  1. Exception Handling (2) Lecture 3 - Instruction Set - Al

  2. 68000 Exception Handling • The 68000’s exception classification • Register that support OS and exceptions • Protecting OS memory • The various exceptions • The exception vectors Lecture 3 - Instruction Set - Al

  3. The 68000’s family exceptions Lecture 3 - Instruction Set - Al

  4. Supervisory State Registers Registers across The processor Family Lecture 3 - Instruction Set - Al

  5. Registers • 68000 • SSP – Supervisor Stack Pointer • System Byte of Status Word • 68010 adds • Vector Base Register • Source Function Code • Destination Function Code • etc Lecture 3 - Instruction Set - Al

  6. Supervisor Memory Space Lecture 3 - Instruction Set - Al

  7. Exceptions and Interrupts • Reset • Externally Generated • Force both the RESET* and HALT* pins low for at least 10 clock cycles • Force the 68000 into a known start-up state • No RTE Lecture 3 - Instruction Set - Al

  8. Exceptions and Interrupts • Bus Error • Externally Generated • Initiated by hardware driving BERR* pin low • A catchall exception • Can be used to indicated non-populated memory has been addressed Lecture 3 - Instruction Set - Al

  9. Exceptions and Interrupts • Interrupt • Hardware generated on pins IPL0*, IPL1*, IPL2* • Pins activated indicated level of interrupt • Bits 8, 9, 10 of the status word indicates level of interrupt needed for service • Interrupting device generates level code through a 8-line-to-3-bit encoder Lecture 3 - Instruction Set - Al

  10. Interrupt Hardware Lecture 3 - Instruction Set - Al

  11. Interrupt HW Level encoder Lecture 3 - Instruction Set - Al

  12. Exceptions and Interrupts • Address Error • Exception occurs when 68000 attempts to access a 16-bit word or 32-bit longword at an odd address • Consider • LEA $7000,A0 Load A0 with $00 7000 • MOVE.B (A0)+,D0 Load D0 with byte at (A0)n incr • MOVE.W (A0)+,D0 Load D0 with word • Final instruction has A0 containing $7001 Lecture 3 - Instruction Set - Al

  13. Exceptions and Interrupts • Illegal Instruction • What happens when you try to execute and op-code that is not defined? • 8-bit uprocessor days • 68000? • Illegal Instruction Exception Lecture 3 - Instruction Set - Al

  14. Exceptions and Interrupts • Divide by Zero • Trying to divide by 0 generates this exception • CHK Instruction • Check Register against bounds • CHK D1,D0 generates an exception if • [D0(0:15)] < 0 • [D0(0:15)] > [D1(0:15)] • Point – useful for compiler writers Lecture 3 - Instruction Set - Al

  15. Exceptions and Interrupts • Privilege Violation • Processor in user state (S-bit is clear) • Attempt to execute a privileged instruction • Trace • Controlled by the trace bit of the status word • Contents of all registers output after each instruction Lecture 3 - Instruction Set - Al

  16. Exceptions and Interrupts • Line 1010 Emulator • Allow creation of special instructions • When this op code is encountered an exception occurs • Remaining bits of instruction word can be used to further specify “user” created instruction • Line 1111 Emulator • A second version Lecture 3 - Instruction Set - Al

  17. Exceptions and Interrupts • Un-initialized Interrupt Vector • When a 68000 device causes and interrupt • During IACK device supplies ID • If not yet initialized $0F is sent so device can be initialized • 68000 Devices respond with $0F when reset Lecture 3 - Instruction Set - Al

  18. Exceptions and Interrupts • Spurious Interrupt • IACK generated but no response? • Prevents hanging when no device responds to IACK after an IPL0-IPL2 pin pulled low • TRAP (Software Interrupt) • TRAP #x where x is from 0 to 15 ($0 to $F) • Allows creation of unique instructions Lecture 3 - Instruction Set - Al

  19. Exceptions and Interrupts • TRAPV Instruction • Trap on overflow • “IF V=1 THEN exception ELSE continue” • Double Bus Fault • Example: A bus error occurs and while responding to this a second bus error occurs? • 68000 halts!!! Lecture 3 - Instruction Set - Al

  20. Exception Vectors • 256 longwords (512 words) • Extend form address $00 0000 to $00 03FF Lecture 3 - Instruction Set - Al

  21. Exception Vector Table • Table located in low memory • Schemes allow relocation to other addresses Lecture 3 - Instruction Set - Al

  22. How would you implement the table in memory? • How would you allow the movement of the table to other addresses of memory? Lecture 3 - Instruction Set - Al
