of Nylon Rod substitution STS Rod Plastic Keep/improve functionality Easy & simple handling Minimize environmental influence Nylon-6

  9. Bottom part Upper part Boltト <STS rod of other companies > Flat surface -> Hard to replace the filter <Our nylon rod> Circle shaped projection part Injection molding -> Protect the damage on mounting plate, and fix the rod on mounting plate <Our stainless Rod> Groove -> Use the tool Hole 133ea(¢5) <Stainless rod> Flat surface -> Need rubber packing between mounting plate and rod in order to prevent damage Impact wrench Press:Max 5.2kg/㎠ <Our nylon Rod> (+) projection part Injection Molding -> Use electromotion tool Our Supamic filter (Rod) • 3-2. Design Merit

  10. Our Supamic filter (Rod) • 3-4. Comparison between STS rod and Nylon rod

  11. Our Supamic filter (Fiber) • 4-1. Comparison between Glass fiber and Nylon fiber (1) *Filtering accuracy of Nylon-6 fiber & Glass fiber : 2.0㎛ Solid more than 2.0㎛ is less than 10mg in the oil after filtering

  12. Our Supamic filter (Fiber) • 4-1. Comparison between Glass fiber and Nylon fiber (2) • Nylon-6 fiber is developed better than Glass fiber. • Nylon-6 fiber is the most fitted for material of Supamic filter.

  13. Our Supamic filter (Fiber) • 4-1. Comparison between Glass fiber and Nylon fiber (3) *Glass fiber: It generates carcinogenic substances and dust, moreover, it is made of glass fiber and chemical resin adhesive, the worker has to take a bath after a replacement work even handling small quantity. *Nylon fiber: It does not cause dust, it enables worker to perform speedy and correct filter replacement & operation.

  14. Our Supamic filter (Fiber) • 4-1. Comparison between Glass fiber and Nylon fiber (4)

  15. Customer ListFiltration system & Supamic filter element • Japan JFE Soji Trade • Taiwan YUSCO Chiafar Industrial Factory Co., Ltd. • China Shanghai Krupp (KTN Group) Zpss CPSS • Thailand Thainox • India Jindal Stainless Ltd • USA NAS I2S ACS • South Africa Columbus Stainless (Acerinox Group) • Spain Acerinox S.A. • Finland Outokumpu • Korea POSCO Hyundai Steel BNG Steel Dongkuk Industries Co., Ltd. Thaihan Electric Wire Co., Ltd. POONGSAN Co., Ltd. • Germany Krupp Thyssen Nirosta(Dusseldorf) Demag • Belgium Ugine-ALZ Belgium • Rumania Otelinox • Italy ThyssenKrupp AST (KTN Group) * Refer to the Reference list for detail information (quantity, date, ordered item, happening time )

  16. Thank you! • East Sea Corporation • Tel: 82-54-282-0151 • Fax: 82-54-274-9090 • E-mail:ddk5202@naver.com
