1. Natural proofs for structure, data, and separation xiaokangqiuPranavgarg Andrei Stefanescu P. Madhusudan University of Illinois at Urbana-Champaign PLDI 2013, SEATTLE, WA

2. Motivation Don’t know • Automatic Deductive Software Verification • Success stories: Hypervisor (MSR), ExpressOS (Illinois), etc. using tools like Boogie, VCC, etc. • Challenge: dynamically modified heap • Structure (e.g., “p points to the root of a tree”) • Data (e.g., “the integers stored in a list is sorted”) • Separation (e.g., “the procedure modifies only elements reachable using the next field”) int f(int x){ assume x>0; … inv x < y; … assert y>0; } VC-Generator Verification Condition SMT Solver Annotated Program yes no

3. Example: Memory Isolation … … PID: 12 PID: 30 PID: 19 Start Addr Start Addr Start Addr Verify invariants in ExpressOS[@UIUC, ASPLOS’13] • “Every two assigned memory chunks are disjoint“ • “The start addresses are sorted along the doubly-linked list” • “The memory allocator modifies only this doubly-linked list” • Key Challenge: Prev Prev Prev End Addr End Addr End Addr Next Next Next … … Structure, Data,and Separationare mixed UNDECIDABLE • Expressivelogics • to specify complex • data structures • Automatedreasoning • with these • sophisticated logics

4. heap verification Expressive keep expressiveness Expressive Logics: Separation logics, HOL, Matching logic, etc. Natural Proofs give up decidability sound but incomplete preserve automaticity Decidable Logics: Strand, LISBQ, CSL, etc. Automatic

5. Natural proofs: in a nutshell • Handle a logic that is very expressive (inevitably undecidable) • Retain automaticity at the same level as decidable logics • Identify a class of naturalproofs N such that • N includes natural proof tactics used in human proofs • Many correct programs can be proved using a proof in class N • The class N is effectively searchable (checking if there is a proof in N is efficiently decidable) All Proofs N

6. More generalNatural proofs • Natural Proofs for Trees [POPL’12] • only for trees (can’t say “x points to a tree and y points into the tree”) • only functional recursion (no while-loops, too weak for loop invariants) • only classical logic (no frame reasoning) • In this work: Natural Proofs for Separation Logic • A wide variety of structures, and their combination (trees, doubly-linked lists, cyclic lists, etc.) • Iterative and Recursive (pre, post, and loop-inv.) • Separation Logic (frame reasoning is natively supported)

7. contribution • Dryad: a dialect of separation logic that is amenable to natural proofs • No explicit quantification, but supports recursivedefinitions • Admits a translation to quantifier-free classic logic with recursion • Automatic VC-generation for Dryad-annotated programs • Develop natural proofs using decision procedures (powered by SMT solvers) Two proof tactics for handling recursive defs[Suter et al., 2010] : • Unfold across the footprint • Formula abstraction These two tactics form the class of natural proofs!

8. Binary search tree in dryad • (loop invariant for “bst-search”: • root points to a BST and curr points into the BST; • k is stored in the BST iffk is stored under curr) the union of the keys stored in the root and the left/right sub-trees root right subtree: a BST left subtree: a BST the root Recursive predicate Recursive function Base case: empty heaplet SeparatingConjunction Base case: empty set curr k

9. Why dryad? • The heaplet semantics is not supported by automatic theorem provers • Solution:translated to • Capture the scope (heaplet required) of a formula using set-variables? • Empty heap emp : • Singleton heap : • Separating Conj.t t’: • Recursive definition : • Separation Logic: The semantics of is arbitrary fix point of the recursive definition, and the scope is not syntactically determined reachl,r(x) ? Dryad: the scope is exactly the reachable locations from x using l and r (only difference between Dryad and classic Separation Logic)

10. Translating heaplets to sets • The heaplet required for a Dryad formula can be syntactically determined • the scope can be modeled as a set of locations, and the heaplet semantics can be expressed using free set variables Example: • translated to • (still quantifier-free)

11. natural proofs for dryad • We consider programs with modular annotations • A simple heap-manipulating language • (supports memory allocation/deallocation, destructive pointer/data updates, and function calls) • Pre/post-conditions and loop invariants written in Dryad • Footprint:dereferenced locations (x is in footprint if y := x.next) • Verify programs in 4 steps • 1. Translate Dryad to classic logic with recursion • 2. VC-Generation (compute strongest-post) • 3. Unfold recursive defsacross the footprint (still precise; explained later) • 4. Formula Abstraction • (recursive definitions uninterpreted, becomes sound but incomplete) Natural Proofs: Two proof tactics inspired by human proofs

12. 1st proof tactic:Unfolding across the footprint • The verification condition ψVC involves recursive definitions that can be unfolded ad infinitum. • Where to stop? • In most cases: unfold only across the footprint (locations get dereferenced in the program). Footprint: {x, z}, then assert tree(x) = … tree(z) = … … y = x.l; z = x.r; z.l = y; … Non-footprint: {y}, then assert tree(y) /\ NoMod(y) ==> tree’(y)

13. 1st proof tactic:Unfolding across the footprint • Formally, we capture this proof tactic using a set of conjuncts: • Theorem • ψVC is valid iffψ’VC is valid. Unfold only across the footprint Apply the frame rule for non-footprint locations

14. 2nd proof tactic:formula abstraction • Natural Proofs in two steps: • Formula Abstraction • replace each recursive definition rec with uninterpreted • when a proof for is found, we call it a natural proof for (sound but incomplete) • is expressible in the decidable theories • (theory of sets/arrays, maps, uninterpretedfunctions and integers) • and is solvable using modern SMT solvers.

15. User-provided axioms • Proof tactics cannot effectively find the relationship between data structures • Meta-level axioms for structures (independent of program verified) • Relating simpler data structures and more sophisticated ones, e.g., • Relating partial data structures and complete ones, e.g., • Instantiated at all non-footprint locations • Still automatic? • Axioms are program-independent, defined once and for all • Can be encoded in the verifier

16. Natural proofs for dryad Program + Recursive defs + Annotations in Dryad Program + Recursive defs + annptations in Classical-logic VCGen Translate Verification Conditions no Formula in a dec. logic over sets: Does a natural proof exist? Encode NTwo proof tactics for recursive defs yes Don’t know SMT Solver

17. experimental evaluation • A prototype verifier with Z3 as the backend solver (more details at http://web.engr.illinois.edu/~qiu2/dryad/) Inductive data structures singly-linked list, sorted list, doubly-linked list, cyclic list, max-heap, BST, Treap, AVL tree, red-black tree, binomial heap, … Data structures from open source programs • Glib library: singly/doubly-linked list • OpenBSD library: queue • Linux kernel: VMA for virtual memory management ExpressOS: a secure mobile platform • Structures for memory management

18. We verified … 106 Dryad-annotated programs • insert, delete, search, reverse, rotate, … (recursive & iterative) • Quicksort, Schorr-Waite algorithm for trees, etc. • VMA: virtual memory operations • ExpressOS: operations memory isolation • full-functional, partial correctness (e.g., data structure invariants, expected set-of-keys, …) All the VCs were automaticallyproved by our tool！ • 69 verified within 1 sec • 96 verified within 10 sec • 104 verified within 100 sec “RBT-delete_iter” spent 225 secs, “binomial-heap-merge_rec” spent 153 secs (To the best of our knowledge) • First terminating automatic mechanism that can prove such a wide variety of data-structure manipulating programs full-functionally correct

19. Related work • Natural proofs • [Suter et al., POPL’10]: Proof tactics for functional programs • [Madhusudan et al., POPL’12]: Imperative programs, only trees, no while-loops, no frame reasoning • Separation Logic • Verifast, Bedrock, etc.: proof tactics provided by the user per program • Implicit Dynamic Frames: also using sets for heaplet, not syntactically determined, not quantifier-free • HIP/Sleek: search for a class of proofs, but not in any decidable theory • Classical Logic • Dafny, VCC, etc.: require significant ghost annotations • Jahob: often relies on complex provers, e.g., Mona or Isabelle

20. conclusion • Dryad • an expressive, tractable dialect of separation logic • A translation to QF classical logic with recursion • Established a natural proof scheme • Algorithmically search for a subclass of proofs • Automatic, sound but incomplete • Formalized two proof tactics for inductive data structures • A verifier that handles Hoare-triples automatically using SMT solvers Future work • More proof tactics for natural proofs (non-inductive structures, e.g., graphs) • Natural Proofs for C (incorporate natural proofs into existing verifiers, e.g., VCC) • Natural Proofs for concurrent programs (Rely-Guarantee + Dryad) All Proofs Natural proofs
