Efficient Boiler Program for Enhanced Energy Savings and Performance

DESCRIPTION

The Efficient Boiler Program (EBP), in partnership with Natural Resources Canada and the Ministry of Energy, aims to promote the use of high-efficiency natural gas boilers in new construction and retrofitting applications. Running from April 2005 to 2008, the program offers incentives for installing near-condensing and condensing boilers, resulting in energy savings of up to 40%. The initiative enhances energy efficiency, occupant comfort, and marketability while providing significant environmental benefits, making it a valuable program for both commercial and institutional sectors.

1 / 10

Download Presentation
Télécharger la présentation

Efficient Boiler Program for Enhanced Energy Savings and Performance

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

    1. Efficient Boiler Program

    2. Terasen Gas Commercial DSM Program Efficient Boiler Program Partnered with: Natural Resources Canada (NRCan) Ministry of Energy, Mines and Petroleum Resources (MEMPR)

    3. Efficient Boiler Program (EBP) Program Application Period: April, 2005 December, 2006 (being extended into 2007 & 2008 for New Construction Markets) Two years to install boiler from date of application approval. Goal: Increase the use of higher efficiency natural gas boilers in new construction and retrofit applications.

    4. The Benefits (EBP) Ongoing savings of up to 40% Higher performance Energy efficiency assistance Space efficiency and occupant comfort Increased marketability Environmental benefits

    5. Program Incentives (EBP) Purchase Price Incentives: Near Condensing Boilers: $4000 max/ boiler+$3.00 / MBH Condensing Boilers: $6000 max/ boiler+$9.00 / MBH Standard-eff. Boiler price: $7 / MBH of input New construction cap: 75% of price premium Retrofit cap: 50% of price premium Plus: Incentives to Properly Size Boilers - $400 / $1500 max Plus: Retrofit Venting Modification - $2000 max Plus: Retrofit Monitoring Incentive - $1,500 max plus $1/GJ saved (yr 1)

    6. Market & Boiler Information (EBP) Market Information Agriculture -3 Assembly 6 Commercial -18 Education 20 Health Care 6 Institutional 2 Municipal 4 Recreation -1 Multi-Residential 102 Retail 1

    7. Energy Information (EBP)

    8. Program Results (EBP)

    9. Boiler Monitoring & Performance Boiler start-up summary report Weekly diagnostic and visual checks Weekly checklist report (Weeks 1-26) Six-month combustion analysis report Weekly checklist report (Weeks 27-52) Twelve-month combustion analysis report

    10. Thank You
