Synchronization

Shared Memory Thread Synchronization • Threads cooperate in multithreaded environments • User threads and kernel threads • Share resources and data structures • E.g. memory cache in a web server • Coordinate execution • Producer/consumer model • For correctness, cooperation must be controlled • Must assume threads interleave execution arbitrarily • Scheduler cannot know everything • Control mechanism: synchronization • Allows restriction of interleaving • Note: This is a global issue (kernel and user) • Also in distributed systems

Shared Resources • Our focus: Coordinating access to shared resource • Basic Problem: • Two concurrent threads access a shared variable • Accessmethods: Read-Modify-Write • Two levels of approach: • Mechanisms for control • Low level locks • Higher level mutexes, semaphores, monitors, condition variables • Patterns for coordinating access • Bounded buffer, producer/consumer, …

The Classic Example • Managing a bank account: • Suppose account is shared between 2 people • What happens if both people go to ATMS and deposit $$? int balance; void deposit(int amount) { balance += amount; } int withdraw(int amount){ balance -= amount; return balance; }

Cooperating Requires Synchronization • Deposit implemented as sequence of ASM instructions void deposit(int amount) { balance += amount; } Load R1, balance Add R1, amount Store R1, balance • What happens if two processes call deposit at same time? Process 1 Process 2 Load R1, balance Add R1, amount Store R1, balance Load R1, balance Add R1, amount Store R1, balance • Race Condition: Result depends on operation interleaving

Interleaved Schedules • Execution of the two threads can be interleaved • Assume uniprocessor w/ preemptive scheduling Load R1, balance Add R1, amount Context Switch Instruction Sequence as seen by CPU Load R1, balance Add R1, amount Store R1, balance Context Switch Store R1, balance • What’s the account balance after this sequence?

But doesn’t the x86 do this for us? • X86 allows memory operands CISC (x86) Load/Store Arch (micro ops) HW decoder asm (“addl %1, %0\n”, : “+m”(balance) : “r”(amount) : ); Load R1, balance Add R1, amount Store R1, balance • Answer: NO • X86 instructions implemented using micro-ops in HW • Instructions decomposed into RISC instructions by CPU decoding logic • X86 is load/store under the covers • So a “single” x86 instruction is actually a sequence of micro instructions

The crux of the matter • Two concurrent threads access a shared resource without any synchronization • Creates a Race condition • Output is non-deterministic and depends on timing • We need mechanisms for controlling access to shared resources • Allows us to reason about program operation • Re-introduces determinism • Synchronization is necessary for any shared data structure

When are resources shared? • Local variables are not shared • Refer to data on stack, each thread has its own stack • But… only if you don’t give another thread a reference to a local variable • Global variables are shared • Stored in static data segment • Globally accessible by any thread • Dynamic objects are shared • Stored in the heap, shared if you have a pointer

Mutual Exclusion • Mutual exclusion synchronizes access to shared resources • Code requiring mutual exclusion for correctness is a “critical section” • Only one thread at a time can execute in critical section • All other threads must wait to enter • Only when a thread leaves can another can enter

Scheduler assumptions inti = 0; • Who wins? • Is it guaranteed that someone wins? • Answer: We cannot know • There is randomness in the system (From where?) • Interruptsand the scheduler Thread A Thread B while (i < 10) { i++; } printf(“A won!\n”); while (i > -10) { i--; } printf(“B won!\n”);

Easy solution for uniprocessors • Problem== Preemption • Solution == Disable Preemption • Sources of preemption • Voluntary preemption: Controlled by thread • Involuntary preemption: Controlled by Scheduler • How is scheduler invoked? • Solution: • Disable interrupts and do not give up CPU • On Linux w/ a single processor all spinlocks are translated to: asm (“cli”); and asm(“sti”);

Critical Section Requirements • Mutual exclusion • Only one process in critical section at a time • Progress (Deadlock free) • A process in a critical section cannot block • Cannot depend on other processes • Bounded (Starvation free) • Waiting processes must eventually proceed • Performance • Overhead of entering and exiting a critical section is small (relative to work done inside it) • Busy waiting can cause serious problems (spin wait) • Fair • Don’t make some processes wait longer than others

Implementing Critical Sections • To implement critical sections, need atomic operations • Atomic Operations: No other instructions can be interleaved • Examples of atomic operations • Memory accesses • Loads & stores • Cache coherency ensures atomicity • Code between interrupts on a single CPU/core • But interrupts can happen randomly… • Must explicitly disable interrupts • Special instructions • Test-and-Set • Compare-and-Swap • Etc…

But the x86 is not atomic! CISC (x86) Load/Store Arch (micro ops) HW decoder • The x86 offers a special instruction mode that forces atomicity • Only for a single instruction!! • Lock Prefix: Forces all micro-ops of a single instruction to execute atomically • Asserts a lock signal on the memory bus • Disallows other CPUs/cores from accessing memory region • asm (“lock <instr>” ::: ) asm (“addl %1, %0\n”, : “+m”(balance) : “r”(amount) : ); Load R1, balance Add R1, amount Store R1, balance

Critical Section Building Blocks • OK we have single instruction atomicity… • Now what? • Build higher level synchronization in OS • Abstraction! • Small set of operations (that absolutely must be correct!!) Locks Semaphores Monitors Condition Variables Memory accesses Test-and-set Compare-and-swap Disable Interrupts Lock memory bus • Small set of operations (that absolutely must be correct!!)

Mechanisms for Building Critical Sections • Locks • Very primitive with minimal semantics • Used heavily in kernel • Semaphores • Basic • Easy to understand • Hard to use • Monitors • High level • Modern variants require language support (i.e. Java: synchronized) • Linux Kernel: Wait queues

Locks • Lock: An object in memory that provides 2 operations • Acquire(): Called before critical section entry • Release(): Called after critical section exit • Always called as a pair (Responsibility of the programmer) • Between acquire() and release() a thread “holds” the lock • Acquire does not return until lock is held • Only one thread can hold the lock at a time • What happens when there is a bad programmer? • Two basic types of locks: • Spinlocks: acquire() busy waits (spins) until lock is acquired • Mutexes: acquire() blocks (sleeps) until lock is acquired

Using Locks int withdraw(int amount){ balance -= amount; return balance; } acquire(lock); balance -= amount; • What happens at the 2nd acquire()? • What would happen if this was a uniprocessor and: • Acquire(lock) => asm(“cli”); • Release(lock) => asm(“sti”); acquire(lock) release(lock); int withdraw(int amount){ acquire(lock); balance -= amount; release(lock); return balance; } balance -= amount; release(lock);

Using locks badly int withdraw(int amount){ balance -= amount; return balance; } int main() { int balance = 0; acquire(lock); balance = withdraw(10); release(lock); return balance; } • Why not this? • Will this work correctly? • Always try to keep critical sections as small as possible • Helps performance, reduces bugs, easier to read, etc…

Locks without hardware support • Its not pretty… • Peterson’s algorithm • Assume 2 threads • tid -> Thread ID (0,1) int turn = 0; // shared variable bool lock[2] = {false, false}; int withdraw(int amount) { lock[tid] = true; turn = 1 – tid; while (lock[1 - tid] && (turn == (1 – tid))); // spin balance -= amount; // critical section lock[tid] = false; return balance; }

Locks with hardware support • CPU provides atomic instructions • Note that ALL x86 operations are not atomic by default, atomicity must be enabled explicitly • Two standard instructions: test-and-set, compare-and-swap • But there are others (See proj. 1) booltest_and_set(bool * flag) { bool old = *flag; *flag = true; return old; } intcompare_and_swap(int * value, intcmp, int new) { int old = *value; if (*value == cmp) { *value = new; } return old; }

Spinlocks • Basic form of mutual exclusion • Busy wait until a lock is available while (!acquire(lock)); • Problems: • Wastes resources while trying to acquire lock • Under contention utilization goes way down • Notes: • Only use for very short critical sections • Do not sleep with a lock held!

Reader writer locks • Like spin locks for read-mostly data • Reading is only sensitive if it is being actively modified • If modifications are rare then it doesn’t make sense to serialize readers • Must make sure not to starve writers acquire(write_lock) acquire(read_lock)

Barriers • Synchronize execution into a sequence of stages • Mostly used in parallel computation (time steps) • Each thread waits until every other thread is at the same location:barrier_wait(); • Once every thread arrives, continue; • Ensures that execution occurs in lock step across all threads Barrier Barrier Barrier

Wait Queues • Locking is bad • Busy waiting wastes resources • How do we use time waiting to do other stuff • Wait Queues • Sleep until an event arrives • Require signal from other thread to indicate status has changed • Re-evaluate current state before continuing

RCU • Read-copy-update • Replacement for reader-writer locks • Does not actually use locks • Creates different versions of shared data • Modifying data creates a new copy • Future readers access new copy • Old readers still have old version • Must garbage collect • Only after all readers are done • But how do we know? • Quiescent state • Place requirements on reader contexts (cannot sleep) • Therefore if a CPU with a reader has slept, then reader is done

Transactional memory • Embed transaction processing into memory system • Memory system tracks memory touched inside critical section (transaction) • If another thread modifies same data, transaction aborts • Execution returns to initial state • Memory contents reset to initial values • Present on latest Intel Haswell CPUs
