  1. Network Printer Server

  2. Contents • Samsung Network Printer • Network Printer Server Software • Firmware • Management Software • Protocols and Services • Troubleshooting

  3. Cezanne Network’s Comparison with other models Network Feature

  4. Samsung Network Printer Main Operation Role Network Printing Network Scanning Device Configuration Getting information from device Administrator's PC User Internet User MFP Protocols NW Printer • TCP/IP • 9100,LPR,IPP… • SNMP,HTTP… • NetWare (IPX/SPX) • EtherTalk (Macintosh) Network Sharing Connectivity Wired (10/100 Base TX) Wireless (802.11 a/b/g)

  5. Network Printer Server Software Samsung SyncThru (~2004) Samsung SyncThru Web Admin Service (2005~) Samsung Network Embedded Web Server (~2004) Samsung SyncThru Web Service(2004~) Samsung SetIP Samsung IPP Client (~2005 1Q) HP JetAdmin, WebJetAdmin Samsung SmarThru WorkFlow Network Card Management Software Management Software Client Computer’s Printing Port Monitor Samsung Port Monitor HP Port Monitor Microsoft Port Monitor

  6. Network Printer Server Software Network Printer Detection Add Network Printing Port Network Card Configuration Network Printer Configuration Network Card Firmware Upgrade Samsung SyncThru Targets Management Program for Printer Administrator Running on Microsoft Windows only Features

  7. Network Printer Server Software Samsung SyncThru Network Printer Client Computer Network Printer Network Printer Samsung SyncThru Network Connection

  8. SyncThru Web Admin Service Web based Printer Management Solution Network Printer Server Software MFP NW Printer SNMP SNMP SNMP HTTP MFP Administrator's PC Detecting device on the network Performing Maintenance operations Getting detailed reports and statistics on device events For more information, please refer to network application guide. SyncThru Web Admin Service Server

  9. Network Printer Server Software SWAS Device Menu • Detecting and Displaying devices on the network Device information in the network

  10. Network Printer Server Software SWAS Device Menu Display general , Supply, Protocols, Status, Usage meters, Alert, Diagnostics information and Plug-INs Detail information of device by double-click

  11. SWAS Plug-in • Plug-in Structure • SyncThruTM Web Admin Service can install additional function to support Pug-in and manage optionally. • Device Cloning • Support the property copy between machines and the reservation function when setting the property value of multiple Printing devices. • File Storage • Delete, move and copy Font/Form/Macro on the printer • Only model attached HDD Can Support this function. • Job Accounting • Restrict the job to assign job’s right for Pinrt/Copy/Scan/Fax job to personal user. • Only model attached HDD Can Support this function.

  12. Device Cloning Plug-in ▶Device Cloning Fucntion :Support the property copy between machines and the reservation function when setting the property value of multiple Printing devices. (Current Support Model : SCX-6345N) 삼성 디바이스 삼성 프린터#2 Complete Device Cloning Reservation. I will confirm the result at tomorrow morning. ^^ 삼성 프린터#1 삼성 프린터 #3 관리자 PC

  13. File Storage Plug-in ▶Font/Form/Macro Management Function : Delete, move and copy Font/Form/Macro on the printer (Current Support Model: SCX-6345N) Target Printer #1 Target Printer #2 Download font remotely Target Printer #3 Administrator

  14. Job Accounting Plug-in ▶User Account Setting Fucntion : Restrict the job to assign job’s right for Pinrt/Copy/Scan/Fax job to personal user. (Current Support Model : SCX-6345N) User#2 can’t do color copy User #PC1 User#1 can’t print only 100pages.. Administrator Support Personal Usage Report

  15. JMS Diagram ① N/W Card EWS ② HDD JMS • The program that manage printing job of Model attached HDD • Because Java aapling embedded in HDD is running, User can use the same UI anywhere regardless of OS.

  16. Network Printer Server Software Samsung SetIP Configuration of IP Address • Mostly used at first installation of network printer • IP address setting with MAC address only • MAC address is written on printer’s backside Samsung SetIP Utility • Running on Microsoft Windows OS only • Automatic detection of Samsung network printers • Manual setting of undetected network printers

  17. Network Printer Server Software Web Server Samsung SyncThru Web Service SyncThru Web Service (SWS) • is new name for Samsung Embedded Web server. • is a HTTP daemon running as a part of firmware • accepts HTTP request via port 80 as normal web servers. • provides interface to users information of networked printers and allow to configure the setting of printers • is able to provide more complicated options than Local UI for printer configuration http://10.240.9.170 IP: 10.240.9.170 HTTP User

  18. Network Printer Server Software Samsung SyncThru Web Service Features Embedded Web Server Web User Interface http://NPC-IP-Address/ Functionality General Information Machine Settings Network Settings Maintenance Support

  19. Network Printer Server Software Samsung SyncThru Web Service: General Information (Printer) General Information Machine Status Supplies Status Network Information Firmware Version Print Information

  20. Network Printer Server Software Samsung SyncThru Web Service: Machine Settings (Printer) Machine Settings Layout Setup Printer Paper Graphic PCL PS EPSON Color Email-Notification Setup …

  21. Network Printer Server Software Samsung SyncThru Web Service: Network Settings Network Settings General EtherTalk NetWare TCP/IP SLP SNMP Raw TCP/IP, LPR, IPP IP Filtering Wireless UPnP Reset

  22. Network Printer Server Software Samsung SyncThru Web Service: Maintenance Maintenance Firmware Upgrade Security

  23. Network Printer Server Software Samsung SyncThru Web Service: Support Support Contact Information Link

  24. Network Software (Firmware) Protocol Printing Protocol • TCP/IP protocol printing • Standard TCP/IP printing (9100 port) • LPR (515 port) • IPP (Internet Printing Protocol / 631 port) • Samsung Network Port (2000 port) • Netware printing • IPX/SPX suite (Novell Netware Network Environment) • EtherTalk printing (AppleTalk) • Macintosh printing Management Protocol • IP assignment Protocol • DHCP, BOOTP, AutoIP • Discovery Protocol • SLP, mDNS (Bonjour), UPnP, SNMP, SetIP, WINS • Configuration Protocol • SNMP, HTTP, LDAP Network Scan Protocol • Scan To Network • Email (SMTP), FTP, SMB, Client

  25. Network Printer Server Software TCP/IP Printing Protocol Samsung Network Printer Port Printing • TCP Port : 2000 • Port Monitor installation • OS : Windows95/98/NT/ME LPD (Line Printer Daemon) Printing • TCP Port : 515 • OS : Unix, Linux, Windows OS (Win NT, 2K ~) • An existing print server protocol widely used on the Internet for communicating between line printer daemons

  26. Network Printer Server Software TCP/IP Printing Protocol Microsoft Standard TCP/IP Printing • TCP Port : 9100 • OS : Windows OS (Win 2K~), Mac OS (Mac 10.3~) • Originally designed by HP • Raw printing protocol (Microsoft Standard TCP/IP port) • Samsung network printer supports bi-directional printing communication (IBM AS400) • LAN Fax of SmarThru4.0 uses this bi-directional channel • (SCX-5x30 Series, SCX–6x22 Series , SCX-4725 Series, CLX-3160 Series…)

  27. Network Printer Server Software IBM AS/400 Machines • Bidirectional Printing Communication (Raw TCP IP Port) Printer Print data Network PJL Query (Printer status) @PJL status AS/400 machine queries the status of the printer Printer parses PJL query and sends printer status to AS/400 AS/400 will now send print data Printer prints the received data Repeat step A to D.

  28. Network Printer Server Software Internet End-User TCP/IP Printing Protocol IPP Printing Protocol • TCP Port : 631 • OS : Windows OS (Win 2K~), Mac OS (Mac 10.3~), Novell OS • IPP (Internet Printing Protocol) is an Internet standard protocol • that defines operations and attributes for application-level printing over the Internet .

  29. Network Printer Server Software IPX/SPX Printing Protocol IPX/SPX Port Printing • OS : Windows95/98/ME/2000/XP/2003 • Same Frame Type and Network Number Netware Server Printing • Novell Netware Server Queue Printing • Novell Client Login • Queue Create on Netware Server • PSERVER Mode / RPRINTER Mode • NDPS Gateway Printing • Same Frame Type and Network Number

  30. Network Printer Server Software 1. DISCOVER 2. OFFER DHCP Client 3. REQUEST DHCP Server 4. ACK DHCP (Dynamic Host Configuration Protocol) DHCP is a communication protocol enabling network administrators to centrally manage and to automate the assignment of IP addresses in a network. In an IP network, each device needs a unique IP address. DHCP lets a network administrator supervise and distribute IP addresses from a central point and automatically sends a new IP address when a device is plugged into a different place in the network.

  31. Network Printer Server Software DNS (Domain Name System) DNS is used for registration of domain names and provides Host names to an IP address resolution service. For printer devices, DNS may be utilized for printer domain name registration, so that print server clients may refer to the printer by its host name rather than by its IP address. Even though a printer’s IP address is changed, all clients can operate this printer without reconfiguration. Addressing to a printer device by IP address is not convenient and may often go stale if an IP address to a device is assigned dynamically via a DHCP server. If the DHCP server can provide information about a printer’s changing IP address to the DNS server automatically, user convenience is increased. The printer’s name will be used as its DNS name.

  32. Network Printer Server Software WINS (Windows Internet Name Service) WINS proprietary Microsoft name resolution service WINS servers maintain computer names (NetBIOS names) and IP addresses automatically. WINS is used to dynamically provide an NT-based domain name server with the names and IP addresses of Windows computers.

  33. Network Printer Server Software SLP (Service Location Protocol) SLP (Service Location Protocol) is an Internet standard network protocol that provides a framework to allow networking applications to discover the existence, location, and configuration of networked services with human readable text string. Character Encoding : UTF-8 (SLP v2) Using TCP/UDP port : 427. SLP Security : IPSec. SLP Multicast Address : 1. 239.255.255.253 : RFC2608 2. 224.0.1.127 : Requested By Xerox (Xerox Device Discovery) 3. In the absence of Multicast support, Broadcast may be used. SLP is used for detecting network printer server in Syncthru WAS

  34. Network Printer Server Software Multicast DNS - Bonjour (Old name : Rendezvous) Automatic discovery of computers, devices, and services on IP networks Automatically find each other without the need to enter IP (Internet Protocol) addresses or configure DNS (Domain Name Service) servers Listens for multicast DNS queries on TCP/IP port 5353 Sends responses for Multicast DNS queries to multicast address 224.0.0.251 DNS domain: “< Host Name > + .local” Services Zero Configuration Networking Multicast DNS DNS Service Discovery http://www.apple.com/macosx/features/bonjour/ Bonjour for Windows - Bonjour is useful for detecting network printer server on internet explore and add network printer port.

  35. Network Printer Server Software • SNMP (Simple Network Management Protocol) • SNMP facilitates the exchange of management information between network devices. It enables network administrators to remotely monitor and configure network devices, find and solve network problems, and plan for network growth. • Network devices are monitored and controlled using four basic SNMP commands: • • read: is used by a Network Management server to monitor network devices. The server examines different variables that are maintained by the devices. • • write: is used by a Network Management server to control managed devices. The server changes the values of variables stored within the devices. • • trap: is used by network devices to asynchronously report events to a Network Management server. When certain types of events occur, a device sends a trap to the specified server.

  36. Network Printer Server Software SNMPv3 (Simple Network Management Protocol - A Security Enhancement for SNMP ) • SNMPv3 • = SNMPv2 + administration + security • SWS -> Network Settings -> SNMPv3 1. User Name : • SNMPv3 Account user name • 2. Authentication Password : • a 16-byte hexadecimal value • for authenticating the SNMP packet • contents using the MD5 algorithm. • 3. Privacy Password : a 16-byte hexadecimal value for encrypting the data portion of the SNMP packet using the DES algorithm.

  37. Network Printer Server Software Web Server HTTP (Hypertext Transfer Protocol ) • HTTP is an application layer protocol for distributed, collaborative, hypermedia information systems. • The Samsung Network Printer has a built-in web server, SyncThru Web Service. You can configure and manage your network print server through SyncThru Web Service using HTTP over TCP/IP. • Used in IPP Protocol IP: 10.240.9.170 http://10.240.9.170 User

  38. Network Printer Server Software 웹 서버 HTTPS (Secure Hypertext Transfer Protocol ) • Secure, encrypted Web-based communication is provided through the Secure HTTP (HTTPS) protocol. • SWS -> Machine Settings -> Secure Web • To support the use of HTTPS communications, an certificate must be installed. • HTTPS TCP Port Number is 443. • HTTPS URL uses 'https://‘ instead of 'https://' IP: 10.240.9.170 https://10.240.9.170 사용자

  39. Network Printer Server Software HTTPS Configuration - Self Certificate • SWS -> Machine Settings -> Secure Web • Create New Certificate (Self Certificate) • Input information and create certificate • Enable Web Security • Accept certificate from device and use HTTPs

  40. Network Printer Server Software HTTPS Configuration - Certificate Signing Request • SWS -> Machine Settings -> Secure Web • Create New Certificate (Certificate Signing Request ) • Input information • Download a Certificate Signing Request .(X.509 or DER) • Submit a Certificate Signing Request to Trusted Certificate Authority and acquire certificate (Next Page) • Upload certificate and enable Secure Web

  41. Network Printer Server Software HTTPS Configuration - Certificate Signing Request (Example of Windows Trusted Certificate Authority) • Access Trusted Certificate Authority Web Site. • Request Certificate -> Advanced request certificate. (Base 64 Encoding MC or PKCS #10 ….) • Submit a Certificate Signing Request (Find - X.509 or DER) • Select type of Certificate (DER encode or Base64 encode) and download certificate. • Upload certificate to device and enable HTTPS

  42. Wireless Security Spec Network Printer Server Software • Static WEP • 64bit / 128bit WEP • WPA-Personal • TKIP / AES • WPA2-Personal • AES • mixed mode : TKIP+AES • WPA-Enterprise • WPA2-Enterprise • Other mixed mode security

  43. Wireless Main Page Connection Status SSID Operation Mode BSSID Wireless Settings Wizard Custom Network Printer Server Software

  44. Wireless Settings - Wizard SSID Setup Network Name Operation Mode Security Link Quality Network Printer Server Software

  45. Wireless Settings - Wizard WEP Security Setup 802.11 Auth Open System Shared Key Using Key Key1~4 Key Length 64bit 128bit Key Type Alphanumeric Hexadecimal WEP Key 5 or 13 char Network Printer Server Software

  46. Wireless Settings - Wizard WPA-Personal Security Setup WPA Encryption WPA Key Network Printer Server Software

  47. Wireless Settings - Wizard Wireless Settings Confirmation

  48. Wireless Settings - Custom Custom Setting Ad-hoc Setting Other WEP Key2~4 Hexa Network Printer Server Software

  49. Troubleshooting Before troubleshooting • LAN cable check • Connected or Not connected • Wrong cable (defected cable, crossover cable) • Connection connector (Link partner check) • Network LED check • Link LED check (Link LED On when connected) • Activity LED check (No packet Regularly blinking, packet random blinking depend on Printer Model) • Print Network test page • Printed correctly. If not, NIC is in lock up state or NIC can not communicate with printer • Network address value check : IP address, Subnet Mask, Gateway, MAC address • NIC F/W version (Correct or not) • V1.0x.xx : NPC3 • V2.0x.xx : NPC3H • V3.0x.xx : PHY Board • V4.0x.xx : On Board • Protocol Enable / Disable • WLAN module / Status check if WLAN available.

  50. Troubleshooting Before troubleshooting • Printer SET status check • Toner Empty, Paper Empty and so on : Hard Stop cases (Job can be finished completely) Network Printer Configuration check • Address Conflict check • IP address Conflict : Same IP address in a network • Unplug network cable and PING test • MAC address Conflict : Same MAC address in a physical network • Default MAC address or same MAC address (PING and ARP –a) • IP get method check (Panel or SWS) • DHCP/BOOTP : IP can be changed after rebooting • Auto IP address : Xerox Model default on • Protocol Enable / Disable, Port Number (In SWS) • IP filtering On/Off • SNMP community name check (When SNMP no response)
