S parse K ernel M achines

Christopher M. Bishop, Pattern Recognition and Machine Learning Sparse Kernel Machines

Outline • Introduction to kernel methods • Support vector machines (SVM) • Relevance vector machines (RVM) • Applications • Conclusions

Supervised Learning • In machine learning, applications in which the training data comprises examples of the input vectors along with their corresponding target vectors are called supervised learning (x,t) (1,60,pass) (2,53,fail) (3,77,pass) (4,34,fail) ﹕ y(x) output

Classification x2 y<0 y>0 y=0 t=1 t=-1 x1

Regression t 1 0 -1 x new x 0 1

Linear Models • Linear models for regression and classification: if we apply feature extraction, model parameter input

Problems with Feature Space • Why feature extraction? Working in high dimensional feature spaces solves the problem of expressing complex functions • Problems: - there is a computational problem (working with very large vectors) - curse of dimensionality

Kernel Methods (1) • Kernel function: inner products in some feature space  nonlinear similarity measure • Examples - polynomial: - Gaussian:

Kernel Methods (2) • Many linear models can be reformulated using a “dual representation” where the kernel functions arise naturally  only require inner products between data (input)

Kernel Methods (3) • We can benefit from the kernel trick: - choosing a kernel function is equivalent to choosing φ  no need to specify what features are being used - We can save computation by not explicitly mapping the data to feature space, but just working out the inner product in the data space

Kernel Methods (4) • Kernel methods exploit information about the inner products between data items • We can construct kernels indirectly by choosing a feature space mapping φ, or directly choose a valid kernel function • If a bad kernel function is chosen, it will map to a space with many irrelevant features, so we need some prior knowledge of the target

Kernel Methods (5) • Two basic modules for kernel methods General purpose learning model Problem specific kernel function

Kernel Methods (6) • Limitation: the kernel function k(xn,xm) must be evaluated for all possible pairs xn and xm of training points when making predictions for new data points • Sparse kernel machine makes prediction only by a subset of the training data points

Support Vector Machines (1) • Support Vector Machines are a system for efficiently training the linear machines in the kernel-induced feature spaces while respecting the insights provided by the generalization theory and exploiting the optimization theory • Generalization theory describes how to control the learning machines to prevent them from overfitting

Support Vector Machines (2) • To avoid overfitting, SVM modify the error function to a “regularized form” where hyperparameter λ balances the trade-off • The aim of EW is to limit the estimated functions to smooth functions • As a side effect, SVM obtain a sparse model

Support Vector Machines (3) Fig. 1 Architecture of SVM

SVM for Classification (1) • The mechanism to prevent overfitting in classification is “maximum margin classifiers” • SVM is fundamentally a two-class classifier

Maximum Margin Classifiers (1) • The aim of classification is to find a D-1 dimension hyperplane to classify data in a D dimension space • 2D example:

Maximum Margin Classifiers (2) support vectors support vectors margin

Maximum Margin Classifiers (3) small margin large margin

Maximum Margin Classifiers (4) • Intuitively it is a “robust” solution - If we’ve made a small error in the location of the boundary, this gives us least chance of causing a misclassification • The concept of max margin is usually justified using Vapnik’s Statistical learning theory • Empirically it works well

SVM for Classification (2) • After the optimization process, we obtainthe prediction model: where (xn,tn) are N training data we can find that an will be zero except for that of the support vectors  sparse

SVM for Classification (3) Fig. 2 data from twp classes in two dimensions showing contours of constant y(x) obtained from a SVM having a Gaussian kernel function

SVM for Classification (4) • For overlapping class distributions, SVM allow some of the training points to be misclassified  soft margin penalty

SVM for Classification (5) • For multiclass problems, there are some methods to combine multiple two-class SVMs - one versus the rest - one versus one  more training time Fig. 3 Problems in multiclass classification using multiple SVMs

SVM for Regression (1) • For regression problems, the mechanism to prevent overfitting is “ε-insensitive error function” quadratic error function ε-insensitive error funciton

SVM for Regression (2) × Error = |y(x)-t|- ε No error Fig . 4 ε-tube

SVM for Regression (3) • After the optimization process, we obtainthe prediction model: we can find that an will be zero except for that of the support vectors  sparse

SVM for Regression (4) Fig . 5 Regression results. Support vectors are line on the boundary of the tube or outside the tube

Disadvantages • It’s not sparse enough since the number of support vectors required typically grows linearly with the size of the training set • Predictions are not probabilistic • The estimation of error/margin trade-off parameters must utilize cross-validation which is a waste of computation • Kernel functions are limited • Multiclass classification problems

Relevance Vector Machines (1) • The relevance vector machine (RVM) is a Bayesian sparse kernel technique that shares many of the characteristics of SVM whilst avoiding its principal limitations • RVM are based on Bayesian formulation and provides posterior probabilistic outputs, as well as having much sparser solutions than SVM

Relevance Vector Machines (2) • RVM intend to mirror the structure of the SVM and use a Bayesian treatment to remove the limitations of SVM the kernel functions are simply treated as basis functions, rather than dot-product in some space

Bayesian Inference • Bayesian inference allows one to model uncertainty about the world and outcomes of interest by combining common-sense knowledge and observational evidence.

Relevance Vector Machines (3) • In the Bayesian framework, we use a prior distribution over w to avoid overfitting where α is a hyperparameter which control the model parameter w

Relevance Vector Machines (4) • Goal: find most probable α* and β* to compute the predictive distribution over tnew for a new input xnew, i.e. p(tnew | xnew, X, t, α*, β*) • Maximize the likelihood function to obtain α* and β* : p(t|X, α, β) Training data and their target values

Relevance Vector Machines (5) • RVM utilize the “automatic relevance determination” to achieve sparsity where αm represents the precision of wm • In the procedure of finding αm*, some αmwill become infinity which leads the corresponding wm to be zero  remain relevance vectors !

Comparisons - Regression SVM RVM (on standard deviation predictive distribution)

Comparisons - Regression

Comparison - Classification SVM RVM

Comparison - Classification

Comparisons • RVM are much sparser and make probabilistic prediction • RVM gives better generalization in regression • SVM gives better generalization in classification • RVM is computationally demanding while learning

Applications (1) • SVM for face detection

Applications (2) Marti Hearst, “ Support Vector Machines” ,1998

Applications (3) • In the feature-matching based object tracking, SVM are used to detect false feature matches Weiyu Zhu et al., “Tracking of Object with SVM Regression” , 2001

Applications (4) • Recovering 3D human poses by RVM A. Agarwal and B. Triggs, “3D Human Pose from Silhouettes by Relevance Vector Regression” 2004

Conclusions • The SVM is a learning machine based on kernel method and generalization theory which can perform binary classification and real valued function approximation tasks • The RVM have the same model as SVM but provides probabilistic prediction and sparser solutions
