  1. COSC 2007Data Structures II Chapter 14 Graphs I

  2. Topics • Introduction & Terminology • ADT Graph

  3. Introduction • Graphs • Important mathematical concept that have significant application in computer science • Can be viewed as a data structure or ADT • Provide a way to represent relationships between data • Questions Answered by Using Graphs: • Airline flight scheduling: • What is the shortest distance between two cities?

  4. B C A F D E Terminology and Notations • A graph G is a pair (V, E) where • V is a set of vertices (nodes) V = {A, B, C, D, E, F} • E is a set of edges (connect vertex) E = {(A,B), (A,D), (B,C),(C,D), (C,E), (D,E)}

  5. B C A F D E Terminology and Notations • If edge pairs are ordered, the graph is directed, otherwise undirected. • We draw edges in undirected graphs with lines with no arrow heads. (B, C) and (C, B) mean the same edge This is an undirected graph.

  6. B C A F D E Terminology and Notations • If edge pairs are ordered, the graph is directed, otherwise undirected. • We draw edges in directed graphs with lines with arrow heads. This edge is (B, C). (C, B) wouldmean a directed edge from C to B This is a directed graph.

  7. B C A F D E Terminology and Notations • Directed Graph (Digraph): • If an edge between two nodes has a direction (directed edges) • Out-degree (OD) of a Node in a Digraph: • The number of edges exiting from the node • In-degree (ID) of a Node in a Digraph: • The number of edges entering the node This is a directed graph.

  8. B C A F D E Terminology and Notations • Vertex w is adjacent to v if and only if (v, w) E. • In a directed graph the order matters: • B is adjacent to A in this graph, but A is not adjacent to B.

  9. B C A F D E Terminology and Notations • Vertex w is adjacent to v if and only if (v, w) E. • In an undirected graph the order does not matter: • we say B is adjacent to A and that A is adjacent to B.

  10. 3 B C A 4.5 1.2 7.5 F – 2.3 D E Terminology and Notations • In some cases each edge has a weight (or cost) associated with it. • The costs might be determined by a cost function E.g., c(A, B) = 3, c(D,E) = – 2.3, etc. 4

  11. 4 3 B C A 4.5 1.2 7.5 F – 2.3 D E Terminology and Notations • In some cases each edge has a weight (or cost) associated with it. • When no edge exists between two vertices, we say the cost is infinite. E.g., c(C,F) = 

  12. B C A F D E Terminology and Notations • Let G = (V, E) be a graph. • A subgraph of G is a graph H = (V*, E*) such that V* V and E* E. E.g., V* = {A, C, D}, E* = {(C, D)}.

  13. C A D Terminology and Notations • Let G = (V, E) be a graph. • A subgraphof G is a graph H = (V*, E*) such that V* V and E* E. E.g., V* = {A, C, D}, E* = {(C, D)}.

  14. B C A F D E Terminology and Notations • Let G = (V, E) be a graph. • A path in the graph is a sequence of vertices • w , w , . . . , w such that (w , w ) E for1<= i <= N–1. 1 2 N i i+1 E.g., A, B, C, E is a path in this graph

  15. B C A F D E Terminology and Notations • Let w , w , . . . , w be a path. • The length of the path is the number of edges, N–1, one less than the number of vertices in the path. 1 2 N E.g., the length of path A, B, C, E is 3.

  16. B C A F D E Terminology and Notations • Let w , w , . . . , w be a path in a directed graph. • Since each edge (w , w ) in the path is ordered, • the arrows on the path are always directed along • the path. 1 2 N i i+1 E.g., A, B, C, E is a path in this directed graph, but . . . . . . but A, B, C, D is not a path, since (C, D) is not an edge.

  17. B C A F D E Terminology and Notations A path is simple if all vertices in it are distinct, except that the first and last could be the same. E.g., the path A, B, C, E is simple . . . . . . and so is the path A, B, C, E, D, A.

  18. B C A F D E Terminology and Notations If G is an undirected graph, we say it is connectedif there is a PATH from every vertex to every other vertex. This undirected graph is not connected.

  19. B C A F D E Terminology and Notations If G is an directed graph, we say it is strongly connectedif there is a path from every vertex to every other vertex. This directed graph is strongly connected.

  20. B C A F D E Terminology and Notations If G is an directed graph, we say it is strongly connectedif there is a path from every vertex to every other vertex. This directed graph is not strongly connected; e.g., there’s no path from D to A.

  21. B C A F D E Terminology and Notations If G is directed and not strongly connected, but the underlying graph (without direction to the edges) is connected, we say that G is weakly connected. This directed graph is notstrongly connected, but it is weakly connected, since . . .

  22. B C A F D E Terminology and Notations If G is directed and not strongly connected, but the underlying graph (without direction to the edges) is connected, we say that G is weakly connected. . . . since the underlying undirected graph is connected.

  23. B C A F D E Terminology and Notations • Cycle: a path that begins and ends at the same node but doesn't pass through other nodes more than once The path A, B, C, E, D, A is a cycle.

  24. B C A F D E Terminology and Notations • A graph with no cycles is called acyclic. This graph is acyclic.

  25. B C A F D E Terminology and Notations • A graph with no cycles is called acyclic. This directed graph is not acyclic, . . .

  26. B C A F D E Terminology and Notations • A graph with no cycles is called acyclic. . . . but this one is. A Directed Acyclic Graph is often called simply a DAG.

  27. B C A D E Terminology and Notations • A complete graph is one that has an edge between every pair of vertices. Incomplete:

  28. B C A D E Terminology and Notations • A complete graph is one that has an edge between every pair of vertices. (if the graph contains the maximum possible number of edges) • A complete graph is also connected, but the converse is not true Complete:

  29. B C A D E Terminology and Notations • A complete graph is one that has an edge between every pair of vertices. • Suppose G = (V, E) is complete. Can you express |E| as a function of |V|? This graph has |V| = 5 vertices and |E| = 10 edges. Complete:

  30. B C A F D E Terminology and Notations • A free treeis a connected, acyclic, undirected graph. • “Free” refers to the fact that there is no vertex designated as the “root.” This is a free tree.

  31. root B C A F D E Terminology and Notations • A free treeis a connected, acyclic, undirected graph. • If some vertex is designated as the root, we have a rootedtree.

  32. H K G B C A I F J L D E Terminology and Notations • If an undirected graph is acyclic but possibly disconnected, it is a forest. This is a forest. It contains three free trees.

  33. H K G B C A I F J L D E Terminology and Notations • If an undirected graph is acyclic but possibly disconnected, it is a forest. This graph contains a cycle. Therefore it is neither a free tree nor a forest.

  34. Review • In a graph, a vertex is also known as a(n) ______. • node • edge • path • cycle

  35. Review • A graph consists of ______ sets. • two • three • four • five

  36. Review • A subset of a graph’s vertices and edges is known as a ______. • bar graph • line graph • Subgraph • circuit

  37. Review • Two vertices that are joined by an edge are said to be ______ each other. • related to • bordering • utilizing • adjacent to

  38. Review • All ______ begin and end at the same vertex and do not pass through any other vertices more than once. • paths • simple paths • cycles • simple cycles

  39. Review • Which of the following is true about a simple cycle? • it can pass through a vertex more than once • it can not pass through a vertex more than once • it begins at one vertex and ends at another • it passes through only one vertex

  40. Review • A graph is ______ if each pair of distinct vertices has a path between them. • complete • disconnected • connected • full

  41. Review • A complete graph has a(n) ______ between each pair of distinct vertices. • edge • path • Cycle • circuit

  42. Review • The ______ of a weighted graph have numeric labels. • vertices • edges • paths • cycles

  43. Review • The edges in a ______ indicate a direction. • graph • multigraph • digraph • spanning tree

  44. Review • If there is a directed edge from vertex x to vertex y, which of the following can be concluded about x and y? • y is a predecessor of x • x is a successor of y • x is adjacent to y • y is adjacent to x
