  1. Mars: Basic Planetary Characteristics Geography 494-01 S/07 Dr. Christine M. Rodrigue C.M. Rodrigue, 2007 Geography, CSULB

  2. Mars in Space • Orbital Characteristics • Planetary orbits are elliptical • The major focus of Mars' or Earth's orbit is inside the Sun • The plane of that orbit is the ecliptic • The diameter of the orbit along its long axis is the major axis • Half that distance is the semi-major axis (here shown as a) • The diameter of the planet's orbit along its short axis is the minor axis • Half that is the semi-minor axis • C on this graph is the distance from the center of the orbit to one focus • Eccentricity is c/a – 0 for a perfect circle C.M. Rodrigue, 2007 Geography, CSULB

  3. Mars in Space • Orbital Characteristics • Mars’ and Earth’s eccentricity • Mars has one of the greatest eccentricities in the solar system at 0.0934 • Earth is one of the more circular at 0.0167 C.M. Rodrigue, 2007 Geography, CSULB

  4. Mars in Space • Orbital Characteristics • Mars’ solar irradiance and surface insolation averaged over the year • Very freaky: South polar regions get the most solar radiation due to greater axial tilt, greater eccentricity, and the greater length of day • The length of day overcompensates for the lower sun angle • GEOG 442 students can compare with Lab 1 C.M. Rodrigue, 2007 Geography, CSULB

  5. Mars in Space • Orbital Characteristics • Mars’ and Earth’s distance from the Sun • Mars is about 227,936,640 km from the Sun averaged along the semi-major axis • Earth is 149,597,890 km • Solar irradiance at Mars is about 590 W/m2 versus 1,350 W/m2 at Earth (~44%) C.M. Rodrigue, 2007 Geography, CSULB

  6. Mars in Space • Orbital Characteristics • Mars’ and Earth’s distance from the Sun • Solar irradiance at Mars is about 590 W/m2 versus 1,350 W/m2 at Earth (~44%) C.M. Rodrigue, 2007 Geography, CSULB

  7. Mars in Space • Orbital Characteristics • Mars’ and Earth’s distance from the Sun • Solar irradiance at Mars is about 590 W/m2 versus 1,350 W/m2 at Earth (~44%) • Here, it would be like living on Earth at 54 N or S in March or September C.M. Rodrigue, 2007 Geography, CSULB

  8. Mars in Space • Orbital Characteristics • Mars’ and Earth’s distance from the Sun • Mars at perihelion is 206,600,000 km (Southern Hemisphere summer) • Earth is 147,100,000 km (also Southern Hemisphere summer) • Mars at aphelion is 249,200,000 km • Earth is 152,100,000 km • So, Mars perihelion distance is only 82.9% of its aphelion distance • On Earth, perihelion is 96.7% of aphelion • On Earth, this difference is a trivial influence, especially since perihelion hits during the more oceanic hemisphere’s summer • On Mars, it’s a major seasonal driver C.M. Rodrigue, 2007 Geography, CSULB

  9. Mars in Space • Orbital Characteristics • Mars’ and Earth’s changes in eccentricity • Planets’ orbital shapes alternate between more circular and more elliptical • Earth’s varies from ~0.01 to ~0.05 over a cycle of ~100,000 years • Mars’ varies from close to 0.00 to ~0.14 C.M. Rodrigue, 2007 Geography, CSULB

  10. Mars: Data from Robotic Missions • Rotational characteristics • Axial tilt or obliquity: • Mars: 2511’ 24” (25.19 ) from the vertical of the ecliptic • Earth: 2326’24” (23.44) from the vertical of the ecliptic • Mars’ axis precesses 360  in 93,000 Martian years or ~125,000 Earth years • Earth’s axis precesses 1 per 71.6 years or 360 in 25,765 years C.M. Rodrigue, 2007 Geography, CSULB

  11. Mars: Data from Robotic Missions • Size • Mars and Earth compared: • Mars’ equatorial radius: 3,397 km (Earth: 6,378 km) • Equatorial circumference: 21,344 km (Earth: 40,075 km) • Volume: 163,140,000,000 km3 (Earth: 1,083,200,000,000 km3 • Mass: 641.85 x 1018 metric tons (Earth: 5,973.70 x 1018 metric tons) • Mean density: 3.94 g/cm3 (Earth: 5.52 g/cm3), where water = 1.00 • Equatorial surface gravity: 3.693 m/s2 (Earth: 9.766 m/s2) or about 38% of Earth’s • Escape velocity: 11.18 km/sec (Earth: 5.02 km/sec) C.M. Rodrigue, 2007 Geography, CSULB

  12. Mars in Space • Size • Mars’ and Earth’s relative sizes compared C.M. Rodrigue, 2007 Geography, CSULB
