  1. XML Workshop XML – Standardformat für den Austausch von elektronischen Daten in der pharmazeutischen Industrie? Joerg Dillert Senior Consultant March, 30th, 2004

  2. 0. Allgemeines

  3. Der Workshop … • ist in Germisch!

  4. Ein paar Regeln • 9.00 – 16.30 • Pausen 15,60,15 • Handys aus oder Vibration! • Toiletten • Fluchtwege • Fragen - bitte jederzeit

  5. 1. Einführung Was ist eigentlich XML? Wie ist es entstanden?

  6. Handys, Smartphones und PDAs mit integrierter SyncML-Unterstützung Modell Anbieter Gerätetyp Verfügbarkeit • Alcatel: ot715 • Motorola: A830, A835, V600, E390 • Nokia 7250, 6800, 3650, 6220, 9210i, 7650 • Samsung SGH-D700 • Siemens: S55, SL55, M55, SX1 • Sony Ericsson: T68i, T610, P800, Z1010, PEG-NZ90 • PDAs: Sony PEG-NX70V, PEG-T675C,PEG-T625C

  7. Wir leben im Zeitalter der Buzzwords • B2B, B2M, E2B • DIA, EMEA, FDA • XML, DTD, XSL, SVG • Die (Computer) Industrie gibt uns viele neue Wörter jede Woche • Schauen Sie mal an Ihren Arbeitsplatz – welches sind denn so Ihre Buzzwords? (SOPs, DCFs, …)

  8. Smudo ... kennen Sie diese Deutsche Musikgruppe? MFG

  9. Urkundlich erwähnt … SGML Standard Generalized Markup Language ISO 88791 seit 1986

  10. The SGML family of markup languages – more buzzwords!! GML Generalized Markup Language Goldfarb, Mosher and Lorie, IBM, 1969 IBM Document Composition Facility DCF (Script) SGML Standardized Generalized Markup Language Content attributes. ISO-8879 first published in 1986 HTML HyperText Markup Language Functional attributes: hyperlink, frame Based on hyperdocument standard definitions CALS Continuous Acquisition and Life-cycle Support Based on DoD MIL-M-28001B standard definitions XML eXtensible Markup Language (Founding father: Dr. Charles F. Goldfarb, IBM)

  11. 1986 • Entwicklung SGML in den IBM Labs in Almaden • Charles Goldfarb • ISO Standard • Überarbeitung 1990, Ziel war eine universell einsetzbare Auszeichnungssprache für Dokumente

  12. A brief history of SGML The Evolution of Markup Languages • Plain text • Font attributes: Bold, underline, italics, font size • Document structure attributes: Heading level, index term • Document content attributes: Patient age, dosage unit

  13. 1990 • Am Kernforschungszentrum Cern in Genf begann Entwicklung von HTML • erster Entwurf 1993, Geburtstunde des Web • 1995 überarbeitet HTML Version 2.0

  14. 1994 • Um Wildwuchs zu verhindern – Gründung des World Wide Web Consortium (W3C) • primäre Aufgabe: Weiterentwicklung von HTML

  15. 1998 • W3C erkannte, daß mit HTML die Herausforderungen der Zukunft nicht gemeistert werden können • Zwischen Zuviel an Markup (SGML) und dem Zuwenig (HTML) sollte der goldene Mittelweg gefunden werden • Abschluß des Findungsprozesses – XML • 1998 als offizieller Standard verabschiedet

  16. 2001 • W3C verabschiedet als wichtigste Ergänzung die erste Version von XSL (Extensible Stylesheet Language) • stellt Regeln zur Umwandlung von XML Dokumenten und ein Vokabular zum Formatieren dieser Dokumente zur Verfügung • 2002 Arbeitsentwurf zu XHTML Version 2.0 , Bruch mit HTML 4.0 und XHMTL 1.0 – keine Rückwärtskompatibilität

  17. The big advantage of XML • You have flexibility - you can define your own TAGS • The Parser need only the DTD / Schemas for checking the correctness of your file • Readable for everyone • Vendor independent (No vendor can impose their own definitions, standards or undocumented formats) • License free ... all three types are in ASCII format! (American Standard Code for Information Interchange )

  18. XML and data interchange • This kind of information data interchange is the standard in other industries and is called B2B • The Germans favourite spare time object ... • is produced Just in Time

  19. B2B Server B2B Server What we‘ve learned from other industries ... Supplier System Y Car producer System X Request Order Delivery Proposal Order confirmation Delivery confirmation Invoicing

  20. XML is ... • The data interchange and document format for now and in the future (E2B, CDISC, CTD) • Is in practical use in many industries • E.g. car production industry • EVERY system can communicate with another • You need only ONE interface per system

  21. 2. XML eXtensible Markup Language

  22. XML • XML - eXtensible Markup Language • It is a subset of SGML • It focusses on content (sometimes also structure) • The XML file contains the DATA • It is restricted by TAGs • Example: <messagetype>ICSR</messagetype>

  23. An example as a graphic

  24. ... and as XML structure <ANA106> <Screening visit> <Inclusion criteria> <Inc1>YES</Inc1> <Inc2>YES</Inc2> <Inc3>YES</Inc3> <Inc4>YES</Inc4> </Inclusion criteria> <Exclusion criteria> <Excl1>NO</Excl1> <Excl2>NO</Excl2> <Excl3>NO</Excl3 <Excl4>NO</Excl4> </Exclusion criteria> <Demographic/Investigator> <Sex>Male</Sex> <DoB>07/26/1966</DoB> <Smoke>Yes</Smoke> <InvNo>128</InvNo> </Demographics/Investigator> ... --- more page(sections> </Screnning visit> <Visit 1> ... --- more blocks </Visit 1> ... --- more visits </ANA106>

  25. einfache XML Struktur <?xml version="1.0" encoding="ISO-8859-1"?> <DVMDTagung> <Workshop> <event > <stadt>Ulm</stadt> <ort>MedSchule</ort> </event> </Workshop> </ DVMDTagung >

  26. Attribute <?xml version="1.0" encoding="ISO-8859-1"?> <DVMDTagung> <Workshop name=„XML in der Pharmazeutischen Industrie" Leiter=„Joerg Dillert"> <event datum="31.03.2004"> <stadt>Ulm</stadt> <ort>MedSchule</ort> </event> <event datum=„25.06.2004"> <stadt>Berlin</stadt> <ort>PFOffice</ort> </event> </Workshop> </ DVMDTagung >

  27. Attribute <?xml version="1.0" encoding="ISO-8859-1"?> <!– zum Kommentieren --> <DVMDTagung> <Workshop name="XML in der Pharmazeutischen Industrie" Leiter=„Joerg Dillert"> <event datum="31.03.2004"> <stadt>Ulm</stadt> <ort>MedSchule</ort> </event> <event datum="25.06.2004"> <stadt>Berlin</stadt> <ort>PFOffice</ort> </event> </Workshop> </DVMDTagung > see in IE see in XML Notepad

  28. Characters • Character set • Characters that may be represented in XML document • e.g., ASCII character set • Letters of English alphabet • Digits (0-9) • Punctuation characters, such as !, - and ?

  29. Character Set • XML documents may contain • Carriage returns • Line feeds • Unicode characters • Enables computers to process characters for several languages

  30. Characters vs. Markup • XML must differentiate between • Markup text • Enclosed in angle brackets (< and >) • e.g,. Child elements • Character data • Text between start tag and end tag • e.g., Fig. 5.1, line 7: Welcome to XML!

  31. White Space, Entity References and Built-in Entities • Whitespace characters • Spaces, tabs, line feeds and carriage returns • Significant (preserved by application) • Insignificant (not preserved by application) • Normalization • Whitespace collapsed into single whitespace character • Sometimes whitespace removed entirely <markup>This is character data</markup> after normalization, becomes <markup>This is character data</markup>

  32. White Space, Entity References and Built-in Entities (cont.) • XML-reserved characters • Ampersand (&) • Left-angle bracket (<) • Right-angle bracket (>) • Apostrophe (’) • Double quote (”) • Entity references • Allow to use XML-reserved characters • Begin with ampersand (&) and end with semicolon (;) • Prevents from misinterpreting character data as markup

  33. White Space, Entity References and Built-in Entities (cont.) • Build-in entities • Ampersand (&amp;) • Left-angle bracket (&lt;) • Right-angle bracket (&gt;) • Apostrophe (&apos;) • Quotation mark (&quot;) • Mark up characters “<>&” in element message <message>&lt;&gt;&amp;</message> see in IE

  34. Using Unicode in an XML Document • XML Unicode support • e.g., displays Arabic words • Arabic characters • represented by entity references for Unicode characters

  35. XML document that contains Arabic words <?xml version = "1.0"?> <welcome> <from> &#1583;&#1575;&#1610;&#1578; &#1614;&#1604;&#1571;&#1606;&#1583; </from> <subject> &#1571;&#1607;&#1604;&#1575;&#1611; &#1576;&#1603;&#1605; &#1601;&#1610;&#1616; &#1593;&#1575;&#1604;&#1605; </subject> </welcome> see in IE

  36. Markup • XML element markup • Consists of • Start tag • Content • End tag • All elements must have corresponding end tag<img src =“img.gif”>is correct in HTML, but not XML • XML requires end tag or forward slash (/) for termination <img src =“img.gif”></img>or <img src =“img.gif”/>is correct XML syntax

  37. Markup (cont.) • Elements • Define structure • May (or may not) contain content • Child elements, character data, etc. • Attributes • Describe elements • Elements may have associated attributes • Placed within element’s start tag • Values are enclosed in quotes • Element car contains attribute doors, which has value “4” <car doors =“4”/>

  38. Markup (cont.) • Processing instruction (PI) • Passed to application using XML document • Provides application-specific document information • Delimited by <? and ?>

  39. 1 <?xml version = "1.0"?> 2 3 <!-- Fig. 5.5 : usage.xml --> 4 <!-- Usage of elements and attributes --> 5 6 <?xml:stylesheet type = "text/xsl"href = "usage.xsl"?> 7 8 <book isbn = "999-99999-9-X"> 9 <title>Deitel&amp;s XML Primer</title> 10 11 <author> 12 <firstName>Paul</firstName> 13 <lastName>Deitel</lastName> 14 </author> 15 16 <chapters> 17 <preface num = "1" pages = "2">Welcome</preface> 18 <chapter num = "1" pages = "4">Easy XML</chapter> 19 <chapter num = "2" pages = "2">XML Elements?</chapter> 20 <appendix num = "1" pages = "9">Entities</appendix> 21 </chapters> 22 23 <media type = "CD"/> 24 </book> PI discussed later

  40. CDATA Sections • CDATA sections • May contain text, reserved characters and whitespace • Reserved characters need not be replaced by entity references • Not processed by XML parser • Commonly used for scripting code (e.g., JavaScript) • Begin with <![CDATA[ • Terminate with ]]> see in IE

  41. 1 <?xml version = "1.0"?> 2 3 <!-- Fig. 5.7 : cdata.xml --> 4 <!-- CDATA section containing C++ code --> 5 6 <book title = "C++ How to Program" edition = "3"> 7 8 <sample> 9 // C++ comment 10 if ( this-&gt;getX() &lt; 5 &amp;&amp; value[ 0 ] != 3 ) 11 cerr &lt;&lt; this-&gt;displayError(); 12 </sample> 13 14 <sample> 15 <![CDATA[ 16 17 // C++ comment 18 if ( this->getX() < 5 && value[ 0 ] != 3 ) 19 cerr << this->displayError(); 20 ]]> 21 </sample> 22 23 C++ How to Program by Deitel &amp; Deitel 24 </book> CDATA

  42. CDATA (cont.)

  43. XML Namespaces • Naming collisions • Two different elements have same name <subject>Math</subject> <subject>Thrombosis</subject> • Namespaces • Differentiate elements that have same name<school:subject>Math</school:subject> <medical:subject>Thrombosis</medical:subject> • school and medical are namespace prefixes • Prepended to elements and attribute names • Tied to uniform resource identifier (URI) • Series of characters for differentiating names

  44. XML Namespaces (cont.) • Creating namespaces • Use xmlns keyword xmlns:text =“urn:deitel:textInfo” xmlns:image =“urn:deitel:imageInfo” • Creates two namespace prefixes text and image • urn:deitel:textInfo is URI for prefix text • urn:deitel:imageInfo is URI for prefix image • Default namespaces • Child elements of this namespace do not need prefix xmlns =“urn:deitel:textInfo”

  45. 1 <?xml version = "1.0"?> 2 3 <!-- Fig. 5.8 : namespace.xml --> 4 <!-- Namespaces --> 5 6 <directory xmlns:text = "urn:deitel:textInfo" 7 xmlns:image = "urn:deitel:imageInfo"> 8 9 <text:file filename = "book.xml"> 10 <text:description>A book list</text:description> 11 </text:file> 12 13 <image:file filename = "funny.jpg"> 14 <image:description>A funny picture</image:description> 15 <image:size width = "200" height = "100"/> 16 </image:file> 17 18 </directory> XML namespace - no default

  46. 1 <?xml version = "1.0"?> 2 3 <!-- Fig. 5.9 : defaultnamespace.xml --> 4 <!-- Using Default Namespaces --> 5 6 <directory xmlns = "urn:deitel:textInfo" 7 xmlns:image = "urn:deitel:imageInfo"> 8 9 <file filename = "book.xml"> 10 <description>A book list</description> 11 </file> 12 13 <image:file filename = "funny.jpg"> 14 <image:description>A funny picture</image:description> 15 <image:size width = "200"height = "100"/> 16 </image:file> 17 18 </directory> XML namespace with default default needs full name

  47. 3. DTD und Schemas

  48. DTD / Schema • DTD – Document Type Definition • Sometimes also called the ‘Document Type Description‘ • Today you have Schemas • Schemas are more detailed • Comes back to XML • Contains the ‘grammar’ of an XML document • The parser (a program) checks the correctness of the XML file based on the DTD / Schemas • numerics • characters ...

  49. Parsing / Validieren Correct (well-formed) file XML file DTD Schemas

  50. DTDs vs. Schemas • beschreiben den prinzipiellen Aufbau von Dokumenten eines bestimmten Typs • können entweder mit DTDs (Document Type Definitions) oder XML-Schemata spezifiziert werden • DTDs wurden von SGML übernommen und sind Teil von XML 1.0. • XMLSchema sind ein eigener W3C-Standard.
