  1. BERKER KNX TOUCH SENSORS

  2. THE BERKER TOUCH SENSORS TS SENSOR R.3 TOUCH SENSOR R.1 TOUCH SENSOR

  3. THE BERKER TOUCH SENSORS • The Touch Sensors standsfor… • INNOVATIV AND MODERNfine material and design, combined with highly efficient electronic • COSMOPOLITIANworldwide compatible design language • UNIQUEThere is no real comparable product in the market • QUATLITY CONCIOUSgenuine high-class material, precise finish

  4. TS SENSOR R.1 / R.3 TOUCH SENSOR TECHNOLOGY / DISPLAY CUSTUMISED PARAMETER TECHNICAL DATA Bekrer TS Sensor and R.Touch Sensor

  5. TS SENSORDESIGN AND VERSIONS • white status LED • Blue ON LED • Versions: • 1gang – 4gang • 2gang & 3gang with RTR • Variants: polar white, black und aluminium Bekrer TS Sensor and R.Touch Sensor

  6. TS SENSOR COMFORTOVERVIEW • Productname: Glass sensor, x-gang, comfort with integral bus coupling unit • Order No: 7514 xx xx Bekrer TS Sensor and R.Touch Sensor

  7. TS SENSOR COMFORTOVERVIEW • Only suitable for KNX/EIB • Integrated bus coupling unit • Internal temperature sensor • Connection for external temperature sensor (e.x. 161 Floor temperature sensor / remote sensor) • pure ETS Application (no PlugIn-Software) Bekrer TS Sensor and R.Touch Sensor

  8. TS SENSOR RTR DISPLAYOVERVIEW • Productname: Glass sensor x-gang with room thermostat • Order No: 7564 xx xx Bekrer TS Sensor and R.Touch Sensor

  9. TS SENSOR RTR DISPLAYOVERVIEW • Darkdesign Display – by semi-printing is an "invisible" effect • Display – language neutral – mostly symbols Bekrer TS Sensor and R.Touch Sensor

  10. TS SENSOR RTR DISPLAYOVERVIEW • Only suitable for KNX/EIB • Integrated bus coupling unit • Internal temperature sensor • Connection for external temperature sensor (e.x. 161 Floor temperature sensor / remote sensor) • Seperate auxiliary power supply needed (18…30 V DC) Bekrer TS Sensor and R.Touch Sensor

  11. TS SENSOR RTR DISPLAYADDITIONAL POWER • TS Sensor RTR needs an additional power supply • KNX output without choke can be used • 2. Wire pair of KNX cable (yellow – white) can be used • Power consumption max. 0,5 W(i.e. 30 V ca. 17 mA) e.g: 7591 00 03 Bekrer TS Sensor and R.Touch Sensor

  12. TS SENSORMOUNTING • Low Building height (5,7mm) • Glass surface • Screwless mounting on special wallbox (1870 or 1871) • Optional adapter ring for anti dismanting protection and „shadow gap“ • The adapter ring will incread the building hight up to 10,7mm Bekrer TS Sensor and R.Touch Sensor

  13. TS SENSORSTRUCTURE • terminal connection for KNX/EIB bus cable • terminal connection for wired floor temperature/remote sensors (optional accessories) • Programming button – programming LED • terminal connection for additional power supply (ONLY TS SENSOR RTR) Bekrer TS Sensor and R.Touch Sensor

  14. TS SENSOR R.1 / R.3 TOUCH SENSOR TECHNOLOGY / DISPLAY CUSTUMISED PARAMETER TECHNICAL DATA Bekrer TS Sensor and R.Touch Sensor

  15. R.1 / R.3 TOUCH SENSORDESIGN AND VERSIONS • R.1 (soft) and R.3 (hard) version • white status LED‘s • Blue operation LED in the buttom • Versions: • 1gang – 4gang • 2gang & 3gang with RTR • Variants: polar white, black Bekrer TS Sensor and R.Touch Sensor

  16. R.1 / R.3 TOUCH SENSOR OVERVIEW • Construction like R.1 / R.3 • 7mm plastic plate with a 3mm glas surface • Can be mounted on a normal wall box • Connection for external temperature sensor (e.x. 0161 Floor temperature sensor / remote sensor) Bekrer TS Sensor and R.Touch Sensor

  17. R.1 / R.3 TOUCH SENSOR COMFORTOVERVIEW • Productname: Berker R.x Touch Sensor, x-gang comfort • Order No: 7514 xx xx Bekrer TS Sensor and R.Touch Sensor

  18. R.1 / R.3 TOUCH SENSOR COMFORTOVERVIEW • Only suitable for KNX/EIB • Integrated bus coupling unit • Internal temperature sensor • Connection for external temperature sensor (e.x. 161 Floor temperature sensor / remote sensor) Bekrer TS Sensor and R.Touch Sensor

  19. R.1 / R.3 TOUCH SENSOR RTROVERVIEW • Productname: Berker R.x Touch Sensor, x-gang with RTR • Order No: 7564 xx xx Bekrer TS Sensor and R.Touch Sensor

  20. R.1 / R.3 TOUCH SENSOR RTROVERVIEW • Only suitable for KNX/EIB • Display in „Dark design“ • Integrated bus coupling unit • Internal temperature sensor • Connection for external temperature sensor (e.x. 161 Floor temperature sensor / remote sensor) • Seperate auxiliary power supply needed (18…30 V DC) Bekrer TS Sensor and R.Touch Sensor

  21. R.1 / R.3 TOUCH SENSORMOUNTING • Constroction like the designs R.1 or R.3 • Mounting on a „normal“ 2gang wallbox • With mountingframe and screw for anti dismanting protection Bekrer TS Sensor and R.Touch Sensor

  22. R.1 / R.3 TOUCH SENSORSTRUCTURE • terminal connection for KNX/EIB bus cable • terminal connection for wired floor temperature/remote sensors (optional accessories) • Programming button – programming LED • terminal connection for additional power supply (ONLY TS SENSOR RTR) Bekrer TS Sensor and R.Touch Sensor

  23. TS SENSOR R.1 / R.3 TOUCH SENSOR TECHNOLOGY / DISPLAY CUSTUMISED PARAMETER TECHNICAL DATA Bekrer TS Sensor and R.Touch Sensor

  24. TS SENSOR / R.x TOUCH SENSORTECHNOLOGY • Functional Principle (Quelle: Quantum) Bekrer TS Sensor and R.Touch Sensor

  25. Comfort Thermostat disabled Indoor temperature Heating/cooling Standard Frost/heat protection Outdoor temperature Night Sensor surfaces disabled Display for values (time/temperature) Basesetpoint shift Fan stages 1-3 Display of the day of the week TS SENSOR / R.x TOUCH SENSORSTRUCTURE OF THE DISPLAY For future applications Use of the proven display symbols Bekrer TS Sensor and R.Touch Sensor

  26. TS SENSOR R.1 / R.3 TOUCH SENSOR TECHNOLOGY / DISPLAY CUSTUMISED PARAMETER TECHNICAL DATA Bekrer TS Sensor and R.Touch Sensor

  27. TS SENSOR / R.x TOUCH SENSORCOSTUMIZED • Example: TS Sensor Configurator Bekrer TS Sensor and R.Touch Sensor

  28. OVERVIEW MOUNTING DISPLAY CONFIGURATION PARAMETER TECHNICAL DATA Bekrer TS Sensor and R.Touch Sensor

  29. TS SENSOR / R.x TOUCH SENSORPARAMETER / ETS CONFIGUTATION • TS Sensor and R.x Touch Sensors work with naerly the same technic. Therefore we show only the TS Sensor RTR ETS application. Bekrer TS Sensor and R.Touch Sensor

  30. TS SENSOR RTR DISPLAYETS PARAMETERGENERAL Bekrer TS Sensor and R.Touch Sensor

  31. TS SENSOR RTR DISPLAYETS PARAMETER • Gerneral settings • Choose between „Rocker“ or „Button“ Function Bekrer TS Sensor and R.Touch Sensor

  32. TS SENSOR RTR DISPLAYETS PARAMETER • Function of the „Rocker“ • Function of the „Button“ Bekrer TS Sensor and R.Touch Sensor

  33. TS SENSOR RTR DISPLAYETS PARAMETER • Functionofthe Status LED Bekrer TS Sensor and R.Touch Sensor

  34. TS SENSOR RTR DISPLAYETS PARAMETER DISABLEFUNCTION Bekrer TS Sensor and R.Touch Sensor

  35. TS SENSOR RTR DISPLAYETS PARAMETER DISABLEFUNCTION Bekrer TS Sensor and R.Touch Sensor

  36. TS SENSOR RTR DISPLAYETS PARAMETER ALARMSIGNAL Todisplay an externalalarm (eg wind alarm) Bekrer TS Sensor and R.Touch Sensor

  37. TS SENSOR RTR DISPLAYETS PARAMETER ROOM TEMP. CONTROL Bekrer TS Sensor and R.Touch Sensor

  38. TS SENSOR RTR DISPLAYETS PARAMETER ROOM TEMP. CONTROL Bekrer TS Sensor and R.Touch Sensor

  39. TS SENSOR RTR DISPLAYETS PARAMETER ROOM TEMP. CONTROL Bekrer TS Sensor and R.Touch Sensor

  40. TS SENSOR RTR DISPLAYETS PARAMETER ROOM TEMP. CONTROL Bekrer TS Sensor and R.Touch Sensor

  41. TS SENSOR RTR DISPLAYETS PARAMETER ROOM TEMP. CONTROL Bekrer TS Sensor and R.Touch Sensor

  42. TS SENSOR RTR DISPLAY ETS PARAMETER ROOM TEMP. CONTROL Bekrer TS Sensor and R.Touch Sensor

  43. TS SENSOR RTR DISPLAY ETS PARAMETER ROOM TEMP. CONTROL Bekrer TS Sensor and R.Touch Sensor

  44. TS SENSOR RTR DISPLAYETS PARAMETER DISPLAY SETTINGS Bekrer TS Sensor and R.Touch Sensor

  45. TS SENSOR RTR DISPLAYETS PARAMETER DISPLAY SETTINGS Bekrer TS Sensor and R.Touch Sensor

  46. IN DETAILAPPLICATION – UTILITY • Single-family houses (private application) • Room control device • Display of set temperatures(e.g. as absolute display) Bekrer TS Sensor and R.Touch Sensor

  47. IN DETAILAPPLICATION – UTILITY • Properties (public buildings, offices, business premises, etc.) • Room control device • Display of set temperatures (e.g. as difference from actual temperature) Bekrer TS Sensor and R.Touch Sensor

  48. TS SENSOR RTR DISPLAYETS PARAMETER SCENE Bekrer TS Sensor and R.Touch Sensor

  49. TS SENSOR RTR DISPLAYETS PARAMETER SCENE Bekrer TS Sensor and R.Touch Sensor

  50. OVERVIEW MOUNTING DISPLAY CONFIGURATION PARAMETER TECHNICAL DATA Bekrer TS Sensor and R.Touch Sensor
